2016 NISSAN NOTE engine

SEC-56
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2195 ANTI-SCANNING
B2195 ANTI-SCANNING
DTC LogicINFOID:0000000012430366
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Refer to SEC-56, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430367
1.CHECK SELF DIAGNOSTIC RESULT 1
1. Select “Self Diagnostic Result” of “BCM” using CONSULT.
2. Erase DTC.
3. Perform DTC CONFIRMATION PROCEDURE for DTC B2195. Refer to SEC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> Inspection End.
2.CHECK EQUIPMENT OF THE VEHICLE
Check that unspecified accessory part re lated to engine start is not installed.
Is unspecified accessory part related to engine start installed?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK SELF DIAGNOSTIC RESULT 2
1. Obtain the customers approval to remove unspecified accessory part related to engine start, and then remove it.
2. Select “Self Diagnostic Result” of “BCM” using CONSULT.
3. Erase DTC.
4. Perform DTC CONFIRMATION PROCEDURE for DTC B2195. Refer to SEC-56, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> Inspection End.
4.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2195 ANTI-SCANNING ID verification between BCM and ECM that is
out of the specified specification is detected. ID verification request out of the
specified specification
Revision: August 2015
2016 Versa Note

cardiagn.com

B2196 DONGLE UNITSEC-57
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2196 DONGLE UNIT
DescriptionINFOID:0000000012430368
BCM performs ID verification between BCM and dongle unit.
When verification result is OK, BCM permits cranking.
DTC LogicINFOID:0000000012430369
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Turn ignition switch OFF.
3. Turn ignition switch ON.
4. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is the DTC detected?
YES >> Refer to SEC-57, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430370
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.PERFORM INITIALIZATION
1. Perform initialization of BCM and registration of all mechanical keys using CONSULT. For initialization and registration procedures, refe r to CONSULT Immobilizer mode and follow the on-
screen instructions.
2. Start the engine.
Dose the engine start?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK DONGLE UNIT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and dongle unit connector.
3. Check continuity between BCM harness connector and dongle unit harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2196 DONGLE NG The ID verification results between BCM
and dongle unit is invalid. • Harness or connectors
(Dongle unit circuit is open or shorted.)
• Dongle unit
BCM Dongle unit
Continuity
Connector TerminalConnector Terminal
M97 24M6 1Yes
BCM GroundContinuity
Connector Terminal
M97 24 No
Revision: August 2015 2016 Versa Note

