2016 JEEP GRAND CHEROKEE SRT Owners Manual

•Battery Voltage
Shows the actual battery voltage.
• Transmission Temperature
Shows the actual transmission temperature.G-Force
When selected, this screen displays all four G-Force
values (two lateral and two longitudinal) as well as
steering angle.
SRT Performance Pages — G-Force
4
UNDERSTANDING YOUR INSTRUMENT PANEL 375

When G-Force is selected, the following features will be
available:
•Lateral G-Force Left and Right
The lateral g-force measures the (sideways) left and right
force of the vehicle.
• Longitudinal G-Force Acceleration and Braking
The longitudinal g-force measures the acceleration and
braking force of the vehicle.
• Peak G-Forces Acceleration and Braking, Left and
Right
This shows the maximum g-forces that have been
achieved since the last reset from the DID. Peak values
are maintained through ignition cycles by the DID until
they are cleared by the driver. •
Vehicle Speed
Vehicle Speed measures the current speed of the vehicle
in either mph or km/h, starting at 0 with no maximum
value.
• Steering Wheel Angle
Steering Wheel Angle utilizes the steering angle sensor to
measure the degree of the steering wheel relative to zero.
The zero degree measurement indicates a steering wheel
straight ahead position. When the steering angle value is
negative, this indicates a turn to the left, and when the
steering angle value is positive, a turn to the right.
376 UNDERSTANDING YOUR INSTRUMENT PANEL

Engine
When selected, this screen displays the following values:
•Vehicle Speed
Shows the actual vehicle speed in mph or (km/h). •
Instantaneous Horsepower/Kilowatts
Shows instantaneous engine power.
• Instantaneous Torque
Shows instantaneous engine torque in Foot Pounds (lb/ft).
•Oil Pressure
Shows actual oil pressure in Pounds per Square Inch
(PSI) or Kilopascals (kPa).
• Gear
Shows the current (or pending) operating transmission
gear of the vehicle.
SRT Performance Pages — Engine
4
UNDERSTANDING YOUR INSTRUMENT PANEL 377

SRT Drive ModesYour SRT vehicle is equipped with a Drive Modes feature
which allows for coordinating the operation of various
vehicle systems depending upon the type of driving
behavior desired. The Drive Modes feature is controlled
through with the Selec-Track switch and may be accessed
by performing any of the following:
•Pushing the SRT button on the Selec-Track switch.
• Pushing the Custom button on the Selec-Track switch.
• Selecting “Drive Modes” from the “Apps” menu.
• Selecting “Drive Modes” from within the Performance
Pages menu.
Drive Modes
378 UNDERSTANDING YOUR INSTRUMENT PANEL

The SRT Drive Modes main screen displays the current
drive mode and real-time status of the vehicle’s perfor-
mance configuration. The selectable Drive Modes are
Track, Sport, Auto, Snow, Tow or Custom. Information
shown will indicate the actual status of each system,
along with a vehicle graphic that displays the active drive
mode status. The color red indicates “Track,” orange
“Sport,” yellow “Street” and blue for “Snow.” These
features will reset to AUTO upon an ignition cycle. If the
system status shown does not match the current drive
mode set up, a message will be displayed indicating
which values are not matching the current mode.
NOTE:Electronic Stability Control (ESC) Full-Off can be
activated by pushing and holding the ESC Off button on
the instrument panel switch bank for five seconds. Listed below are the available Drive Modes:
Track Mode
Drive Modes (Track)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 379

Selecting “Track” with the Selec-Track switch will acti-
vate the configuration for typical track driving. The
Transmission, Stability Control, All-Wheel Drive, Steer-
ing, and Suspension systems are all set to their “Track”
settings highlighted in red. The Paddle Shifters are
enabled.Sport Mode
Drive Modes (Sport)
380 UNDERSTANDING YOUR INSTRUMENT PANEL

Selecting “Sport” with the Selec-Track switch will acti-
vate the configuration for typical enthusiast driving. The
Transmission, Stability Control, All-Wheel Drive, Steer-
ing, and Suspension systems are all set to their “Sport”
settings highlighted in orange. The Paddle Shifters are
enabled.Tow Mode
Drive Modes (Tow)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 381

Selecting “Tow” with the Selec-Track switch will activate
the configuration for towing a trailer. Once in this mode,
trailer sway control is enabled in the ESC system. The
Transmission is set to “Tow” setting highlighted in
purple. Stability Control is set to “Full” highlighted in
blue. All-Wheel Drive is set to “50/50” highlighted in
blue. Steering is set to “Street” highlighted in yellow.
Suspension is set to “Sport” highlighted in orange.Snow Mode
Selecting “Snow” with the Selec-Track switch will acti-
vate snow mode for use on loose traction surfaces. When
in Snow mode (depending on certain operating condi-
tions), the transmission may use second gear (rather than
Drive Mode Snow
382 UNDERSTANDING YOUR INSTRUMENT PANEL
