2016 NISSAN NOTE stop start

STC-36
< SYMPTOM DIAGNOSIS >
UNBALANCE STEERING WHEEL TURNING FORCE (TORQUE VARIATION)
Does the symptom continue?
YES >> GO TO 7.
NO >> The assist torque decreases because of protection function. This is not malfunction. Inspection
End.
7.CHECK EPS CONTROL UNIT SIGNAL (4)
With CONSULT
1. Start the engine.
CAUTION:
Never drive the vehicle.
2. Turn steering wheel from full left stop to full right stop.
3. Select “TORQUE SENSOR” in “Data Monitor” of “EPS”.
4. Perform the torque sensor inspection.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.CHECK EPS MOTOR
Perform the trouble diagnosis of EPS motor. Refer to STC-23, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace the specific malfunctioning part.
9.CHECK STEERING WHEEL TURNING FORCE
Check the steering wheel turning force. Refer to ST-19, "
Steering Wheel Turning Force".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check the steering wheel turning force for mechanical malfunction. Refer to ST-19, "
Steering
Wheel Turning Force".
Monitor item ConditionDisplay value
TORQUE SENSOR Steering wheel: Not steering (There is no
steering force)
Approx. 0 Nm
Steering wheel: Right turn Positive value (Nm)
Steering wheel: Left turn Negative value (Nm)
Revision: August 2015 2016 Versa Note

cardiagn.com

GEAR OILTM-17
< PERIODIC MAINTENANCE > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PERIODIC MAINTENANCE
GEAR OIL
InspectionINFOID:0000000012430947
GEAR OIL LEAKS
Make sure that gear oil is not l eaking from transaxle or around it.
GEAR OIL LEVEL
1. Remove filler plug (1) and gasket from transaxle case.
2. Check the gear oil level from filler plug hole as shown.
CAUTION:
Do not start engine whil e checking gear oil level.
3. Install a new gasket on filler plug and then install filler plug to transaxle case.
CAUTION:
Do not reuse gasket.
4. Tighten filler plug to the specified torque. Refer to TM-26,
"Exploded View".
DrainingINFOID:0000000012430948
1. Start engine and let it run to warm up transaxle.
2. Stop engine. Remove drain plug (1) and gasket, using suitable
tool and then drain gear oil.
3. Install a new gasket on drain plug (1) and install drain plug to clutch housing, using suitable tool.
CAUTION:
Do not reuse gasket.
4. Tighten drain plug (1) to the specified torque. Refer to TM-26,
"Exploded View".
RefillingINFOID:0000000012430949
1. Remove filler plug (1) and gasket from transaxle case.
2. Fill with new gear oil until gear oil level reaches the specified limit at filler plug hole as shown.
CAUTION:
Do not start engine whil e checking gear oil level.
3. Install a new gasket on filler plug and then install filler plug to transaxle case.
CAUTION:
Do not reuse gasket.
4. Tighten filler plug to the specified torque. Refer to TM-26, "
Exploded View".
SCIA7119E
PCIB1504E
Oil capacity
and viscosity: Refer to
MA-11, "Fluids and Lubri-
cants".
SCIA7119E
Revision: August 2015 2016 Versa Note

