2014 TOYOTA PRIUS PLUG-IN HYBRID Owners Manual

17
PRIUS PHV_OM_OM47856U_(U)
B
Telephone switches*1, 2 “DISP” button
P. 269Audio remote
control switches
*1, 2
Cruise control switch

Dynamic radar cruise control
switch

P. 310
P. 314
Vehicle-to-vehicle distance button P. 314
Talk switch*1, 2
“TRIP” button P. 269, 275
Climate remote control switches P. 371
: If equipped
*1: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
*2: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”.

18
PRIUS PHV_OM_OM47856U_(U)
C
Clock adjustment buttons P. 277
Charging timer switch P. 90
Power (ignition) switch P. 240
Pictorial indexInstrument panel
Head-up display switches P. 287

19
PRIUS PHV_OM_OM47856U_(U)
Air conditioning system P. 360
Rear window and outside rear view
mirror defoggers switch
P. 377
D
EV/HV mode selection switch
Eco drive mode switch
Power mode switch
P. 37
P. 249
P. 249
Emergency flasher switch P. 526
Shift lever P. 247
P position switch P. 250
: If equipped

20
PRIUS PHV_OM_OM47856U_(U)
Pictorial indexLuggage compartment
Luggage cover P. 406
Luggage compartment light P. 145
Auxiliary box P. 405
Cargo hooks P. 405
Auxiliary box P. 405

21
PRIUS PHV_OM_OM47856U_(U)

22
PRIUS PHV_OM_OM47856U_(U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the hybrid system
Approximately five hours after the hybrid system is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound
of a fuel evaporation leakage check and, it does not indicate a malfunct\
ion.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.

23
PRIUS PHV_OM_OM47856U_(U)
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline pow-
ered vehicles or home electronic appliances despite of their electromagnetic
shielding.
Unwanted noise may occur in the reception of the mobile two-way radio.

24
PRIUS PHV_OM_OM47856U_(U)
Vehicle data recordings
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
• Hybrid battery (traction battery) status
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
● Usage of data collected through Safety Connect (U.S. mainland only)
If your Toyota has Safety Connect and if you have subscribed to those ser-
vices, please refer to the Safety Connect Telematics Subscription Service
Agreement for information on data collected and its usage.
