2014 NISSAN TEANA sensor

B2581, B2582 INTAKE SENSORHAC-65
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
3. Check resistance between intake sensor terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace intake sensor. Refer to HAC-106, "Removal and Installation"
.
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12 −
15 (5) 17.73
− 10 (14) 13.46
− 5 (23) 10.33
0 (32) 8.00
5 (41) 6.25
10 (50) 4.93
15 (59) 3.92
20 (68) 3.14
25 (77) 2.54
30 (86) 2.06
35 (95) 1.69
40 (104) 1.39 45 (113) 1.15
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-66
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
B2630, B2631 SUNLOAD SENSOR
DTC LogicINFOID:0000000009463136
DTC DETECTION LOGIC
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT
1. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC No. is displayed in the self-diagnosis results.
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
Is DTC No.
“B2630” or “B2631” displayed?
YES >> Perform trouble diagnosis for the sunload sensor. Refer to HAC-66, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463137
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK SUNLOAD SENSOR POWER SUPPLY
1. Disconnect sunload sensor connector.
2. Turn ignition switch ON.
3. Check voltage between sunload sensor harness connector M56 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK CONTINUITY BETWEEN SUNL OAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
DTC Items
(CONSULT screen terms) Diagnostic item is detected when... Possible cause
B2630 SUNLOAD SEN (SHORT) Detected calorie at sunload sensor 1395 w/m
2
(1200 kcal/m2·h) or more • Sunload sensor
• A/C auto amp.
• Harness and connector
(Sunload sensor circuit is open, or
there is a short in the circuit)
B2631 SUNLOAD SEN (OPEN)
Detected calorie at sunload sensor 0 w/m
2
(0 kcal/m2·h)
+
−Voltage
(Approx.)
Sunload sensor
Connector Terminal M56 1 Ground 5 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

B2630, B2631 SUNLOAD SENSORHAC-67
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
3. Check continuity between sunload sensor harness connector M56 terminal 2 and A/C auto amp. harness
connector M152 terminal 26.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK SUNLOAD SENSOR
1. Reconnect sunload sensor connector and A/C auto amp. connector.
2. Check sunload sensor. Refer to HAC-67, "Component Inspection"
.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Replace sunload sensor. Refer to HAC-105, "Removal and Installation"
.
4.CHECK CONTINUITY BETWEEN SUNLOAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harness connector M56 terminal 1 and A/C auto amp. harness
connector M152 terminal 9.
4. Check continuity between sunload sensor harness connector M56 terminal 1 and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000009463138
1.CHECK SUNLOAD SENSOR
1. Turn ignition switch ON.
2. Check voltage between A/C auto amp. harness connector and ground.
Sunload sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M56 2 M152 26 Yes
Sunload sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M56 1 M152 9 Yes
Sunload sensor —Continuity
Connector Terminal
M56 1 Ground No
(+) ( −)
A/C auto amp. —
Connector Terminal
M56 9 Ground
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-68
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
NOTE:
Select a place in direct sunl ight when checking sunload sensor.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace sunload sensor. Refer to HAC-105, "Removal and Installation"
.
AWIIA1189GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

