2015 LEXUS LX570 Owners Manual

1291-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) Your vehicle is equipped with AD VANCED AIRBAGS designed based
on the US motor vehicle safety stan dards (FMVSS208). The airbag sen-
sor assembly (ECU) co ntrols airbag deploy ment based on information
obtained from the sensors etc. shown in the system components diagram
above. This information includes crash severity and occupant informa-
tion. As the airbags deploy, a chemica l reaction in the inflators quickly fills
the airbags with nontoxic gas to help restrain th e motion of the occu-
pants. ■
If the SRS airbag s deploy (inflate)●
Bruising and slight abrasions may result from contact with a deploying (inflat-
ing) SRS airbag. ●
A loud noise and white powder will be emitted. ●
Parts of the airbag module (steering wh eel hub, airbag cover and inflator) as
well as the front seats, second seats, an d parts of the front, center and rear pil-
lars, and roof side rail, may be hot for se veral minutes. The airbag itself may also
be hot. ●
The windshield may crack. ●
For Safety Connect subscribers, if the SRS airbags deploy or in the event of a
severe rear-end collision, the system is designed to send an emergency call to
the response center, notifying them of th e vehicle’s location (without needing to
push the “SOS” button) and an agent will attempt to speak with the occupants
to ascertain the level of emergency and assistance required. If the occupants
are unable to communicate, the agent auto matically treats the call as an emer-
gency and helps to dispatch the necessary emergency services. (  P. 726)

1301-7. Safety information
LX570_OM_OM60L96U_(U) ■
SRS airbag deployment conditions (SRS front airbags) ●
The SRS front airbag will deploy in the event of an impact that exceeds the set
threshold level (the level of force corresponding to an approximately 12 - 18 mph
[20 - 30 km/h] frontal collision with a fix ed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situa-
tions:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which
can move or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which
the front of the vehicle “underrides”, or goes under, the bed of a truck●
Depending on the type of collision, it is possible that only the seat belt preten-
sioners will activate. ●
The SRS front airbags for the front passeng er will not activate if there is not a
passenger sitting in the front passenger seat. However, the front airbags for the
front passenger may deploy if luggage is pu t in the seat, even if the seat is unoc-
cupied.■
SRS airbag deployment conditions (SRS side airbags and SRS curtain shield air-
bags) ●
The SRS side airbags and SRS curtain shield airbags will deploy in the event of
an impact that exceeds the set threshold level (the level of force corresponding
to the impact force produced by an ap proximately 3300 lb. [1500 kg] vehicle
colliding with the vehicle cabin from a direction perpendicular to the vehicle
orientation at an approx imate speed of 12 - 18 mph [20 - 30 km/h]).●
The SRS curtain shield airbags will depl oy in the event of vehicle rollover.

1311-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) ■
Conditions under which the SRS airbags may deploy (inflate), other than a colli-
sion
The SRS front may also deploy if a serious impact occurs to the underside of your
vehicle. Some examples are shown in the illustration.
The SRS curtain shield airbags may also deploy under the situations shown in the
illustration.
■
Types of collisions that may not de ploy the SRS airbag (front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a side or
rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But,
whenever a collision of any type causes sufficient forward deceleration of the vehi-
cle, deployment of the SRS front airbags may occur. ●
Hitting a curb, edge of pavement or hard
surface ●
Falling into or jumping over a deep hole ●
Landing hard or falling
●
The angle of vehicle tip-up is marginal. ●
The vehicle skids and hits curb stone.
●
Collision from the side ●
Collision from the rear ●
Vehicle rollover

1321-7. Safety information
LX570_OM_OM60L96U_(U) ■
Types of collisions that may not deploy the SRS airbag
(side airbags and curtain shield airbags)
The SRS side airbag and curtain shield airb ag may not activate if the vehicle is sub-
jected to a collision from the side at certain angles, or a collision to the side of the
vehicle body other than the passenger compartment.
The SRS side airbags do not generally inflate if the vehicle is involved in a frontal or
rear collision, if it rolls over, or if it is involved in a low-speed side collision.
The SRS curtain shield airbags do not generall y inflate if the vehicle is involved in a
frontal or rear collision, if it pitches end over end, or if it is involved in a low-speed
side collision. ●
Collision from the side to the vehicle body
other than the passenger compartment ●
Collision from the side at an angle
●
Collision from the front ●
Collision from the rear ●
Vehicle rollover
●
Collision from the front ●
Collision from the rear ●
Pitching end over end