cardiagn.com

TRANSAXLE ASSEMBLYTM-25
< UNIT REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• Do not reuse self-tapping bolt.
• Tighten transaxle assembly bolts to the specified torque. The illus- tration is the view from the engine.
InspectionINFOID:0000000012430963
INSPECTION AFTER INSTALLATION
• Check the operation of the control linkage. Refer to TM-21, "Inspection".
• Before starting engine, check oil/fluid levels incl uding engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-11, "
Fluids and Lubricants".
• Use procedure below to check for fuel leaks.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leaks at connection points.
• Start engine. With engine speed increased, check again for fuel leaks at connection points.
• Run engine to check for unusual noise and vibration. NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal and installation, slack in the guide
may generate a pounding noise during and just after engine start. However, this is normal. Noise will stop
after hydraulic pressure rises.
• Warm up engine thoroughly to make sure there is no lea ks of fuel, exhaust gas, or any oils/fluids including
engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec-
ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc.
Bolt symbol
ABC D
Insertion direction Transaxle to
engine Engine to transaxle
Quantity 2321
Bolt length
() mm (in) 55 (2.17)
49 (1.93) 69 (2.72)
Tightening torque
N·m (kg-m, ft-lb) 48.0 (4.9, 35)
JPDIC0813ZZ
Item
Before starting engine Engine runningAfter engine stopped
Engine coolant LevelLeaks Level
Engine oil LevelLeaks Level
Transmission/
transaxle fluid CVT Models
LeaksLevel/Leaks Leaks
M/T Models Level/Leaks LeaksLevel/Leaks
Other oils and fluids* LevelLeaks Level
Fuel LeaksLeaks Leaks
Exhaust gas —Leaks —
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-84
< SYSTEM DESCRIPTION >[CVT: RE0F11A]
SYSTEM
Gear shifting is performed in all shifting ranges from the lowest to the
highest gear ratio.
D Position (OD OFF)
The gear ratio is generally high by limiting the shifting range on the
high side, and this always generates a large driving power.
L Position
By limiting the shifting range only to the lowest of the gear ratio, a
large driving force and engine brake are obtained.
Hill Climbing And Descending Control
If a downhill is detected with the accelerator pedal is released, the system performs dow
nshift to increase the
engine brake force so that vehicle may not be accelerated more than necessary. If a climbing hill is detected,
the system improves the acceleration performance in re-acceleration by limiting the gear shift range on the
high side.
NOTE:
For engine brake control on a downhill, the control can be stopped with CONSULT.
Control In Acceleration
From change of the vehicle speed or accelerator pedal posit ion, the acceleration request level of the driver or
driving scene is evaluated. In start or acceleration during driving, the gear shift characteristics with linearity of
revolution increase and vehicle speed increase are gained to improve the acceleration feel.
SELECT CONTROL
SCIA1953E
SCIA8229E
SCIA8240E
JSDIA2060GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-88
< SYSTEM DESCRIPTION >[CVT: RE0F11A]
SYSTEM
Provides idle neutral control when st
op/start operation is not performed.
Idle Neutral Control Start Condition
Idle neutral control is started when all of the following conditions are fulfilled. However, during idle neutral con-
trol, idle neutral control is stopped when any of the following conditions is not met or idle neutral control contin-
ues 30 seconds.
NOTE:
Stops or prohibits the idle neutral control when the TC M and ECM detect that the vehicle is in one of the fol-
lowing conditions.
• Engine coolant temperature and CVT fluid temperature are the specified temperature or more, or the speci-
fied temperature or less.
• When a transaxle malfunction occurs.
• When the vehicle detects DTC and is in the fail-safe mode.
• When idle speed increases due to heavy electric load*. *: When any one of rear window defogger switch, A/C s witch, headlamp, fog lamp is turned ON. In addition,
when the steering wheel is operated.
JPDIA1215GB
Driving environment : Flat road or road with mild gradient
Selector lever position : “D” position
Vehicle speed : 0 km/h (0 MPH)
Accelerator pedal position : 0.0/8
Brake pedal : Depressed
Engine speed : Idle speed
Turn signal lamp/hazard signal lamp : Not activated
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-100
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
TOTAL GEAR RATIOAuxiliary gearbox: 1GR
Counter gear ratio
×Pulley ratio Auxiliary
gearbox gear ratio
Auxiliary gearbox: 2GR Counter gear ratio ×Pulley ratio
PULLEY GEAR RATIO In driving (forward)
2.20 − 0.55
In driving (reverse) 2.20
AUX GEARBOX Vehicle started with selector lever in “L” position
1st
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 2nd
In gear shifting of auxiliary gearbox 1st ⇔ 2nd
G SPEED Vehicle stopped
0.00 G
During acceleration The value changes to the positive side
along with acceleration.
During deceleration The value changes to the positive side
along with deceleration.
ACCEL POSI SEN 1 Accelerator pedal released
0.00 deg
Accelerator pedal fully depressed 80.00 deg
VENG TRQ While driving The value changes along with acceleration/
deceleration.
PRI TRQ While driving The value changes along with acceleration/
deceleration.
TRQ RTO While driving The value changes along with acceleration/
deceleration.
LINE PRESSURE Selector lever: “P” position 0.575 MPa
FLUID TEMP Ignition switch ON. Displays the CVT fluid temperature.
DSR REV While driving It varies along with the driving condition.
TRGT GEAR RATIO While driving It varies along with the driving condition.
TGT PLLY GR RATIO In driving (forward)
2.20 − 0.55
In driving (reverse) 2.20
TRGT AUX GEARBOX Vehicle started with selector lever in “L” position
1st
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 2nd
In gear shifting of auxiliary gearbox Display gear position after gear shifting
LU PRS • Engine started
• Vehicle is stopped.
−
0.500 MPa
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.450 MPa
LINE PRS • After engine warm up
• Selector lever: “N” position
•At idle
0.500 MPa
• After engine warming up
• Selector lever: “D” position
• Depress the accelerator pedal fully 4.930 – 5.430 MPa
TRGT PRI PRESSURE • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH) 0.325 MPa
Monitor item
ConditionValue/Status (Approx.)
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-105
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P37
(BR/W) GroundHigh clutch & re-
verse brake sole-
noid valve OutputIn driving at “L” position
Release the accelerator pedal after
the following conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 50 km/h (31 MPH) or more
38
(G) Ground Torque converter
clutch solenoid
valve Output• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 20 km/h (12 MPH) or more
• Engine started
• Vehicle is stopped
39
(G/B) Ground
Low brake solenoid
valve Output• Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH)
Release the accelerator pedal after
the following conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 50 km/h (31 MPH) or more
Te r m i n a l N o .
(Wire color) Description
ConditionValue (Approx.)
+ − Signal Input/
OutputJSDIA1897GB
JSDIA3653GB
JSDIA1900GB
JSDIA1901GB
JSDIA1902GB
JSDIA1903GB
Revision: August 2015 2016 Versa Note

