2015.75 VAUXHALL VIVA Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
192 Vehicle Care
2. Pull up the release knob on topof the rear seat backrest
forward.
3. Place the loop end of the strap
from tool box through the seat
back latch.
4. Place the hook end of the strap through the loop and pull it until
the strap is fastened securely
to the seat back latch.
5. Pull back backrests of the rear
seats.
6. Mount the hook to the tailgate latch.
7. Tighten the strap and secure it using the buckle.
Jump Starting
Do not start with quick charger.
A vehicle with a discharged battery
can be started using jump leads and
the battery of another vehicle.
{Warning
Be extremely careful when
starting with jump leads. Any
deviation from the following
instructions can lead to injuries or
damage caused by battery
explosion or damage to the
electrical systems of both
vehicles.
Avoid contact with eyes, skin,
fabrics and painted surfaces. The
fluid contains sulphuric acid which
can cause injuries and damage in
the event of direct contact.
. Never expose the battery to
naked flames or sparks.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 193
.A discharged battery can
already freeze at temperatures
of 0 °C.
Defrost the frozen battery before
connecting jump leads.
. Wear eye protection and
protective clothing when
handling a battery.
. Use a booster battery with the
same voltage (12 volts). Its
capacity (Ah) must not be much
less than that of the discharged
battery.
. Use jump leads with insulated
terminals and a cross section of
at least 16 mm² (25 mm² for
diesel).
. Do not disconnect the
discharged battery from the
vehicle.
. Switch off all unnecessary
electrical consumers.
. Do not lean over the battery
during jump starting.
. Do not allow the terminals of one
lead to touch those of the
other lead. .
The vehicles must not come into
contact with each other during
the jump starting process.
. Apply the parking brake, manual
gearbox in neutral, automatic
transmission in P.
. Open the positive terminal
protection caps of both vehicle
batteries.
Lead connection order :
1. Connect the red lead to the positive terminal of the booster
battery. 2. Connect the other end of the
red lead to the positive terminal
of the discharged battery.
3. Connect the black lead to the negative terminal of the
booster battery.
4. Connect the other end of the black lead to a vehicle
grounding point, such as the
engine block or an engine
mounting bolt. Connect as far
away from the discharged
battery as possible, however at
least 60 cm(24 inches).
Route the leads so that they cannot
catch on rotating parts in the engine
compartment.
To start the engine : 1. Start the engine of the vehicle providing the jump.
2. After 5 minutes, start the other engine. Start attempts should
be made for no longer than
15 seconds at an interval of
1 minute.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
194 Vehicle Care
3. Allow both engines to idle forapprox. 3 minutes with the
leads connected.
4. Switch on electrical consumers (e.g. headlights, heated rear
window) of the vehicle
receiving the jump start.
5. Reverse above sequence exactly when removing leads.Towing the Vehicle
If towing service is not available in
an emergency, your vehicle may be
temporarily towed by a rope secured
to the emergency towing eye.
Disengage cap by using the
screwdriver and remove the cap.
The towing eye is stowed with the
vehicle tools.
See Tools 0177.
Screw in the towing eye as far as it
will go until it stops in a horizontal
position. (Should be contact with
tow nut.)
Attach a tow rope or better still a
tow rod to the towing eye.
The towing eye must only be used
for towing and not for recovering the
vehicle.
Switch on ignition to release
steering column lock and to permit
operation of brake lights, horn and
windscreen wipers.
Transmission in neutral.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 195
Caution
Drive slowly. Do not drive jerkily.
Excessive tractive force can
damage the vehicle.
When the engine is not running,
considerably more force is needed
to brake and steer.
To prevent the entry of exhaust
fumes from the towing vehicle,
switch on the air recirculation and
close the windows.
The vehicle must be towed facing
forward, not faster than 55 mph. In
all other cases and when the
transmission is defective, the front
axle must be raised off the ground.
Seek the assistance of a workshop.
After towing, unscrew the
towing eye.
Insert cap and close cap.
Appearance Care
Exterior Care
Locks
The locks are lubricated at the
factory using a high quality lock
cylinder grease. Use de-icing agent
only when absolutely necessary, as
this has a degreasing effect and
impairs lock function. After using
de-icing agent, have the locks
re-greased by a workshop.
Washing
The paintwork of your vehicle is
exposed to environmental
influences. Wash and wax your
vehicle regularly. When using
automatic vehicle washes, select a
programme that includes waxing.
Bird droppings, dead insects, resin,
pollen and the like should be
cleaned off immediately, as they
contain aggressive constituents
which can cause paint damage.
