2015 TOYOTA TACOMA Owners Manual (in English)

217
2-5. Driving information
2
When driving
Weight limits
● The gross trailer weight must never exceed the TWR described in
the table. ( P. 218, 519)
● The gross combination weight must never exceed the GCWR
described in the table. ( P. 218)
Access Cab models
●The gross vehicle weight must
never exceed the GVWR indi-
cated on the Certification
Label.
● The gross axle weight on each
axle must never exceed the
GAWR indicated on the Certi-
fication Label.
Double Cab models
● If the gross trailer weight is over the unbraked TWR, trailer service
brakes are required.
● If the gross trailer weight is over 2000 lb. (905 kg), a sway control
device with sufficient capacity is required.
● If the gross trailer weight is over 5000 lb. (2265 kg), a weight dis-
tributing hitch with sufficient capacity is required.

218 2-5. Driving information
GCWR, TWR, Unbraked TWR, Fifth wheel and Gooseneck towing TWR
Confirm that the gross trailer weight, gross combination weight, gross
vehicle weight, gross axle weight and tongue weight are all within the
limits.
■GCWR
* and TWR*
Access Cab models
*: These models meet the tow-vehicle trailering requirement of SAE
International per SAE J2807.
Model code*1EngineDriving
systemGCWRTWR
TRN225L- CRMDKA
2.7 L
4-cylinder (2TR-FE) engine 2WD
7440 lb.
(3370 kg)
3500 lb.
(1585 kg)
TRN225L-
CRPDKA 7470 lb.
(3385 kg)
TRN245L- CRMDKA 4WD7860 lb.
(3565 kg)
TRN245L- CRPDKA 7880 lb.
(3570 kg)
TRN265L- CRPDKA 2WD7640 lb.
(3465 kg)
GRN225L- CRFDKA
4.0 L V6
(1GR-FE) engine 7460 lb.
(3380 kg) 3300 lb.
(1495 kg)
GRN245L- CRADKA
4WD7970 lb.
(3615 kg)
*23500 lb.
(1585 kg)
*2
11100 lb.
(5030 kg)
*36500 lb.
(2945 kg)
*3
GRN245L- CRFDKA 7930 lb.
(3595 kg)*23500 lb.
(1585 kg)
*2
11070 lb.
(5020 kg)
*36500 lb.
(2945 kg)
*3
GRN265L- CRADKA 2WD7730 lb.
(3505 kg)*23500 lb.
(1585 kg)
*2
10860 lb.
(4925 kg)
*36500 lb.
(2945 kg)
*3

219
2-5. Driving information
2
When driving
Double Cab models
Model code*1EngineDriving
systemGCWRTWR
TRN225L- PRPDKA 2.7 L
4-cylinder (2TR-FE) engine 2WD7450 lb.
(3375 kg) 3400 lb.
(1540 kg)
TRN265L- PRPDKA 7720 lb.
(3500 kg) 3500 lb.
(1585 kg)
GRN245L- PRADKA
4.0 L V6
(1GR-FE) engine 4WD8050 lb.
(3650 kg)
*23500 lb.
(1585 kg)
*2
11180 lb.
(5070 kg)
*36500 lb.
(2945 kg)
*3
GRN245L- PRFDKA 8020 lb.
(3635 kg)*23500 lb.
(1585 kg)
*2
11160 lb.
(5060 kg)
*36500 lb.
(2945 kg)
*3
GRN250L- PRADKA 8010 lb.
(3630 kg)*23400 lb.
(1540 kg)
*2
10960 lb.
(4970 kg)
*36200 lb.
(2810 kg)
*3

220 2-5. Driving information
*1: The model code is indicated on the Certification Label. (P. 217521)
*2: Without towing package
*3: With towing package
■Unbraked TWR*
1000 lb. (450 kg)
■ Fifth wheel and gooseneck towing TWR
*
Toyota does not recommend fifth wheel and gooseneck towing.
GRN265L-
PRADKA 4.0 L V6
(1GR-FE) engine 2WD7810 lb.
(3540 kg)*23500 lb.
(1585 kg)
*2
10950 lb.
(4965 kg)
*36500 lb.
(2945 kg)
*3
GRN270L- PRADKA 7900 lb.
(3580 kg)*23500 lb.
(1585 kg)
*2
11030 lb.
(5000 kg)
*36500 lb.
(2945 kg)
*3
*: These models meet the tow-vehicle trailering requirement of SAE International per SAE J2807.
Model code*1EngineDriving
systemGCWRTWR

221
2-5. Driving information
2
When driving
Trailer Tongue Weight
● A recommended tongue weight varies in accordance with the types
of trailers or towing as described below.
● To ensure the recommended values shown below, the trailer must
be loaded by referring to the following instructions.
• Tongue Weight
The gross trailer weight should be distributed so that the tongue
weight is 9% to 11%. (Tongue weight /Gross trailer weight x 100
= 9% to 11%)
Gross trailer weight
Tongue weight
If using a weight distributing hitch when towing, return the front
axle to the same weight as before the trailer connection.
If front axle weight cannot be measured directly, measure the
front fender height above th e front axle before connection.
Adjust weight distributing hitch torque until front fender is
returned to the same height as before connection.
The gross trailer weight, gross axle weight and tongue weight
can be measured with platform scales found at a highway
weighing station, building supply company, trucking company,
junk yard, etc.

222 2-5. Driving information
HitchTrailer hitch assemblies have different weight capacities. Toyota rec-
ommends the use of Toyota hitch/brac ket for your vehicle. For details,
contact your Toyota dealer.
● If you wish to install a trailer hitch, contact your Toyota dealer.
● Use only a hitch that c onforms to the gross trailer weight require-
ment of your vehicle.
● Follow the directions supplied by the hitch manufacturer.
● Lubricate the hitch ball with a light coating of grease.
● Remove the trailer hitch whenever you are not towing a trailer.
After removing the hitch, seal any mounting hole in the vehicle
body to prevent entry of any substances into the vehicle.
Bumper towing (vehicles with steel bumper only)
The rear bumper of your vehicle
is equipped with a hole to install
a trailer ball. If you have any
questions, contact your Toyota
dealer.
The gross trailer weight (trailer
weight plus cargo weight) when
towing with the bumper must
never exceed the TWR (
P. 218,
519) or 3500 lb. (1585 kg) which-
ever is lower.

223
2-5. Driving information
2
When driving
Selecting trailer ball
Use the correct trailer ball for your application. Trailer ball load rating
Matches or exceeds the gross
trailer weight rating of the trailer.
Ball diameter
Matches the size of the trailer
coupler. Most couplers are
stamped with the required trailer
ball size.
Shank length
Protrudes beyond the bottom of
the lock washer and nut by at
least 2 threads.
Shank diameter
Matches the ball mount hole
diameter size.
Trailer
classTypical trailer ball
size
IV2 5/16 in.
II and III2 in.
I1 7/8 in.

224 2-5. Driving information
Positions for towing hitch receiver and hitch ballWeight carrying ball position:
56.1 in. (1425 mm)
Hitch receiver pin hole posi-
tion: 44.2 in. (1123 mm)
Connecting trailer lightsVehicles with 7 pin connector Use the wire harness stored in
the rear end under the vehicle
body.
Vehicles without 7 pin connector
Please consult your dealer when installing trailer lights, as incor-
rect installation may cause dama ge to the vehicle’s lights. Please
take care to comply with your st ate’s laws when installing trailer
lights.