1331-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) ■
When to contact your Lexus dealer
In the following cases, the vehicle will require inspection and/or repair.
Contact your Lexus dealer as soon as possible. ●
Any of the SRS airbags have been inflated. ●
The front of the vehicle is damaged or
deformed, or was involved in an accident
that was not severe enough to cause the
SRS front airbags to inflate.
●
A portion of a door is damaged or
deformed, or the vehicle was involved in an
accident that was not severe enough to
cause the SRS side and curtain shield air-
bags to inflate.
●
The pad section of the steering wheel,
dashboard near the front passenger airbag
or lower portion of the instrument panel is
scratched, cracked, or otherwise dam-
aged.
●
The surface of the seats with the side airbag
is scratched, cracked or otherwise dam-
aged.

1341-7. Safety information
LX570_OM_OM60L96U_(U) CAUTION■
SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may caus e death or serious injury.●
The driver and all passengers in the vehicl e must wear their seat belts properly.
The SRS airbags are supplemental device s to be used with the seat belts.●
The SRS driver airbag deploys with considerable force, and can cause death or
serious injury especially if the driver is very close to the airbag. The National
Highway Traffic Safety Administration (“NHTSA”) advises:
Since the risk zone for the dr iver’s airbag is the first 2 - 3 in. (50 - 75 mm) of infla-
tion, placing yourself 10 in. (250 mm) from your driver airbag provides you with a
clear margin of safety. This distance is measured from the center of the steering
wheel to your breastbone. If you sit less than 10 in. (250 mm) away now, you can
change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals
comfortably.
• Slightly recline the back of the seat.
Although vehicle designs vary, many dr ivers can achieve the 10 in. (250 mm)
distance, even with the driver seat all the way forward, simply by reclining the
back of the seat somewhat. If reclining the back of your seat makes it hard to
see the road, raise yourself by using a fi rm, non-slippery cushion, or raise the
seat if your vehicle has that feature.
• If your steering wheel is adjustable, ti lt it downward. This points the airbag
toward your chest instead of your head and neck.
The seat should be adjusted as recomme nded by NHTSA above, while still main-
taining control of the foot pedals, steeri ng wheel, and your view of the instrument
panel controls. ●
The portion of the front, side and rear pil-
lars or roof side rail garnishes (padding)
containing the curtain shield airbags is
inside scratched, cr acked, or otherwise
damaged.

1351-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
SRS airbag precautions
●
The SRS front passenger airbag also deploys with considerable force, and can
cause death or serious injury especially if the front passenger is very close to the
airbag. The front passenger se at should be as far from the airbag as possible with
the seatback adjusted, so the front passenger sits upright.●
Improperly seated and/or restrained in fants and children can be killed or seri-
ously injured by a deploying airbag. An in fant or child who is too small to use a
seat belt should be properly secured using a child restraint system. Lexus
strongly recommends that all infants and children be placed in the rear seats of
the vehicle and properly restrained. The re ar seats are safer for infants and chil-
dren than the front passenger seat. (  P. 146) ●
If the seat belt extender has been con-
nected to the front seat belt buckles but the
seat belt extender has not also been fas-
tened to the latch plate of the seat belt, the
SRS front airbags will judge that the driver
and front passenger are wearing the seat
belt even though the seat belt has not been
connected. In this case, the SRS front air-
bags may not activate correctly in a colli-
sion, resulting in deat h or serious injury in
the event of collision. Be sure to wear the
seat belt with the seat belt extender.

1361-7. Safety information
LX570_OM_OM60L96U_(U) CAUTION■
SRS airbag precautions ●
Do not sit on the edge of the seat or lean
against the dashboard.
●
Do not allow a child to stand in front of the
SRS front passenger airbag unit or sit on
the knees of a front passenger. ●
Do not allow the front seat occupants to
hold items on their knees. ●
Do not lean against the door, the roof side
rail or the front, center and rear pillars.
●
Do not allow anyone to kneel on the pas-
senger seat toward the door or put their
head or hands outside the vehicle.
