2974-5. Using the driving support systems
4
Driving
When the shift position is in any position other than R, the display mode
can be changed in the following procedure.
Press the “MENU” button on the Lexus Display Audio controller, and
then select “Setup” on the screen.
Select “Vehicle”, and then select “Back Camer a Guide Line Setting” on
the screen.
Select the desired display mode.
Estimated course line display
mode ( P. 2 9 8 )
Parking assist guide line dis-
play mode ( P. 300)
Distance guide line display
mode
Distance guide lines only are
displayed.
Switching the display mode
1
2
3
1
2
3

298
ES350_300h_OM_OM33B99U_(U)
4-5. Using the driving support systems
■Screen descriptionVehicle width guide line
The line indicates a guide path when th e vehicle is being backed straight up.
The displayed width is wider than the actual vehicle width.
The line aligns with the estimated course lines when the steering wheel is
straight.
Estimated course lines
The lines show an estimated course when the steering wheel is turned.
Distance guide line
The line moves, together with the estimate d course lines, in sync with the steer-
ing wheel. The line shows points approximately 1.5 ft. (0.5 m) (red) and
approximately 3 ft. (1 m) (yellow) from the center of the edge of the bumper.
Distance guide line
The line shows distance behind the vehicle, a point approximately 1.5 ft. (0.5
m) (blue) from the edge of the bumper.
Vehicle center guide line
The line indicates the estimated vehicle center on the ground.
Estimated course line display mode
1
2
3
4
5

ES350_300h_OM_OM33B99U_(U)
2994-5. Using the driving support systems
4
Driving
■Parking operation
When parking in a space which is in the reverse direction to the space
described in the procedure belo w, the steering directions will be
reversed.
Shift the shift position to R position.
Turn the steering wheel so that
the estimated course lines are
within the parking space, and
back up slowly.Parking space
Estimated course lines
When the rear position of the
vehicle has entered the park-
ing space, turn the steering
wheel so that the vehicle width
guide lines are within the left
and right dividing lines of the
parking space. Vehicle width guide line
1
2
1
2
3
3

300
ES350_300h_OM_OM33B99U_(U)
4-5. Using the driving support systems
Once the vehicle width guide lines and the parking space lines are
parallel, straighten the steering wh eel and back up slowly until the
vehicle has completely en tered the parking space.
Stop the vehicle in an appropriate place, and finish parking.
■Screen description
Vehicle width guide lines
These lines indicate a guide path when the vehicle is being backed
straight up. The displayed width is wider than the actual vehicle
width.
Parking assist guide lines
These lines indicate the pa th of the smallest turn possible behind the
vehicle.
These lines also indicate the ap proximate position of the steering
wheel when parking.
Distance guide line
This line (red) indicates points approximately 1.5 ft. (0.5 m) behind
the rear bumper of your vehicle.
Vehicle center guide line
The line indicates the estimated vehicle center on the ground.
Parking assist guide line display mode
4
5
1
2
3
4

ES350_300h_OM_OM33B99U_(U)
3014-5. Using the driving support systems
4
Driving
■Parking operation
When parking in a space which is in the reverse direction to the space
described in the procedure belo w, the steering directions will be
reversed.
Shift the shift position to R position.
Back up until th e parking assist
guide line meets the edge of
the left-hand dividing line of
the parking space.
Parking assist guide line
Parking space dividing line
Turn the steering wheel all the way to the right, and back up slowly.
Once the vehicle is parallel with th e parking space, straighten the
steering wheel and back up slowly until the vehicle has completely
entered the parking space.
Stop the vehicle in an appropriate place, and finish parking.
1
2
1
2
3
4
5

302
ES350_300h_OM_OM33B99U_(U)
4-5. Using the driving support systems
■Area displayed on screen
The parking assist monitor dis-
plays an image of the view from
the bumper of the rear area of the
vehicle.
The image on the rear view moni-
tor system screen can be
adjusted. (P. 367)
• The area displayed on the screen
may vary according to vehicle ori-
entation conditions.
• Objects which are close to either corner of the bumper or under the
bumper cannot be seen on the
screen.
• The camera uses a special lens. The distance of the image that appears
on the screen differs from the
actual distance.
• Items which are located higher than the camera may not be displayed on the monitor.
• If your vehicle is equipped with a backlit license plate, it may interfere with the
display.
Lexus parking assist monitor precautions
Corners of bumper

ES350_300h_OM_OM33B99U_(U)
3034-5. Using the driving support systems
4
Driving
■Lexus parking assist monitor camera
The camera for the parking assist
monitor is located above the
license plate.
●Using the camera
If the camera lens becomes dirty, it cannot transmit a clear image. If
water droplets, snow or mud adhere to the lens, rinse with water and
wipe with a soft cloth. If the lens is extremely dirty, wash it with a mild
cleanser and rinse.
■Differences between the screen and the actual road
The distance guide lines and the vehi cle width guide lines may not actu-
ally be parallel with the dividing lines of the parking space, even when
they appear to be so. Be sure to check visually.
The distances between the vehicle wi dth guide lines and the left and
right dividing lines of the parking sp ace may not be equal, even when
they appear to be so. Be sure to check visually.
The distance guide lines give a dist ance guide for flat road surfaces. In
any of the following situations, th ere is a margin of error between the
guide lines on the screen and the actual distance/course on the road.

304
ES350_300h_OM_OM33B99U_(U)
4-5. Using the driving support systems
●When the ground behind the vehicle slopes up sharply
The distance guide lines will
appear to be closer to the
vehicle than the actual dis-
tance. Because of this, objects
will appear to be farther away
than they actually are. In the
same way, there will be a mar-
gin of error between the
guidelines and the actual dis-
tance/course on the road.
●When the ground behind the vehicle slopes down sharply
The distance guide lines will
appear to be further from the
vehicle than the actual dis-
tance. Because of this, objects
will appear to be closer than
they actually ar e. In the same
way, there will be a margin of
error between the guidelines
and the actual distance/course
on the road.