cardiagn.com

ADDITIONAL SERVICE WHEN REPLACING CONTROL VALVE OR TRANSAXLE
ASSEMBLY
TM-127
< BASIC INSPECTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ADDITIONAL SERVICE WHEN REPL ACING CONTROL VALVE OR TRAN-
SAXLE ASSEMBLY
DescriptionINFOID:0000000012431044
When replacing the control valve or transaxle assembly , perform the following work. For work procedure, refer
to TM-130, "
Work Procedure".
ERASING, LOADING AND STORING OF CALIBRATION DATA• The TCM acquires calibration data (individual characteristic value) of each solenoid that is stored in the
ROM assembly (in the control valve). This enables the TCM to perform accurate control. For this reason,
after the control valve or transaxle assembly is replaced, it is necessary to erase the calibration data previ-
ously stored in TCM, to load new calibration data, and to store them.
ERASING THE LEARNED VALUE DATA• TCM learns indicated pressure for appropriate control of the transaxle assembly and records the learned
values. For this reason, the leaned values stored in TCM must be erased after replacing a transaxle assem-
bly.
ERASING CVT FLUID DEGR ADATION LEVEL DATA • TCM records the degradation level of the CVT fluid calculated from the vehicle driving status. Therefore, if
the transaxle assembly is replaced, it is necessary to erase the CVT fluid degradation level data recorded by
TCM.
Work ProcedureINFOID:0000000012431045
1.INITIALIZE TCM
With CONSULT
1. Set parking brake.
2. Turn ignition switch ON.
3. Select “Work Support” in “TRANSMISSION”.
4. Select “ERASE MEMORY DATA”.
5. While maintaining the conditions below, touch “Start”.
- Vehicle stop status
- With engine stopped
- Selector lever: “R” position
- Accelerator pedal: Depressed
NOTE:
Select “Start” and complete within approximately 20 seconds.
Is
“COMPLETED” displayed?
YES >> GO TO 2.
NO >> Turn the ignition switch OFF and wait for a minimum of 10 seconds then perform the work again.
2.CHECK AFTER TCM IS INITIALIZED
With CONSULT
1. Turn ignition switch OFF with the selector lever in “R” position and wait for 10 seconds or more.
2. Turn ignition switch ON with the selector lever in “R” position. CAUTION:
Never start the engine.
3. Select “Special function” in “TRANSMISSION”.
4. Select “CALIB DATA”.
5. Check that indicated value of “CALIB DATA” is equal to the value shown in the following table.
Item name Display value Item nameDisplay value
UNIT CLB ID1 00MAP NO HC/RB 00
UNIT CLB ID2 00MAP NO L/B 00
UNIT CLB ID3 00OFFSET2 LU 0
UNIT CLB ID4 00OFFSET2 PL 0
Revision: August 2015 2016 Versa Note

cardiagn.com
