MWI-108
< SYMPTOM DIAGNOSIS >[TYPE B]
THE OIL PRESSURE WARNING LAMP DOES NOT TURN ON
THE OIL PRESSURE WARNING
LAMP DOES NOT TURN ON
DescriptionINFOID:0000000012432649
The engine oil pressure warning lamp stays off when the ignition switch is turned ON.
Diagnosis ProcedureINFOID:0000000012432650
1.CHECK COMBINATION METER ENGIN E OIL PRESSURE WARNING LIGHT
1. Select METER/M&A on CONSULT.
2. Observe OIL W/L DATA MONITOR while operating the ignition switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
ComponentCondition CONSULT
Engine oil pressure warning light Ignition ON
ON
Ignition OFF OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
THE OIL PRESSURE WARNING LAMP DOES NOT TURN OFFMWI-109
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
THE OIL PRESSURE WARNING LAMP DOES NOT TURN OFF
DescriptionINFOID:0000000012432651
The engine oil pressure warning lamp remains on while the engine is running (normal oil pressure).
Diagnosis ProcedureINFOID:0000000012432652
1.CHECK COMBINATION METER INPUT SIGNAL
1. Start the engine and select METER/M&A on CONSULT.
2. Observe OIL W/L DATA MONITOR and the operation of the engine oil pressure warning lamp on the com- bination meter.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Perform ECM self-diagnosis. Refer to EC-60, "
CONSULT Function".
ComponentConditionCONSULT
Engine oil pressure warning light Engine runningOFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-110
< SYMPTOM DIAGNOSIS >[TYPE B]
THE DOOR OPEN WARNING CONTINU
ES DISPLAYING, OR DOES NOT DIS-
PLAY
THE DOOR OPEN WARNING CONTIN UES DISPLAYING, OR DOES NOT
DISPLAY
DescriptionINFOID:0000000012432653
• The door ajar warning is displayed even though all of the doors are closed.
• The door ajar warning is not displayed even though a door is ajar.
Diagnosis ProcedureINFOID:0000000012432654
1.CHECK BCM INPUT SIGNAL
Check the BCM input signal. Refer to DLK-98, "
ComponentFunctionCheck" (with Intelligent Key system) or
DLK-232, "
ComponentFunctionCheck" (without Intelligent Key system).
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK COMBINATION METER INPUT SIGNAL
Select the METER/M&A Data Moni tor and check the DOOR W/L monitor value while opening and closing
doors.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (without Intelligent Key system).
3.CHECK DOOR SWITCH SIGNAL CIRCUIT
Check the door switch signal circuit. Refer to DLK-98, "
Diagnosis Procedure" (with Intelligent Key system) or
DLK-232, "
Diagnosis Procedure" (without Intelligent Key system).
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK DOOR SWITCH
Check the door switch. Refer to DLK-99, "
Component Inspection" (with Intelligent Key system) or DLK-234,
"Component Inspection" (without Intelligent Key system).
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Replace applicable door switch. Refer to DLK-181, "
Removal and Installation" (with Intelligent Key
system) or DLK-308, "
Removal and Installation" (without Intelligent Key system).
Monitor item Condition Status
DOOR W/L Door open
ON
Door closed OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
THE PARKING BRAKE RELEASE WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
MWI-111
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
THE PARKING BRAKE RELEASE WA RNING CONTINUES DISPLAYING,
OR DOES NOT DISPLAY
DescriptionINFOID:0000000012432655
• The parking brake warning is displayed while driving the vehicle even though the parking brake is released.
• The parking brake warning is not displayed while driving the vehicle even though the parking brake is
applied.
Diagnosis ProcedureINFOID:0000000012432656
1.CHECK PARKING BRAKE WARNING LAMP OPERATION
1. Start engine.
2. Check the operation of the brake warni ng lamp while operating the parking brake.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> GO TO 2.
2.CHECK PARKING BRAKE SWITCH
Check the parking brake switch. Refer to WCS-44, "
TYPE B : Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace parking brake switch. Refer to PB-6, "
Exploded View".
3.CHECK PARKING BRAKE SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Check the parking brake switch signal circuit. Refer to WCS-43, "
TYPE B : Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Repair or replace harness or connector.
Condition Warning lamp status
Parking brake applied ON
Parking brake released OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-114
< SYMPTOM DIAGNOSIS >[TYPE B]
THE LOW WASHER FLUID WARNING
CONTINUES DISPLAYING, OR DOES
NOT DISPLAY
THE LOW WASHER FLUID WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
DescriptionINFOID:0000000012432661
• The warning is still displayed even after washer fluid is added.
• The warning is not displayed even though the washer tank is empty.
Diagnosis ProcedureINFOID:0000000012432662
1.CHECK WASHER FLUID LEVEL SWITCH
Check the washer fluid level switch. Refer to MWI-106, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace washer fluid level switch. Refer to WW-59, "
Removal and Installation".
2.CHECK WASHER FLUID LEVEL SWITCH SIGNAL CIRCUIT
Check the washer fluid level switch signal circuit. Refer to MWI-106, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Repair or replace harness or connector.
Revision: August 2015 2016 Versa Note

cardiagn.com

MIR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432080
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000012432081
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note

cardiagn.com

PB-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430686
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: August 2015 2016 Versa Note

cardiagn.com

PB-4
< PERIODIC MAINTENANCE >
PARKING BRAKE SYSTEM
PERIODIC MAINTENANCE
PARKING BRAKE SYSTEM
Inspection and AdjustmentINFOID:0000000012430688
INSPECTION
Parking Brake Control Stroke
1. When parking brake control is operated with a force of 196 N(20.0 kg-f, 44.1 lb-f), make sure parking brake control stroke is
within the specified number of notches. (Check by listening and
counting the number of ratchet clicks.)
2. Check that the parking brake lamp illuminates, after parking brake has been operated to the specified number of notches.
Inspect Components
• Check the parking brake components for bends, wear and or damage. Replace if any damage is noted.
• Check that the parking brake operates properly ; be sure that it is not bound up or sticking.
• Check that the brake warning light illuminates afte r parking brake has been operated to the specified number
of notches. Refer to PB-10, "
Parking Brake Control".
• Inspect and adjust the rear brakes if necessary. Refer to BR-43, "
Inspection and Adjustment".
ADJUSTMENT
1. Pull parking brake control (1) until the access hole (2) is visible.
Use suitable tool to adjust nut (A).
2. Turn adjusting nut (A) using suitable tool to loosen the front cable.
3. Depress the brake pedal with a force of 196 N (20. 0 kg-f, 44.1 lb-f) about 10 times and adjust the brake
shoe clearance.
4. Adjust the cable with the following procedure. CAUTION:Number of
notches
: Refer to PB-10, "
Parking Brake
Control".
Number of
notches : Refer to PB-10, "
Parking Brake
Control".
WFIA0508E
AWFIA1013ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com
