ARRANGEMENTS FOR DEALING WITH THE VEHICLE AT THE END OF ITS LIFE
Fiat has been committed for many years to safeguarding the environment through the constant improvement of its production
processes and manufacturing products that are increasingly “eco-compatible”. To give customers the best possible service in terms
of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life,
Fiat is offering its customers the opportunity of handing over their vehicle* at the end of its life without incurring any additional costs.
The European Directive sets out that when the vehicle is handed over the last keeper or owner should not incur any expenses as
a result of it having a zero or negative market value. In all European Union countries, until 1st January 2007, only vehicles regis-
tered after 1st July 2002 were collected free of charge, while since 2007 collection has been free of charge irrespective of the year
of registration as long as the vehicle contains its basic components (in particular, the engine and bodywork) and has no additional
waste.
To hand your vehicle over at the end of its life without extra cost, go to one of our Dealerships or Fiat-authorised collection and
scrapping centres. These centres have been carefully chosen to offer high quality service for the collection, treatment and recycling
of unused vehicles with respect to the environment.
You can find further information on these collection and scrapping centres either from a Fiat or Fiat Commercial Vehicle Dealer-
ship or by calling the freephone number 00800 3428 0000 or by going on the Fiat website.
(*) Vehicle for transporting passengers with a maximum of nine seats and a total permitted weight of 3.5 t
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 209

Pagine_ITA.indd418-05-200511:54:19
®
Always ask your mechanic for
®
Pagine_ITA.indd118-05-200511:53:40
In the heart of your engine.
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 210

The engine of your car is factory filled with Selenia.
Oil change? The experts recommend Selenia
This is an engine oil range which satisfies the most advanced
international specifications. Its superior technical characteristics
allow Selenia to guarantee the highest performance
and protection of your engine.
The Selenia range includes a number of technologically advanced products:
SELENIA K PURE ENERGY
Pagine_ITA.indd418-05-200511:54:19
Synthetic lubricant designed for latest generation, low
emission, petrol engines. Its specific formulation warrants
the utmost protection also for high performance
turbocharged engines with high thermal stress.
Its low ash content helps to maintain the total cleanliness
of modern catalysts.
SELENIA WR PURE ENERGY
Fully synthetic lubricant that can meet the requirements of
the latest diesel engines. Low ash content to protect the
particulate filter from the residual products of combustion.
High Fuel Economy System that allows
considerable fuel saving.
It reduces the danger of dirtying the turbine to ensure the
protection of increasingly high performance diesel
enginesSELENIA MULTIPOWER
Particularly ideal for the protection of new generation petrol
engines, very effective even in the most severe weather
conditions. It guarantees a reduction in fuel consumption
(Energy conserving) and it is also ideal for alternative
engines.
SELENIA SPORT
Fully synthetic lubricant capable of meeting the needs of
high performance engines.
Studied to protect the engine also in high thermal stress
conditions, it prevents deposits on the turbine to achieve
the utmost performance in total safety.
The range also includes Selenia StAR Pure Energy, Selenia
Racing, Selenia K, Selenia WR, Selenia 20K, Selenia 20K AR.
For further information on Selenia products visit the web site
www.selenia.com.

Pagine_ITA.indd118-05-200511:53:40
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 211

RIGHT HAND DRIVE VERSION
The presence and the position of the instruments and warning lights may vary according to the versions.
1. Side adjustable air vents - 2.Side fixed air vents - 3.Right steering column stalk: windscreen, rear window wiper and trip com-
puter controls - 4.Instrument panel - 5.Left steering column stalk: external lights - 6.Dashboard controls - 7.Central adjustable air
vents - 8.Upper fixed air vent - 9.Front passenger’s air bag - 10.Glovebox - 11.Sound system (where provided) - 12.Heat-
ing/ventilation/climate controls - 13.Ignition switch - 14.Driver’s air bag - 15.Steering wheel adjusting lever - 16.Control plate:
front fog lights/rear fog lights/headlight aiming device/digital display/multifunction display.
F0M0426mfig. 1
212
RIGHT HAND DRIVE VERSION
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 212

INSTRUMENT PANEL
F0M0539mfig. 2 - with digital display
F0M0540mfig. 3 - with multifunction display
ASpeedometer (speed indicator)
BFuel level gauge with reserve warning light
CEngine coolant temperature gauge and excessive
temperature warning light
DRev counter
EDigital display
ASpeedometer (speed indicator)
BFuel level gauge with reserve warning light
CEngine coolant temperature gauge and excessive
temperature warning light
DRev counter
EMultifunction display
213
RIGHT HAND DRIVE VERSION
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 213

Fiat Group Automobiles S.p.A. – Customer Services – Technical Services – Service Engineering – Largo Senatore G. Agnelli, 5 – 10040 Volvera – Torino (Italia)
Print no. 603.81.761 – 07/2010 – 1 edition
CHANGING ENGINE OIL
1.2 - 1.4 - 1.3 Multijet
Tank capacity45
Reserve5 ÷ 7
Refuel petrol cars only with unleaded petrol with an octane rating (RON) of 95 or higher (EN228 specifications).
Refuel diesel cars only with automotive diesel (EN590 specifications).
REFUELLING (litres)
2.2 2.1
2.2 2.2
2.2 2.0
2.2 2.22.2 2.1
2.2 2.2
2.2 2.0
2.2 2.22.4 2.1
2.5 2.2
2.3 2.1
2.3 2.3
1.2 1.41.3 Multijet
litres kg litres kg litres kg
Engine sump and filter 2.6 2.25 2.6 2.25 3.2 2.75
COLD TYRE INFLATION PRESSURE (bar)
Versions1.2 1.4 1.3 MultijetFront Rear Front Rear Front Rear
175/65 R15 84T
Medium load
Full load
185/65 R15 88T
Medium load
Full load
Add +0.3 bar to the prescribed pressure when the tyres are warm. However, recheck that the value is correct with the tyre cold.
With snow tyres, add +0.2 bar to the pressure recommended for standard tyres.
When running at speeds higher than 160 km/h, inflate tyres at full-load pressures.
205-214 ACTUAL 1ed EN 26-07-2010 16:15 Pagina 214

The data contained in this publication is intended merely as a guide. FIAT reserves the right to modify the models and
versions described in this booklet at any time for technical and commercial reasons.
If you have any further questions please consult your FIAT dealer.
Printed in recycled paper without chlorine.
OWNER HANDBOOK
FIATPUNTO
