2016 JEEP GRAND CHEROKEE SRT Owners Manual

Page 633 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual 2. To disengage the wiper blade from the wiper arm, flipup the release tab on the wiper blade and while holding the wiper arm with one hand, slide the wiper
blade down towards the base of the wiper ar

Page 634 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual 3. With the wiper blade disengaged, remove the wiperblade from the wiper arm by holding the wiper arm
with one hand and separating the wiper blade from
the wiper arm with the other hand (move the wipe

Page 635 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual Installing The Front Wipers
1. Lift the wiper arm off of the glass, until the wiper armis in the full up position.
2. Position the wiper blade near the hook on the tip of the wiper arm with the wiper

Page 636 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual 2. Lift the rear wiper arm fully off the glass.
Wiper Pivot Cap In Unlocked Position
1 — Wiper Arm Pivot Cap
2—WiperArm
Wiper Blade In Folded Out Position
1—WiperArmPivotCap
2 — Wiper Arm
3

Page 637 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual 3. To remove the wiper blade from the wiper arm, graspthe bottom end of the wiper blade nearest to wiper
arm with your right hand. With your left hand hold
the wiper arm as you pull the wiper blade aw

Page 638 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual Installing The Rear Wiper
1. Lift the rear wiper arm pivot cap away from the glassto allow the rear wiper blade to be raised off of the
glass.
NOTE: The rear wiper arm cannot be fully raised off the
g

Page 639 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
Exhaust System
The

Page 640 of 723

JEEP GRAND CHEROKEE 2016 WK2 / 4.G SRT Owners Manual CAUTION!
•The catalytic converter requires the use of un-
leaded fuel only. Leaded gasoline will destroy the
effectiveness of the catalyst as an emissions control
device and may seriously reduce eng