If using a vehicle wash, comply with
the vehicle wash manufacturer's
instructions. The windscreen wipers and rear window wiper must be
switched off. Lock the vehicle so
that the fuel filler flap cannot be
opened. Remove antenna and
external accessories such as roof
racks etc.
If you wash your vehicle by hand,
make sure that the insides of the
wheel housings are also thoroughly
rinsed out.
Clean edges and folds on opened
doors and the bonnet as well as the
areas they cover.Caution
Always use a cleaning agent with
a pH value of 4 to 9.
Do not use cleaning agents on
hot surfaces.
Have the door hinges of all doors
greased by a workshop.
Do not clean the engine
compartment with a steam-jet or
high-pressure jet cleaner.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
196 Vehicle Care
Thoroughly rinse and leather-off the
vehicle. Rinse leather frequently.
Use separate leathers for painted
and glass surfaces : Remnants of
wax on the windows will impair
vision.
Do not use hard objects to remove
spots of tar. Use tar removal spray
on painted surfaces.
Exterior lights
Headlamp and other lamp covers
are made of plastic.
Do not use any abrasive or caustic
agents, do not use an ice scraper,
and do not clean them dry.
Polishing and waxing
Wax the vehicle regularly (at the
latest when water no longer beads).
Otherwise, the paintwork will
dry out.
Polishing is necessary only if the
paint has become dull or if solid
deposits have become attached
to it.
Paintwork polish with silicone forms
a protective film, making waxing
unnecessary.Plastic body parts must not be
treated with wax or polishing
agents.
Windows and windscreen
wiper blades
Use a soft lint-free cloth or chamois
leather together with window
cleaner and insect remover.
When cleaning the rear window,
make sure the heating element
inside is not damaged.
For mechanical removal of ice, use
a sharp-edged ice scraper. Press
the scraper firmly against the glass
so that no dirt can get under it and
scratch the glass.
Clean smearing wiper blades with a
soft cloth and window cleaner.
Sunroof
Never clean with solvents or
abrasive agents, fuels, aggressive
media (e.g. paint cleaner, acetone
containing solutions etc.), acidic or
highly alkaline media or abrasive
pads. Do not apply wax or polishing
agents to the sunroof.
Wheels and tyres
Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be
treated with the same agents as
the body.
Paintwork damage
Rectify minor paintwork damage
with a touch-up pen before rust
forms. Have more extensive
damage or rust areas repaired by a
workshop.
Underbody
Some areas of the vehicle
underbody have a PVC
undercoating while other critical
areas have a durable protective wax
coating.
After the underbody is washed,
check the underbody and have it
waxed if necessary.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Vehicle Care 197
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Interior Care
Interior and upholstery
Only clean the vehicle interior,
including the instrument panel
fascia and panelling, with a dry cloth
or interior cleaner.
Clean the leather upholstery with
clear water and a soft cloth. In case
of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned
using a soft damp cloth.
If necessary use a weak soap
solution.Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colour-fast. This could cause visible
discolourations, especially on light
coloured upholstery.
Removable stains and
discolourations should be cleaned
as soon as possible. Clean seat
belts with lukewarm water or interior
cleaner.
Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could
damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like Zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior
cleaner if necessary. Do not use any
other agent. Avoid solvents and
petrol in particular. Do not use
high-pressure jet cleaners.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
198 Service and Maintenance
Service and
Maintenance
General Information
Service Information . . . . . . . . . . . 198
Recommended Fluids,
Lubricants, and Parts
Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 200
General Information
Service Information
In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at
the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is
available at the workshop.
Service display
0Service
Display 068.
European service intervals
Maintenance of your vehicle is
required every 16,000 miles or after
1 year, whichever occurs first,
unless otherwise indicated in the
service display.
A shorter service interval can be
valid for severe driving behaviour,
e.g. for taxis and police vehicles. The European service intervals are
valid for the following countries:
Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display
0Service
Display 068.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Service and Maintenance 199
International service intervals
Maintenance of your vehicle is
required every 10,000 miles or after
1 year, whichever occurs first,
unless otherwise indicated in the
service display.
The international service intervals
are valid for the countries which are
not listed in the European service
intervals.
Service display
0Service
Display 068.
Confirmations
Confirmation of service is recorded
in the Service and Warranty
Booklet. The date and mileage is
completed with the stamp and
signature of the servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty
or goodwill claims are to be met,
and is also a benefit when selling
the vehicle.
Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display
0Service
Display 068.