HAC-94
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
HEATER AND AIR CONDITIONING
SYSTEM CONTROL SYMPTOMS
SYMPTOM DIAGNOSIS
HEATER AND AIR CONDITIONING SYSTEM CONTROL SYMPTOMS
Diagnosis Chart By SymptomINFOID:0000000009463166
NOTE:
Perform the self-diagnoses with CONSULT before perfo rming the symptom diagnosis. If DTC is detected, per-
form the corresponding diagnosis.
Symptom Corresponding malfunction part Reference
• Air conditioning does not activate.
• Air conditioning cannot be controlled.
• Operation status of air conditioning is not indicated on display. • A/C auto amp. ignition power supply
circuit
• Front A/C control (A/C auto amp.) HAC-78, "A/C AUTO AMP. : Diag-
nosis Procedure"
• Air outlet does not change.
• Mode door motor does not operate normally. • Circuit between mode door motor
and A/C auto amp.
• Mode door motor control linkage
• Mode door motor
• A/C auto amp. HAC-80, "MODE DOOR MOTOR :
Diagnosis Procedure"
• Discharge air temperature of driver side does not
change.
• Air mix door motor LH does not operate normally. • Circuit between air mix door motor
LH and A/C auto amp.
• Air mix door motor LH installation condition
• Air mix door motor LH
• A/C auto amp. HAC-78, "AIR MIX DOOR MOTOR
(DRIVER SIDE) : Diagnosis Proce-
dure"
• Discharge air temperature of passenger side does
not change.
• Air mix door motor RH does not operate normally. • Circuit between air mix door motor
RH and A/C auto amp.
• Air mix door motor RH installation condition
• Air mix door motor RH
• A/C auto amp. HAC-79, "AIR MIX DOOR MOTOR
(PASSENGER SIDE) : Diagnosis
Procedure"
• Intake door does not change.
• Intake door motor does not operate normally. • Circuit between intake door motor
and A/C auto amp.
• Intake door motor control linkage
• Intake door motor
• A/C auto amp. HAC-81, "INTAKE DOOR MOTOR :
Diagnosis Procedure"
All door motors do not operate normally.
• Each door motor power supply and
ground circuit
• A/C auto amp. HAC-89, "Diagnosis Procedure"
Blower motor operation is malfunctioning. • Power supply system of front blower
motor
• Circuit between front blower motor
and A/C auto amp.
• Front blower motor
• A/C auto amp. HAC-84, "Diagnosis Procedure"
Compressor does not operate. • Circuit between magnet clutch and
IPDM E/R
• Magnet clutch
• IPDM E/R (A/C relay)
• Circuit between ECM and refriger- ant pressure sensor
• Refrigerant pressure sensor
• CAN communication circuit
• A/C auto amp. HAC-87, "Diagnosis Procedure"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

COMPRESSOR DOES NOT OPERATEHAC-99
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
COMPRESSOR DOES NOT OPERATE
DescriptionINFOID:0000000009463171
Symptom: Compressor does not operate.
Diagnosis ProcedureINFOID:0000000009463172
NOTE:
• Perform self-diagnoses with CONSULT before perform ing symptom diagnosis. If DTC is detected, perform
the corresponding diagnosis.
• Check that refrigerant system is properly charged. If refrigerant amount is below the proper amount, perform
inspection of refrigerant leakage.
1.CHECK MAGNET CLUTCH OPERATION
Check magnet clutch. Refer to HAC-87, "Component Function Check"
.
Does it operate normally?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK REFRIGERANT PRESSURE SENSOR
Check refrigerant pressure sensor. Refer to EC-523, "Component Function Check"
(QR25DE) or EC-979,
"Component Function Check" (VQ35DE).
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK A/C AUTO AMP. OUTPUT SIGNAL
With CONSULT
Check “COMP REQ SIG” and “FAN REQ SIG” in “D ATA MONITOR” mode of “HVAC” using CONSULT.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace A/C auto amp. Refer to HAC-102, "Removal and Installation"
.
4.CHECK ECM INPUT SIGNAL
With CONSULT
Check “AIR COND SIG” and “HEATER FAN SW” in “DATA MONITOR” mode of “ECM” using CONSULT.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Check CAN communication system. Refer to LAN-18, "Trouble Diagnosis Flow Chart"
.
5.CHECK IPDM E/R INPUT SIGNAL
With CONSULT
Monitor item Condition Status
COMP REQ SIG A/C switch ON On
OFF Off
FAN REQ SIG Blower motor ON On
OFF Off
Monitor item Condition Status
AIR COND SIG A/C switch ON On
OFF Off
HEATER FAN SW Blower motor ON On
OFF Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

AMBIENT SENSORHAC-103
< REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000009463176
REMOVAL
1. Remove the core support cover clips (A), then remove the core support cover (1).
