2016 NISSAN NOTE re0f

TM-156
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
4. Stop the vehicle.
CAUTION:
Never turn ignition switch OFF
5. Check the first trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO >> GO TO 8.
8.CHECK CVT FLUID TE MPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperat ure sensor. Replace control valve. Refer to TM-259,
"Removal and Installation".
Diagnosis ProcedureINFOID:0000000012431087
1.CHECK CVT FLUID TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check CVT fluid temperature sensor. Refer to TM-156, "
Component Inspection (CVT Fluid Temperature
Sensor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431088
1.CHECK CVT FLUID TE MPERATURE SENSOR
Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperatur e sensor. Replace control valve assembly. Refer to
TM-242, "
Removal and Installation".
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT unit Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °F) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °F) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °F) 0.87 k Ω
CVT unit
Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °C) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °C) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °C) 0.87 k Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0712 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-157
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0712 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431089
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for 10 seconds or more.
2. Check the first trip DTC.
Is
“P0712” detected?
YES >> Go to TM-157, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431090
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CVT FLUID TEMPERATURE SENSOR
Check CVT fluid temperature sensor. Refer to TM-157, "
Component Inspection (CVT Fluid Temperature Sen-
sor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431091
1.CHECK CVT FLUID TEMPERATURE SENSOR
Check resistance between CVT unit connector terminals.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0712 Transmission Fluid Tempera-
ture Sensor A Circuit Low The CVT fluid temperature identified by the
TCM is 180
°C (356 °F) or more continuously
for 5 seconds or more under the following di-
agnosis conditions:
• Diagnosis conditions
- Ignition switch: ON
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
shorted to ground)
• CVT fluid temperature sensor
TCM —Continuity
Connector Terminal
F44 12Ground Not existed
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-158
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0712 TRANSMISSION FLUID
TEMPERATURE SENSOR A
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperatur e sensor. Replace control valve assembly. Refer to
TM-242, "
Removal and Installation".
CVT unit Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °C) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °C) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °C) 0.87 k Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0713 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-159
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0713 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431092
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Maintain the following condition for 10 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0713” detected?
YES >> Go to TM-159, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431093
1.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminals and CVT unit harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 2)
1. Turn ignition switch ON.
2. Check voltage between TCM harness connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0713 Transmission Fluid Tempera-
ture Sensor A Circuit High The CVT fluid temperature identified by the
TCM is
−40 °C (− 40°F) or less continuously for
5 seconds or more under the following diagno-
sis conditions:
• Diagnosis conditions
- Ignition switch: ON
- Vehicle speed: More than 10 km/h (7 MPH)
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
open or shorted to power supply)
• CVT fluid temperature sensor
Vehicle speed : 20 km/h (12 MPH) or more
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F44 12
F46 12
Existed
11 1 8
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-160
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0713 TRANSMISSION FLUID
TEMPERATURE SENSOR A
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning part.
3.CHECK CVT FLUID TEMPERATURE SENSOR
Check CVT fluid temperature sensor. Refer to TM-160, "
Component Inspection (CVT Fluid Temperature Sen-
sor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431094
1.CHECK CVT FLUID TE MPERATURE SENSOR
Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperatur e sensor. Replace control valve assembly. Refer to
TM-242, "
Removal and Installation".
+
−Vol tag e
(Approx.)
TCM
Connector Terminal F44 12Ground 0 V
CVT unit
Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °C) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °C) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °C) 0.87 k Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0715 INPUT SPEED SENSOR ATM-161
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0715 INPUT SPEED SENSOR A
DTC LogicINFOID:0000000012431095
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0715” detected?
YES >> Go to TM-161, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431096
1.CHECK PRIMARY SPEED SENSOR POWER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect primary speed sensor connector.
3. Turn ignition switch ON.
4. Check voltage between primary speed sensor harness connector terminal and ground.
Is the inspection result normal?
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0715 Input/Turbine Speed Sensor A
Circuit The primary speed sensor value is less than
150 rpm continuously for 5 seconds or more
under the following diagnosis conditions:
• Diagnosis conditions
- Secondary pulley speed: 1,000 rpm or more
- TCM power supply voltage: More than 11 V
• Harness or connector
(Primary speed sensor circuit is open
or shorted)
• Primary speed sensor
The primary speed sensor value is 240 rpm or
less continuously for 500 msec or more under
the following diagnosis conditions:
• Diagnosis conditions
- 10-msec-ago primary pulley speed: 1,000
rpm or more
- TCM power supply voltage: More than 11 V
Selector lever : “L” POSITION
Vehicle speed : 40 km/h (25 MPH) or more
+ −Vol tag e
Primary speed sensor
Connector Terminal F50 3 Ground 10 – 16 V
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-162
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0715 INPUT SPEED SENSOR A
YES >> GO TO 2.
NO >> GO TO 6.
2.CHECK PRIMARY SPEED SENSOR GROUND CIRCUIT
Check continuity between primary speed s ensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK CIRCUIT BETWEEN PRIMARY SPEED SENSOR AND TCM (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between primary speed sensor harness connector terminal and TCM harness connector terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CHECK CIRCUIT BETWEEN PRIMARY SPEED SENSOR AND TCM (PART 2)
Check continuity between primary speed s ensor harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK TCM INPUT SIGNALS
1. Connect all of disconnected connectors.
2. Lift the vehicle.
3. Start the engine.
4. Check frequency of pr imary speed sensor.
Is the inspection result normal?
Primary speed sensor —Continuity
Connector Terminal
F50 1 Ground Existed
Primary speed sensor TCM
Continuity
Connector Terminal Connector Terminal
F50 2 F44 35 Existed
Primary speed sensor —Continuity
Connector Terminal
F50 2 Ground Not existed
+
− Condition Frequency
(Approx.)
TCM
Connector Terminal
F44 35 Ground • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH) 1,100 Hz
JSDIA1906GB
Revision: August 2015
2016 Versa Note

cardiagn.com

P0715 INPUT SPEED SENSOR ATM-163
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace primary speed sensor. TM-246, "
Removal and Installation".
6.CHECK CIRCUIT BETWEEN IPDM E/R AND PRIMARY SPEED SENSOR
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R harness connec tor terminal and primary speed sensor harness con-
nector terminal.
Is the check result normal?
YES >> GO TO 7.
NO >> Repair or replace malfunctioning parts.
7.DETECT MALFUNCTIONING ITEMS
Check the following items:
• Open circuit or short circuit in harness betw een ignition switch and IPDM E/R. Refer to PG-27, "
Wiring Dia-
gram — Ignition Power Supply —".
• Short circuit in harness between IPDM E/R harness connector terminal 21 and primary speed sensor har-
ness connector terminal 3.
• 10A fuse (No.49, IPDM E/R). Refer to PG-60, "
IPDM E/R Terminal Arrangement".
• IPDM E/R
Is the check result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
IPDM E/R Primary speed sensor
Continuity
Connector Terminal Connector Terminal
E45 21F50 3 Existed
Revision: August 2015 2016 Versa Note

cardiagn.com
