2. Confirming the surrounding conditions, reverse the vehicle.
(Display condition)(Vehicle condition)
3. After your vehicle begins entering the parking space, continue backing up slowly so that
the distance between the vehicle width lines and the sides of the parking space on the
left and right are roughly equal.
4. Continue to adjust the steering wheel until the vehicle width guide lines are parallel to the left and right sides of the parking space.
When Driving
Rear View Monitor
4-105
CX-5_8DR2-EA-14A_Edition1 Page233
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (234,1)
5. Once they are parallel, straighten the wheels and back your vehicle slowly into theparking space. Continue checking the vehicle's surroundings and then stop the vehicle in
the best possible position. (If the parking space has division lines, check whether the
vehicle width guide lines are parallel to them.)
(Display condition) (Vehicle condition)
6. When the shift lever is shifted from R to another shift lever position, the screen returns
to the previous display.
4-106
When Driving
Rear View Monitor
CX-5_8DR2-EA-14A_Edition1 Page234
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (235,1)
NOTE
Because there may be a difference between the displayed image, such as indicated below, and the
actual conditions when parking, always verify the safety at the rear of the vehicle and the
surrounding area directly with your eyes.
lIn the image of the parking space (or garage) displayed below, even though the back end and
distance guide lines appear parallel in the monitor, they may not actually be parallel on the
ground.
lWhen parking in a space with a division line on only one side of the parking space, the division
line and the vehicle width guide line may appear parallel on the monitor, but they may not
actually be parallel on the ground.
When Driving
Rear View Monitor
4-107
CX-5_8DR2-EA-14A_Edition1 Page235
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (236,1)
qVariance Between Actual Road Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Such variance in
distance perspective could lead to an accident. Note the following conditions that may
cause a variance in distance perspective.
When the vehicle is tilted due to the weight of passengers and load
When the vehicle rear is lowered, the object displayed on the screen appears farther than
the actual distance.
VarianceObject
4-108
When Driving
Rear View Monitor
CX-5_8DR2-EA-14A_Edition1 Page236
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (237,1)
When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the
screen appears farther (downgrade: closer) than the actual distance.
Appears
farther than
actual
distanceAppears
closer than
actual
distance
Object at actual
position
Object at actual position
Object on screen
A: Distance between the vehicle and object displayed on the screen.
B: Actual distance between the vehicle and object. Object on screen
When Driving
Rear View Monitor
4-109
CX-5_8DR2-EA-14A_Edition1 Page237
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (238,1)
Three-dimensional object on vehicle rear
Because the distance guide lines are displayed based on a flat surface, the distance to the
three-dimensional object displayed on the screen is different from the actual distance.
A
A
C B
CB
(Actual distance) B>C=A
Sensed distance on screen A>B>C (Screen display)
(Actual condition)
qPicture Quality Adjustment
WARNING
Always adjust the picture quality of the rear view monitor while the vehicle is
stopped:
Do not adjust the picture quality of the rear view monitor while driving the vehicle.
Adjusting the picture quality of the rear view monitor such as brightness, contrast,
color, and tint while driving the vehicle is dangerous as it could distract your
attention from the vehicle operation which could lead to an accident.
Picture quality adjustment can be done while the shift lever is in reverse (R).
There are four settings which can be adjusted including brightness, contrast, color, and tint.
When adjusting, pay sufficient attention to the vehicle surroundings.
1. Press the setup button (
) to display the picture quality adjustment screen.
2. Touch the
andon-screen buttons to change the set value.
Touch the
on-screen button to return to the camera image display.
4-110
When Driving
Rear View Monitor
CX-5_8DR2-EA-14A_Edition1 Page238
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (239,1)
Reset
All of the screen setting values can be reset to their initial settings.
1. Press the setup button (
) to display the picture quality adjustment screen.
2. Touch the
on-screen button.
3. Touch the
on-screen button.
When Driving
Rear View Monitor
4-111
CX-5_8DR2-EA-14A_Edition1 Page239
Thursday, November 21 2013 8:49 AM
Form No.8DR2-EA-14A

Black plate (240,1)