cardiagn.com

B2557 VEHICLE SPEEDSEC-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2557 VEHICLE SPEED
DTC LogicINFOID:0000000012430379
DTC DETECTION LOGIC
NOTE:
• If DTC B2557 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to BCS-63, "
DTC Logic".
• If DTC B2557 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait 10 seconds or more.
2. Drive the vehicle at a vehicle speed of 10 km/h (6.2 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-67, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430380
1.CHECK DTC OF “ABS ACTUATOR A ND ELECTRIC UNIT (CONTROL UNIT)”
Check DTC in “Self Diagnostic Result” of “ABS” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to MWI-24, "DTC Index".
NO >> GO TO 3.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible causes
B2557 VEHICLE SPEED BCM detects one of the following conditions for 10
seconds continuously:
• Vehicle speed signal from “combination meter”
is 10 km/h (6.2 MPH) or more and vehicle
speed signal from “ABS actuator and electric
unit (control unit)” is 4 km/h (2.5 MPH) or less.
• Vehicle speed signal from “combination meter” is 4 km/h (2.5 MPH) or less and vehicle speed
signal from “ABS actuator and electric unit
(control unit)” is 10 km/h (6.2 MPH) or more. • Harness or connectors
(The CAN communication line is
open or shorted.)
• Combination meter
• ABS actuator and electric unit
(control unit)
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000012430383
DTC DETECTION LOGIC
NOTE:
• If DTC B2602 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2602 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive vehicle at a speed of 4 km/h (2.5 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-70, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430384
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Check DTC in “Self Diagnostic Re sult” of “ABS” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” of “METER/M&A” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to MWI-24, "DTC Index".
NO >> GO TO 3.
3.CHECK CVT SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Check voltage between CVT shift selector (park position switch) harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2602 SHIFT P DIAG BCM detects the following status for 10 seconds:
• Selector lever is in the P position.
• Vehicle speed is 4 km/h (2.5 MPH) or more.
• Ignition switch is in the ON position. • Harness or connectors
(The CAN communication line is
open or shorted.)
• Harness or connectors [CVT shift selector (park position
switch) circuit is open or shorted.]
• CVT shift selector (park position switch)
• Combination meter
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-82
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2608 STARTER RELAY
B2608 STARTER RELAY
DTC LogicINFOID:0000000012430395
DTC DETECTION LOGIC
NOTE:
• If DTC B2608 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2608 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
• If DTC B2608 is displayed with other DTC (BCM), first perform the trouble diagnosis for other DTC detected.\
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under t he following conditions to start engine.
- Selector lever: In the P position
- Brake pedal: Depressed
2. Wait 1 second after engine started.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-82, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430396
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF IPDM E/R
Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to PCS-20, "DTCIndex".
NO >> GO TO 2.
2.CHECK STARTER RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2608 STARTER RELAY BCM outputs starter relay OFF signal but
BCM receives starter relay ON signal from
IPDM E/R (CAN). • Harness or connectors
(The CAN communication line is open or
shorted.)
• Harness or connectors (Starter relay circuit is open or shorted.)
•IPDM E/R
• Starter relay
(+)
(–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M98 97 Ground CVT selector lever N or P position Battery voltage
Other than above
0
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B260F ENGINE STATUS
B260F ENGINE STATUS
DescriptionINFOID:0000000012430398
BCM receives the engine status signal from ECM via CAN communication.
DTC LogicINFOID:0000000012430399
DTC DETECTION LOGIC
NOTE:
• If DTC B260F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B260F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait 2 seconds or more.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-84, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430400
1.INSPECTION START
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” of “BCM” using CONSULT.
3. Touch ERASE.
4. Perform DTC CONFIRMATION PROCEDURE for DTC B260F. Refer to SEC-84, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> Inspection End.
2.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”.
Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B260F ECM CAN COMM BCM has not yet received the engine status
signal from ECM when ignition switch is in
the ON position. • Harness or connectors
(The CAN communication line is open
or shorted.)
•ECM
Revision: August 2015 2016 Versa Note

cardiagn.com

B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
NOTE:
• If DTC B261F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B261F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Drive vehicle at a speed of 40 km/h (24.8 MPH) or more for 10 seconds.
3. Decrease the vehicle speed to below 40 km/h (24.8 MPH).
4. Repeat steps 2 and 3 twice (total of 3 times).
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-85, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000012430402
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B261F ASCD CNCL/CLTCH SW
(ASCD clutch interlock
switch) BCM detects the following status for 10 seconds
3 times:
• Clutch interlock switch input: 0 V.
• Vehicle speed: 40 km/h (24.8 MPH) or more. • Harness or connectors.
(CAN communication line is open
or shorted.)
• Harness or connectors. (Clutch interlock switch circuit is
open or shorted)
• Clutch interlock switch
• Combination meter
•BCM
Signal name Fuse No.
Ignition power supply 10 (10 A)
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
B2620 PARK/NEUTRAL POSITION SWITCH
DTC LogicINFOID:0000000012430404
NOTE:
• If DTC B2620 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2620 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Drive vehicle at a speed of 40 km/h (24.8 MPH) or more for 10 seconds.
3. Decrease the vehicle speed to below 40 km/h (24.8 MPH).
4. Repeat steps 2 and 3 twice (total of 3 times).
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-88, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000012430405
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B2620 NEUTRAL SW
(Neutral switch) BCM detects the following status for 10 sec-
onds 3 times:
• Park/neutral position switch input: Battery
voltage
• Vehicle speed: 40 km/h (24.8 MPH) or more. • Harness or connector
(CAN communication line is open
or shorted.)
• Harness or connector (Park/neutral position switch circuit
is open or shorted.)
• Park/neutral position switch
• Combination meter
•BCM
Signal name Fuse No.
Ignition power supply 3 (10 A)
Revision: August 2015 2016 Versa Note

cardiagn.com
