P0744 TORQUE CONVERTER
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0744” detected?
YES >> Go to TM-172, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431106
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-132, "
Work Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunction items.
2.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check torque converter clutch solenoid valve. Refer to TM-172, "
Component Inspection (Torque Con-
verter Clutch Solenoid Valve)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunction items.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the transaxle assembly. Refer to TM-259, "Removal and Installation".
NO >> Repair or replace the malfunction items.
Component Inspection (Torque C onverter Clutch Solenoid Valve)INFOID:0000000012431107
1.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of torque converter clutch solenoid valve. Replace control valve assembly.
Refer to TM-242, "
Removal and Installation".
CVT unit
— Condition Resistance
(Approx.)
Te r m i n a l
8Ground CVT fluid temperature: 20
°C (68 °F) 6.1 Ω
CVT fluid temperature: 50 °C (122 °F) 6.9 Ω
CVT fluid temperature: 80 °C (176 °F) 7.7 Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0746 PRESSURE CONTROL SOLENOID ATM-173
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0746 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000012431108
DTC DETECTION LOGIC
NOTE:
DC stands for "DRIVING CYCLE" and indicates a seri es of driving cycle of "Ignition switch OFF → ON → driv-
ing → OFF".
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0746 Pressure Control Solenoid A
Performance/Stuck Off The detecting condition A or detection condi-
tion B is detected twice or more (1 second or
more later after detection of the first) in the
same DC under the following diagnosis condi-
tions:
• Diagnosis conditions
- After the ignition switch is ON, 500 msec or
more have passed.
- Selector lever: Other than “P” and “N” posi-
tions
- Idle is not being detected.
- Engine speed: 600 rpm or more
- Primary pulley speed: 500 rpm or more
- Auxiliary gearbox shifting is not in progress.
- Acceleration/deceleration speed: −0.05 G
or more
- The primary pulley speed experienced 306
rpm or more and the secondary pulley
speed experienced 230 rpm or more at
least once.
- The output speed is 107 rpm or less or the
secondary pulley speed exceeds 61 rpm.
• Detection condition A
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio ex-
ceeding 2.55 is 200 msec or more continu-
ously.
• Detection condition B
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio ex-
ceeding 3.35 is 100 msec or more continu-
ously. • Line pressure solenoid valve
• Control valve assembly
Selector lever
: “D” position
Accelerator pedal position : 0.1/8 or more
Vehicle speed : 40 km/h (25 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-174
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0746 PRESSURE CONTROL SOLENOID A
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0746”detected?
YES >> Go to TM-174, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431109
1.CHECK LINE PRESSURE SOLENOID VALVE
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check line pressure solenoid valve. Refer to TM-174, "
Component Inspection (Line Pressure Solenoid
Va l v e )"
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-132, "
Work Procedure".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (Lin e Pressure Solenoid Valve)INFOID:0000000012431110
1.CHECK LINE PRESSURE SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of line pressure solenoi d valve. Replace transaxle assembly. Refer to TM-
259, "Removal and Installation".
CVT unit
— Condition Resistance
(Approx.)
Te r m i n a l
1Ground CVT fluid temperature: 20
°C (68 °F) 5.3 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.7 Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0846 TRANSMISSION FLUID PRESSURE SEN/SW BTM-175
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0846 TRANSMISSION FLUI D PRESSURE SEN/SW B
DTC LogicINFOID:0000000012431111
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Shift the selector lever to “D” position.
3. Drive the vehicle at a constant velocity of 40 km/h (25 MPH) at lease for 10 seconds.
CAUTION:
At the same time, the accelerator pedal angle must be maintained constant.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0846”detected?
YES >> Go to TM-175, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431112
1.CHECK TCM INPUT SIGNAL
1. Start the engine.
2. Check voltage between TCM connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0846 Transmission Fluid Pressure
Sensor/Switch B Circuit
Range/Performance The detection conditions continuously for 5
seconds or more under the following diagno-
sis conditions:
• Diagnosis conditions
- Selector lever:
“D” position
- The primary pulley speed experienced 306 rpm or more and the secondary pulley
speed experienced 230 rpm or more at
least once.
- Wheel spin is not being detected.
- The rate of change in pulley ratio: Between −0.09 and +0.09 inclusive
- Solenoid valve output current: 750 mA or more
- GND short diagnosis of the solenoid valve circuit is not satisfied.
- TCM power supply voltage: More than 11 V
• Detection conditions
- After the value of “Actual secondary pres-
sure − Target secondary pressure” exceeds
0.675 MPa:
• The rate of change in vehicle speed [km/h (MPH)]: Between −49 ( −30) and +49 (+30)
inclusive
• The rate of change in accelerator pedal an- gle: Between −1.3/8 and +1.3/8 inclusive • Secondary pressure sensor
• Control valve assembly
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-176
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0846 TRANSMISSION FLUID PRESSURE SEN/SW B
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-42, "Intermittent Incident".
NO >> There is a malfunction of secondary pressure sensor value. Replace control valve assembly.
Refer to TM-242, "
Removal and Installation".
+
−Condition Voltage
TCM
Connector Terminal
F44 16 Ground • After engine warm up
• Selector lever:
“N” position
• At idle 0.88 – 0.92 V
Revision: August 2015
2016 Versa Note

cardiagn.com

P0847 TRANSMISSION FLUID PRESSURE SEN/SW BTM-177
