2016 NISSAN NOTE engine

SEC-94
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B26F3 STARTER CONTROL RELAY
B26F3 STARTER CONTROL RELAY
DTC LogicINFOID:0000000012430410
DTC DETECTION LOGIC
NOTE:
• If DTC B26F3 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B26F3 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under t he following conditions to start engine:
- Selector lever: In the P position
- Brake pedal: Not depressed
2. Wait 2 seconds after engine started.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-94, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430411
1.CHECK DTC OF IPDM E/R
Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Perform the diagnosis procedure rela ted to the detected DTC. Refer to PCS-20, "DTCIndex".
NO >> GO TO 2.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B26F3 START CONT RLY ON BCM requests IPDM E/R to turn starter
control relay OFF, but BCM cannot receive
starter control relay OFF state signal from
IPDM E/R (CAN). • Harness or connectors
(The CAN communication line is open
or shorted.)
• IPDM E/R
Revision: August 2015 2016 Versa Note

cardiagn.com

B26F4 STARTER CONTROL RELAYSEC-95
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B26F4 STARTER CONTROL RELAY
DTC LogicINFOID:0000000012430412
DTC DETECTION LOGIC
NOTE:
• If DTC B26F4 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B26F4 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under the following conditions to start engine, and wait 1 second or more:
- Selector lever: In the P position
- Brake pedal: Not depressed
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-95, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430413
1.CHECK DTC OF IPDM E/R
Check DTC in “Self Diagnostic Result ” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Perform the diagnosis procedure related to the detected DTC. Refer to PCS-20, "DTCIndex".
NO >> GO TO 2.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B26F4 START CONT RLY OFF BCM requests IPDM E/R to turn starter
control relay ON, but BCM cannot receive
starter control relay ON state signal from
IPDM E/R (CAN). • Harness or connectors
(The CAN communication line is open
or shorted.)
• IPDM E/R
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-112
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
ENGINE DOES NOT START WHEN INTELLI
GENT KEY IS INSIDE OF VEHICLE
SYMPTOM DIAGNOSIS
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF VE-
HICLE
DescriptionINFOID:0000000012430432
Engine does not start when push-button ignition swit ch is pressed while carrying Intelligent Key.
NOTE:
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• The engine start function, door lock function, power di stribution system, and NATS-IVIS/NVIS in the Intelli-
gent Key system are closely related to each other regarding control. The vehicle security function can oper-
ate only when the door lock and power dist ribution system are operating normally.
Conditions of Vehicle (Operating Conditions)
• “ENGINE START BY I-KEY” setting in “Work suppor t” in “INTELLIGENT KEY” of “BCM” is ON.
• One or more of Intelligent Keys with registered Intelligent Key ID is in the vehicle.
Diagnosis ProcedureINFOID:0000000012430433
1.PERFORM WORK SUPPORT
Perform “INSIDE ANT DIAGNOSIS” in “Work Support” of “INTELLIGENT KEY” of “BCM” using CONSULT.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
>> GO TO 2.
2.PERFORM SELF-DIAGNOSIS RESULT
Select “Self Diagnostic Result” mode of “BCM”, and check whether or not DTC of inside key antenna is
detected.
Is DTC detected?
YES >> Perform the trouble diagnosis for detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 3.
3.CHECK PUSH-BUTTON IGNITION SWITCH
Check push-button ignition switch.
Refer to SEC-66, "
Component Inspection".
Is the operation normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com

