2015 TOYOTA TACOMA Owners Manual (in English)

567
7
For owners
Camper information
Center of gravity locationThe figures given in the illustration indicate the recommended center
of gravity zone. Recommended location for
cargo center of gravity for
cargo weight rating
Rear end of truck bed
*: Truck-campers cannot be used with the X-Runner since it is not
designed for them.
This information has been prepared in accordance with regula-
tion issued by the National Highway Traffic Safety Administration
of the U.S. Department of Transportation. It provides the purchas-
ers and/or prospective purchasers of Toyota vehicles with infor-
mation on truck-camper loading. Your Toyota dealer will help
answer any questions you may have as you read this informa-
tion.
Access Cab models Except X-Runner
X-Runner
*
49.9 in. (1267 mm) — 36.1 in. (917 mm)
—
Double Cab models With short deck
With long deck 45.6 in. (1157 mm)
35.9 in. (911 mm) 31.8 in. (807 mm)
27.8 in. (706 mm)

568
Cargo weight rating and proper matchingWhen the truck is used to carry a slide-in camper, the total cargo load
of the truck consists of the manufacturer’s camper weight figure, the
weight of installed additional camper equipment not included in the
manufacturer’s camper weight figu re, the weight of camper cargo,
and the weight of passengers in the camper.
The total cargo load should not exceed the truck’s cargo weight rating
and the camper’s center of gravity should fall within the truck’s rec-
ommended center of gravity zone when installed.
Camper center of gravity
Recommended center of grav-
ity location zone
CAUTION
■Loading precaution
If a load is too far back, it can cause dangerous handling. If it is too far
forward, the front axle may be overloaded.

569
7
For owners
■Cargo weight rating
Access Cab models
2 people, 2TR-FE engine, 2WD except PreRunner: 750 lb. (340 kg)
4 people, 2TR-FE engine, 2WD except PreRunner:
450 lb. (204 kg)
2 people, 2TR-FE engine, PreRunner: 1000 lb. (453 kg)
4 people, 2TR-FE engine, PreRunner: 700 lb. (317 kg)
2 people, 1GR-FE engine, PreRunner: 950 lb. (430 kg)
4 people, 1GR-FE engine, PreRunner: 650 lb. (294 kg)
2 people, 2TR-FE engine, 4WD: 900 lb. (408 kg)
4 people, 2TR-FE engine, 4WD: 600 lb. (272 kg)
2 people, 1GR-FE engine, 4WD: 840 lb. (381 kg)
4 people, 1GR-FE engine, 4WD: 540 lb. (244 kg)
Double Cab models with short deck
2 people, 2TR-FE engine, 2WD except PreRunner: 650 lb. (294 kg)
5 people, 2TR-FE engine, 2WD except PreRunner:
200 lb. (90 kg)
2 people, 1GR-FE engine, PreRunner: 850 lb. (385 kg)
5 people, 1GR-FE engine, PreRunner: 400 lb. (181 kg)
2 people, 1GR-FE engine, 4WD: 740 lb. (335 kg)
5 people, 1GR-FE engine, 4WD: 290 lb. (131 kg)
Double Cab models with long deck
2 people, 1GR-FE engine, PreRunner: 850 lb. (385 kg)
5 people, 1GR-FE engine, PreRunner: 400 lb. (181 kg)
2 people, 1GR-FE engine, 4WD: 740 lb. (335 kg)
5 people, 1GR-FE engine, 4WD: 290 lb. (131 kg)

570
Gross axle and vehicle weight ratingsSecure loose items to prevent weight shifts that could affect the bal-
ance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual ax le loads should not exceed either
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehicle Weight Rating (GVWR). These
ratings are given on the vehicle cert ification label which is located on
the door latch post on the left side of the vehicle. ( P. 521) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
CAUTION
■Overloading
Be careful — overloading can cause dangerous braking and handling
problems, and can damage your vehicle and its tires.

571
7
For owners
Gross axle weight ratingFront GAWR
Rear GAWR
Gross vehicle weight rating Not exceed GVWR
■ GAWR
GAWR
Front Rear
2WD models
except PreRun-
ner
Vehicles with 2.7L
4-cylinder (2TR-FE)
engine
2380 lb. (1075 kg)
Vehicles with 4.0 L
V6 (1GR-FE) engine
2400 lb. (1085 kg)
2650 lb. (1200 kg)
4WD models and
PreRunner
PreRunner
2755 lb. (1245 kg)
4WD models
2775 lb. (1255 kg)
3110 lb. (1410 kg)

572
■GVWR
2WD models except PreRunner
PreRunner
4WD models
Cab type GVWR
Access Cab Vehicles with 2.7 L 4-cylinder (2TR-FE)
engine
4900 lb. (2220 kg)
Vehicles with 4.0 L V6 (1GR-FE) engine
4700 lb. (2130 kg)
Double Cab 4900 lb. (2220 kg)
Cab type GVWR
Access Cab and
Double Cab Vehicles with 2.7 L 4-cylinder (2TR-FE)
engine
5250 lb. (2380 kg)
Vehicles with 4.0 L V6 (1GR-FE) engine
5400 lb. (2445 kg)
Cab type GVWR
Access Cab Vehicles with 2.7 L 4-cylinder (2TR-FE)
engine
5350 lb. (2425 kg)
Vehicles with 4.0 L V6 (1GR-FE) engine
5500 lb. (2490 kg)
Double Cab 5500 lb. (2490 kg)

Index
573
Abbreviation list ..................... 574
Alphabetical index .................. 576
What to do if... ........................ 585
For vehicles with Entune Audio Plus or Entune Premium
Audio, refer to the “NAVIGATION SYSTEM OWNER’S
MANUAL” for information regarding the multimedia
system.
Multimedia system types: P. 243

574
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONSMEANING
2WDTwo Wheel Drive
4WD Four Wheel Drive ABS Anti-Lock Brake System
ACC Accessory ALR Automatic Locking Retractor
A-TRAC Active Traction Control
AUTO LSD Automatic Limited Slip Differential CRS Child Restraint System
DAC Downhill assist control
ECU Electronic Control Unit
EDR Event Data RecorderELR Emergency Locking Retractor
GAWR Gross Axle Weight Rating
GCWR Gross Combination Weight Rating GVWR Gross Vehicle Weight Rating I/M Emission inspection and maintenance
LATCH Lower Anchors and Tethers for Children LED Light Emitting DiodeLT Light truck
M + S Mud + Snow MMT Methylcy clopentadienyl Manganese Tricarbonyl
MTBE Methyl Tertiary Butyl Ether
OBD On Board Diagnostics
RR DIFF LOCK Rear differential lock RSCA Roll sensing of curtain shield airbag
SRS Supplemental Restraint SystemTIN Tire Identification Number
