2015 LEXUS LX570 Owners Manual

1451-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
Front passenger occupant classification system precautions ●
If an adult sits in the front passenger se at, the AIR BAG ON indicator light is illu-
minated. If the AIR BAG OFF indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn cor-
rectly. If the AIR BAG OFF in dicator still remain illumi nated, either ask the pas-
senger to move to the second seat, or if that is not possible, move the front
passenger seat fully rearward.●
When it is unavoidable to install the forw ard-facing child restraint system on the
front passenger seat, install the child restraint syst em on the front passenger seat
in the proper order. (  P. 151)●
Do not modify or remove the front seat. ●
Do not kick the front passeng er seat or subject it to severe impact. Otherwise,
the SRS warning light may come on to indicate a malfunction in the detection sys-
tem. In this case, contact your Lexus dealer immediately. ●
Do not use a seat accessory, such as a cushion or seat cover, that covers the seat
cushion surface. ●
Child restraint systems installed on the se cond seat should not contact the front
seatbacks.

1461-7. Safety information
LX570_OM_OM60L96U_(U) Child restraint systems
Points to remember
Studies have shown that installing a child restraint on a rear seat is much
safer than installing one on the front passenger seat.
● Choose a child restraint system that su its your vehicle and is appropri-
ate to the age and size of the child.
● For installation details, follow the instructions provided with the child
restraint system.
General installation instructions are provided in this manual. (  P. 151)A child restraint system for a small ch ild or baby must itself be properly
restrained on the seat with the LATC H anchors or the lap portion of the
lap/shoulder belt.
The laws of all 50 states of the U. S.A. and Canada now require the use of
child restraint systems.

1471-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) Types of child restraints
Child restraint systems are classified into the following 3 types according
to the age and size of the child:
Rear facing—Infant seat/convertible seat
Forward facing—Convertible seat
Booster seat

1481-7. Safety information
LX570_OM_OM60L96U_(U) ■
When installing the child restraint system on the front passenger seat
■
Selecting an appropriat e child restraint system●
Use a child restraint system appropriate for the child until the child becomes
large enough to properly wear the vehicle’s seat belts. ●
If a child is too large for a child restrain t system, sit the child on a rear seat and
use the vehicle’s seat belt. (  P. 91) When you have to use a child restraint sys-
tem on the front passenger seat, adjust the
following: ●
The seatback to the most upright position●
The seat cushion to the fully rearward and
highest position ●
The seat belt height to the lowest position

1491-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
Using a child restraint system
The use of a child restraint system not suitable for the vehicle may not properly
secure the infant or child, resulting in serious injury or even death. ■
Child restraint precautions ●
For effective protection in automobile accidents and sudden stops, a child must
be properly restrained, using a seat belt or child restraint system depending on
the age and size of the child. Holding a chil d in your arms is not a substitute for a
child restraint system. In an accident, the child can be crushed against the wind-
shield, or between you an d the vehicle’ s interior.●
Lexus strongly urges the use of a proper child restraint system that conforms to
the size of the child, installed on the rear seat. According to accident statistics, the
child is safer when properly restrained in the rear seat than in the front seat. ●
Never install a rear-facing child restraint system on the front passenger seat even
if the AIR BAG OFF indicator light illuminates. In the event of an accident, the
force of the rapid inflation of the front passenger airbag can cause death or seri-
ous injury to the child if the rear-facing child restraint system is installed on the
front passenger seat. ●
A forward-facing child restraint system may be installed on the front passenger
seat only when it is unavoidable. A child restraint system that requires a top tether
strap should not be used in the front pa ssenger seat since there is no top tether
strap anchor for the front pa ssenger seat. Adjust the seat back as upright as possi-
ble and always move the seat as far back as possible even if the AIR BAG OFF
indicator light illuminates, because the fr ont passenger airbag could inflate with
considerable speed and force. Otherwise, the child may be killed or seriously
injured. ●
Do not use the seat belt extender when installing a child restraint system on the
front or rear passenger seat. If installing a child restrain t system with the seat belt
extender connected to the seat belt, the se at belt will not securely hold the child
restraint system, which could cause death or serious injury to the child or other
passengers in the event of a sudden stop, sudden swerve or accident.

1501-7. Safety information
LX570_OM_OM60L96U_(U) CAUTION■
Child restraint precautions ●
Do not allow the child to lean his/her head or any part of his/her body against the
door or the area of the seat, front and rear pillars or roof side rail from which the
side airbags or curtain shield airbags deploy even if the child is seated in the child
restraint system. It is dangerous if the side airbags and curtain shield airbags
inflate, and the impact could cause de ath or serious injury to the child.●
Make sure you have complied with all installation instructions provided by the
child restraint manufacturer and that the system is properly secured. If it is not
secured properly, it may cause death or seri ous injury to the child in the event of a
sudden stop, sudden swerving or accident.■
When children are in the vehicle
Do not allow children to play with the se at belt. If the seat belt becomes twisted
around a child’s neck, it may lead to choking or other serious injuries that could
result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut
the belt. ■
When the child restraint system is not in use ●
Keep the child restraint system properly se cured on the seat even if it is not in
use. Do not store the restraint unsecured in the passenger compartment. ●
If it is necessary to detach the child restraint system, remove it from the vehicle or
store it securely in the luggage compartment. This will prevent it from injuring
passengers in the event of a sudden stop, sudden swerve or accident.

15111-7. Safety information
Before driving
LX570_OM_OM60L96U_(U) Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly
secure the child restraints to the ou tboard second seats using the LATCH
anchors or a seat belt. Attach the to p tether strap when installing a child
restraint.
The lap/shoulder belt can be used if your child restraint system is not com-
patible with the LATCH (Lower Anch ors and Tethers for Children) system.
Child restraint LATCH anchors
LATCH anchors are provided
for the outboard second seats.
(Buttons display ing the location
of the anchors are attached to
the seats.)
Seat belts equipped with a child
restraint locking mechanism
(ALR/ELR belts except driver’s
seat belt)
Anchor bracket (for top tether
strap) Anchor brackets are provided
for all second seats.

1521-7. Safety information
LX570_OM_OM60L96U_(U) Installation with LATCH system
Fold the seatback forward and
then adjust it as upright as possible.
Take off the covers between the
seat cushion and seatback, then
confirm the position of the LATCH
anchors below the symbol in the
seatback.STEP 1
STEP 2