PRECAUTIONSSEC-117
< PRECAUTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430439
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Precaution for WorkINFOID:0000000012430440
• When removing or disassembling each component, be ca reful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusabl e part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
-Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty
area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-120
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
No.
Component Function
1. Combination meter Combination meter transmits the vehicle
speed signal to BCM via CAN communica-
tion.
BCM also receives the vehicle speed signal
from ABS actuator and electric unit (control
unit) via CAN communication. BCM com-
pares both signals to detect the vehicle
speed.
Security indicator lamp is located on combi-
nation meter.
Security indicator lamp blinks when ignition
switch is in any position other than ON to
warn that NISSAN VEHICLE IMMOBILIZER
SYSTEM-NATS [NVIS (NATS)] is on board.
Refer to MWI-8, "
METER SYSTEM : Compo-
nent Parts Location".
2. ABS actuator and electric unit (control unit) ABS actuator and electric unit (control unit)
transmits the vehicle speed signal to BCM via
CAN communication.
BCM also receives the vehicle speed signal
from the combination meter via CAN commu-
nication. BCM compares both signals to de-
tect the vehicle speed.
Refer to
BRC-7, "
Component Parts Location"
for detailed installation location.
3. Transmission range switch Transmission range switch detects the CVT
shift selector lever position.
4. IPDM E/R Starter control relay is used for the engine
starting function. Starter control relay is con-
trolled by IPDM E/R while communicating
with BCM. IPDM E/R se
nds the starter control
relay statu signal to BCM.
5. BCM BCM controls NISSAN VEHICLE IMMOBI-
LIZER SYSTEM-NATS [NVIS (NATS)] and
VEHICLE SECURITY SYSTEM.
When the ignition switch is turned ON, BCM
performs ID verification between BCM and
ECM. If the ID verification result is OK, ECM
can start engine.
Refer to
BCS-77, "
BODY CONTROL SYS-
TEM : Component Parts Location" for de-
tailed installation location.
6. Clutch interlock switch Clutch interlock switch detects that clutch
pedal is depressed, and then transmits ON/
OFF signal to the BCM.
7. Stop lamp switch Stop lamp switch detects that brake pedal is
depressed, and then transmits ON/OFF sig-
nal to the BCM.
8. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into
the main power window and door lock/unlock
switch.
Door lock and unlock switch transmits door
lock/unlock operation signal to BCM.
Refer to
PWC-6, "
Component Parts Loca-
tion".
9. CVT shift selector (park position switch) Park position switch is integrated into the
CVT shift selector and detects that the selec-
tor lever is in the P (park) position, then trans-
mits ON/OFF signal to the BCM and IPDM E/
R.
Revision: August 2015
2016 Versa Note

cardiagn.com

COMPONENT PARTSSEC-121
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NISSAN VEHICLE IMMOBILIZER SYSTEM-NAT S : CVT Shift Selector (Park Position
Switch)
INFOID:0000000012430443
Park position switch detects that CVT shift selector is in the P (Park) position and then transmits the signal to
BCM and IPDM E/R.
BCM confirms the CVT shift selector position with the following 5 signals:
• P (Park) position signal from CVT shift selector (park position switch)
• P/N position signal from TCM
• P (Park) position signal from IPDM E/R (CAN)
• P/N position signal from IPDM E/R (CAN)
• P/N position signal from TCM (CAN)
IPDM E/R confirms the CVT shift selector position with the following 3 signals:
• P (Park) position signal from CVT shift selector (park position switch)
• P/N position signal from TCM
• P/N position signal from BCM (CAN)
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : BCMINFOID:0000000012430444
BCM controls ENGINE START FUNCTION, NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS (NATS) and
VEHICLE SECURITY SYSTEM.
BCM performs the ID verification between BCM and key. If t he ID verification result is OK, ignition switch oper-
ation is available.
Then, when the power supply position is turned ON, BCM performs ID verification between BCM and ECM. If
the ID verification result is OK, ECM can start engine.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : ECMINFOID:0000000012430445
ECM controls the engine.
When power supply position is turned ON, BCM starts communication with ECM and performs the ID verifica-
tion between BCM and ECM.
If the verification result is OK, the engine can start. If the verification result is invalid, the engine can not start.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : IPDM E/RINFOID:0000000012430446
IPDM E/R has the starter control relay inside. Starter control relay is used for the engine starting function.
IPDM E/R controls this relay while communicating with BCM.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : Combination MeterINFOID:0000000012430447
Combination meter transmits the vehicle speed signal to BCM via CAN communication.
BCM also receives the vehicle speed signal from ABS ac tuator and electric unit (control unit) via CAN commu-
nication. BCM compares both signals to detect the vehicle speed.
10. Front door switch LH Door switch detects door open/close condi-
tion and then transmits ON/OFF signal to
BCM.
11. Rear door switch LH Door switch detects door open/close condi-
tion and then transmits ON/OFF signal to
BCM.
12. Ignition switch Input ignition switch ON/OFF condition to
BCM.
13. NATS antenna amp. ID verification is performed between the BCM
and the transponder integrated into the key
via the NATS antenna amp.
14. Remote keyless entry receiver Remote keyless entry receiver receives but-
ton operation signal and key ID signal then
transmits them to the BCM.
No.
Component Function
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-122
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : Door Switch
INFOID:0000000012430448
Door switch detects door open/close conditi on and then transmits ON/OFF signal to BCM.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NAT S : Remote Keyless Entry Receiver
INFOID:0000000012430449
Remote keyless entry receiver receives each button operation signal and electronic key ID signal from key
and then transmits the signal to BCM.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : Security Indicator Lamp
INFOID:0000000012430450
Security indicator lamp is located on combination meter.
Security indicator lamp blinks when power supply positi on is any position other than ON to warn that NISSAN
VEHICLE IMMOBILIZER SYSTEM-NATS (NATS) is on board.
NISSAN VEHICLE IMMOBILIZER SY STEM-NATS : Starter RelayINFOID:0000000012430451
Engine starting system functions by controlling starter control relay.
Starter control relay is controlled by IPDM E/R on request from BCM.
IPDM E/R transmits starter control relay statu signal to BCM via CAN communication.
NISSAN VEHICLE IMMOBILIZER SY STEM-NATS : Stop Lamp SwitchINFOID:0000000012430452
Stop lamp switch detects that brake pedal is depressed, and then transmits the signal to BCM.
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : Transmission Range Switch
INFOID:0000000012430453
Transmission range switch is integrated in CVT assembly, and detects the CVT shift selector position.
TCM receives the transmission range switch signal and then transmits the P/N position signal to BCM and
IPDM E/R.
BCM confirms the CVT shift selector position with the following 5 signals:
• P (Park) position signal from CVT shift selector (park position switch)
• P/N position signal from TCM
• P (Park) position signal from IPDM E/R (CAN)
• P/N position signal from IPDM E/R (CAN)
• P/N position signal from TCM (CAN)
IPDM E/R confirms the CVT shift sele ctor position with the following 3 signals:
• P (Park) position signal from CVT shift selector (park position switch)
• P/N position signal from TCM
• P/N position signal from BCM (CAN)
Revision: August 2015 2016 Versa Note

