2015 TOYOTA CAMRY HYBRID Owners Manual

545
10
For owners
CAMRY_HV_U (OM33A87U)
AVERTISSEMENT
■Modification et mise au rebut des composants du système de coussins
gonflables SRS
Ne mettez pas votre véhicule au rebut et ne procédez à aucune des modifi-
cations suivantes sans consulter votre concessionnaire Toyota. Les cous-
sins gonflables SRS peuvent ne pas fonctionner correctement ou se
déployer (se gonfler) accidentellement, provoquant la mort ou de graves
blessures.
● Installation, dépose, démontage et ré paration des coussins gonflables
SRS
● Réparations, modifications, démontage ou remplacement du volant, du
tableau de bord, de la planche de bord, des sièges ou de leur garnissage,
des montants avant, latéraux et arrière ou des rails latéraux de toit
● Réparations ou modifications des ailes avant, du pare-chocs avant ou des
flancs de l'habitacle
● Installation d'un protège-calandre (pare-buffle, pare-kangourou, etc.), de
chasse-neige, de treuils, ou d'un porte-bagages de toit
● Modifications du système de suspension du véhicule
● Installation d'appareils électroniques tels que les émetteurs/récepteurs
radios mobiles et les lecteurs CD
● Modifications de votre véhicule pour une personne atteinte d'un handicap
physique

546
CAMRY_HV_U (OM33A87U)

547
Index
CAMRY_HV_U (OM33A87U)What to do if...
(Troubleshooting) .................... 548
Alphabetical index ..................... 551
Vehicles with a navigation system or Entune Audio
Plus:
For details of equipment related to the navigation sys-
tem or Entune Audio Plus, such as the audio system,
refer to the “NAVIGATION AND MULTIMEDIA SYS-
TEM OWNER'S MANUAL”.

548
CAMRY_HV_U (OM33A87U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be
made by your Toyota dealer. (P. 107)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( P. 109)
●Is the key battery weak or depleted? (P. 423)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( P. 162)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (P. 124)
●Is the child-protector lock set?
The rear door cannot be opened from in side the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 11 3 )
●The function to prevent the electronic key from being left inside the trunk
will operate and you can open the trunk as usual. Take the key out from the
trunk. ( P. 118)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened
The trunk lid is closed with the electronic key left inside

549What to do if... (Troubleshooting)
CAMRY_HV_U (OM33A87U)
●Did you press the power switch while firmly depressing the brake pedal?
(P. 161)
●Is the shift lever in P? ( P. 163)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 122)
●Is the steering wheel unlocked? (P. 163)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(P. 486)
●Is the 12-volt battery discharged? ( P. 487)
●Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
power switch in ON mode. (P. 484)
●It is locked automatically to prevent theft of the vehicle. ( P. 163)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 140)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or ON mode (the hybrid system is not operating) for a period of
time. (P. 163)
If you think something is wrong
The hybrid system does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the hybrid system
is stopped
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

550What to do if... (Troubleshooting)
CAMRY_HV_U (OM33A87U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 446)
●The brake system warning light is on
Is the parking brake released? (P. 171)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 444, 453)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( P. 453)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 80)
To stop the alarm, turn the power switch to ON mode or start the hybrid
system.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 444, 453.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 471)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 495)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning light turns on or a warning message or indicator
is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

551
CAMRY_HV_U (OM33A87U)
Alphabetical index
Alphabetical index
A/C ............................................ 332Air conditioning filter ............. 421
ABS (Anti-lock Brake System)...... 218Function ................................ 218
Warning light ......................... 445
Air conditioning filter .............. 421
Air conditioning system.................................... 332Air conditioning filter ............. 421
Airbags ....................................... 36
Airbag operating conditions .... 45
Airbag precautions for your child .............................. 39
Airbag warning light .............. 445
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............................. 45
Curtain shield airbag precautions........................... 42
Front passenger occupant classification system............. 49
General airbag precautions .... 39
Locations of airbags................ 36
Modification and
disposal of airbags ............... 44
Side airbag operating conditions ............................. 45
Side airbag precautions .......... 39
Side and curtain shield airbags operating conditions ............. 45
Side and curtain shield airbags precautions........................... 39
SRS airbags............................ 36
Alarm .......................................... 80
Anchor brackets ........................ 60 Antennas
(smart key system) ............... 121
Anti-lock Brake System (ABS) ...................................... 218Function ................................ 218
Warning light......................... 445
Armrest..................................... 358
Assist grips .............................. 358
Audio input
*............................ 253
Audio system
*......................... 250
Antenna ................................ 323
Audio input............................ 253
AUX port/USB port ............... 253
Bluetooth
® audio .................. 296
CD player.............................. 269
iPod ...................................... 274
MP3/WMA disc ..................... 269
Optimal use .......................... 266
Portable music player ........... 282
Radio .................................... 267
Steering wheel audio switch ................................. 252
USB memory ........................ 278
Automatic High Beam ............. 175
Automatic light control system.................................... 172
AUX port
*................................. 253
Auxiliary boxes ........................ 347
A
*: For vehicles with a navigation system or Entune Audio Plus, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.

552Alphabetical index
CAMRY_HV_U (OM33A87U)
Back-up lightsReplacing light bulb .............. 434
Wattage ................................ 506
Battery (12-volt battery) .......... 402 Battery checking ................... 402
If the vehicle has discharged
battery ................................ 487
Preparing and checking before winter....................... 242
Warning message ................. 456
Battery (traction battery)........... 73
Bluetooth
®*
Audio system ........................ 295
Hands-free system
(for cellular phone) ............. 296
Multimedia system ........ 295, 296
Bottle holders .......................... 345
Brake
Fluid ...................................... 504
Parking brake........................ 171
Warning light ......................... 444
Brake assist ............................. 218
Break-in tips ............................ 149
Brightness control Instrument panel light control................................... 89
BSM (Blind Spot Monitor) ....... 231 Blind Spot Monitor function ............................... 234
Rear Cross Traffic Alert
function ............................... 236 Care .................................. 376, 379
Aluminum wheels ................. 377
Exterior ................................. 376
Interior .................................. 379
Seat belts.............................. 380
Cargo capacity......................... 158
CD player
*............................... 269
Chains ...................................... 243
Child restraint system............... 56 Booster seats, definition ......... 57
Booster seats, installation....... 64
Convertible seats, definition ............................... 57
Convertible seats, installation ............................ 63
Front passenger occupant classification system ............ 49
Infant seats, definition............. 57
Infant seats, installation .......... 62
Installing CRS with LATCH anchors ................................ 61
Installing CRS with seat belts...................................... 62
Installing CRS with top tether strap ..................................... 65
BC