cardiagn.com

SYSTEMSEC-123
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
SYSTEM
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS : System DiagramINFOID:0000000012430454
NISSAN VEHICLE IMMOBILIZER SY STEM-NATS : System DescriptionINFOID:0000000012430455
INPUT/OUTPUT SIGNAL CHART
BCM
SYSTEM DESCRIPTION
NATS (Nissan Anti-Theft System) has the following immobilizer functions:
• Engine immobilizer shows high anti-theft performance to prevent engine from starting by anyone other than
the owner.
• Only a key with key ID registered in BCM and ECM can start engine, and shows high anti-theft performance to prevent key from being copied or stolen.
• Security indicator always flashes with mec hanical key removed condition (key switch: OFF)
• Therefore, NATS warns outsider s that the vehicle is equipped with the anti-theft system.
• If system detects malfunction, security indicator illuminates when ignition switch is turned to ON position.
• If the owner requires, ignition key ID or mechanical key ID can be registered for up to 5 keys.
• During trouble diagnosis or when the following parts have been replaced, and if ignition key is added, regis-
tration
*1 is required:
*1: All keys kept by the owner of the vehi cle should be registered with mechanical key.
-ECM
-BCM
- Ignition key
- Remote keyless entry receiver
• NATS trouble diagnosis, system initialization and additional registration of other mechanical key IDs must be
carried out using CONSULT.
• When NATS initialization has been completed, the ID of the inserted mechanical key or mechanical key IDs can be carried out.
• Possible symptom of NATS malfunction is “Engine cannot start”. Identify the possible causes according to
“Work Flow”, Refer to SEC-139, "
Work Flow".
• If ECM other than Genuine NISSAN is installed, the engine cannot be started. For ECM replacement proce- dure, refer to EC-477, "
Removal and Installation".
PRECAUTIONS FOR KEY REGISTRATION
ALKIA2291GB
Switch/Input signal Input signal to BCM BCM function Actuator/Output signal
NATS antenna amp. Key ID
NATS• Security indicator lamp
• Starter request
ECM Engine status signal
Revision: August 2015 2016 Versa Note

cardiagn.com
