2014 CITROEN DS3 CABRIO Handbook (in English)

95
Access
Do not throw the remote control batteries away, they contain metalswhich are harmful to the environment.
Take them to an approved collectionpoint.
Lost keys

Go to a CITROËN dealer with the vehicle's registration document, your personalidentification documents and if possible the key code label.
The CITROËN dealer will be able to look up the key code and the transponder coderequired to order a new key.


Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised.
No remote control can operate when the key is in the ignition switch, even when the ignition is switched off, except for reinitialisation.


Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more difficult in an emergency. As a safety precaution, never leave children alone in the vehicle, except for a very short period.
In all cases, it is essential to remove the key from the ignition switch when leaving the vehicle.


Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this couldcause malfunctions.


When purchasing a second-hand vehicle

Have the pairing of all of the keys in your possession checked by a CITROËN dealer, to ensure that only your keys can be used to open and star t the vehicle.

Alarm System which protects and provides a deterrent against the theft of your vehicle. It provides two types of protection, exterior and interior, as well as aself-protection function.
Exterior perimeter
protection
The system detects opening of the vehicle.
The alarm is triggered if anyone tries to enter
the vehicle by forcing a door, the boot or the bonnet.

Interior volumetric
protection

The system detects any variation in the volume
in the passenger compartment.
The alarm is triggered if anyone breaks a
window or moves inside the vehicle.
If you wish to leave a pet in the vehicle or a
window partially open, deactivate the interior
volumetric protection.

Self-protection function

The system detects the putting out of ser vice of its components.
The alarm is triggered if anyone tries to put
the wires of the siren, the central control or the
battery out of ser vice.
Do not make any modifications to the alarmsystem, this could cause malfunctions.

Access

Locking the vehicle with full
alarm

Activation
)Switch off the ignition and get out of the
vehicle.)Lock or deadlock the vehicle using the
locking button on the remote control.
The alarm is activated; the indicator lamp in
button Aflashes once per second.
If an opening - door or boot - is notclosed fully, the vehicle is not locked,but the exterior perimeter protection will be activated after 45 seconds atthe same time as the interior volumetricprotection.

Deactivation
)
Unlock the vehicle using the unlockingbutton on the remote control.
The alarm is deactivated; the indicator lamp in button Agoes off.
The exterior perimeter protection is activated, 5 seconds after the locking button on theremote control is pressed.
The interior volumetric protection is activated,
45 seconds after the locking button on the remote control is pressed.

Locking the vehicle
with exterior
perimeter
protection only
To be effective, this deactivation mustbe carried out each time the ignition is switched off.

If the indicator lamp in button Aflashes rapidly, this indicates that the alarmwas triggered during your absence. When the ignition is switched on, thisflashing stops immediately.
To a v o i d t r iggering the alarm when washing your vehicle, lock it using the key in the driver's door lock.
Deactivation of the interior volumetric protection
)Switch off the ignition.)Within ten seconds, press button Auntil
the indicator lamp is on continuously.
)Get out of the vehicle.)Lock or deadlock the vehicle without delay using the locking button on the remote control.
The exterior perimeter protection alone remains
activated; the indicator lamp in button A flashes
once per second.

Reactivation of the interior volumetric protection
)
Unlock the vehicle using the unlockingbutton on the remote control. )
Relock the vehicle using the remotecontrol.
The alarm is activated again with both types
of protection; the indicator lamp in button A
flashes once per second.



Tr iggering of the alarm


This is indicated by sounding of the siren
and flashing of the direction indicators for
approximately thirty seconds.
After it has been triggered, both types of protection are again operational.
If the alarm is triggered ten times in succession, the eleventh time will result in it
becoming inactive.

99Access

Failure of the remote control
)Unlock the vehicle using the key in thedriver's door lock. )Open the door; the alarm is triggered.)Switch on the ignition; the alarm stops.
Locking the vehicle without
activating the alarm
)
Lock or deadlock the vehicle using the keyin the driver's or passenger's door lock.
Malfunction
When the ignition is switched on, illumination of
the indicator lamp in button Afor ten seconds indicates malfunction with the siren.
Have it checked by a CITROËN dealer or a
qualified workshop.

*
Accordin
g to country.


Automatic activation *



2 minutes after the last door or the boot is closed, the alarm is activated automatically. )
To avoid triggering the alarm on enteringthe vehicle, first press the unlocking button on the remote control.

1.Driver's electric window switch.2.Passenger's electric window switch.














Window controls System which opens or closes a window manually or automatically. It is fitted with anti-pinch protection on the driver's side.
The electric window switches remainoperational for approximately45 seconds after the ignition isswitched off or until a door is opened.If, during this period of 45 seconds, youopen a door while operating a window, the window stops. The window switch will then only be operative after the ignition is switched on again.
)Press or pull the switch. The
window stops as soon as the
switch is released.



Passenger's electric
window
There are two methods of operation:

Driver's electric window
-manual mode)Press or pull the switch without passing
the point of resistance. The window
stops as soon as the switch is released.

-
automatic mode
)Press or pull the switch fully. The window
opens or closes completely when theswitch is released. )Pressing or pulling the switch again
stops the movement of the window.

101Access
In the event of unwanted opening of the window on closing (for example in the presence of frost): )
press the switch beyond the pointof resistance and release it; thewindow opens completely, )
then immediately pull the switchwithout going beyond the point of resistance until the window closesfully,)
continue to hold the switch for approximately one second after thewindow has closed. The safety anti-pinch function is not active during these operations.


Safety anti-pinch
On the driver's side, the one-touch front electric
window has a safety anti-pinch function.
When the window rises and meets an obstacle,
it stops and partially lowers again.
Reinitialisation
Always remove the key from the ignition when leaving the vehicle, even for a short time.
In the event of contact during operationof the windows, reverse the movement of the window. To do this, press thecorresponding switch.
When the driver operates thepassenger electric window switch, they should ensure that no one is preventing correct closing of the window.
The driver should ensure that thepassenger uses the electric windowcorrectly.
Be aware of children when operatingthe windows. In the event of a malfunction
you have to
reinitialise the operation of the electricwindows: ) release the switch and pull it again until the
window closes completely,) hold the switch for approximately
one second after closing, ) press the switch to lower the window
automatically.The safety anti-pinch function is not activeduring these operations.

Doors
Opening
From out side
)After unlocking the vehicle using theremote control or the key, pull the door handle.



From inside
)
Pull the door lever to open the door; thisunlocks this vehicle completely.




Closing

When a door is not closed correctly:
-when the engine is running , this
warning lamp comes on, accompaniedby a message in the multifunction screen for a few seconds,
-when the vehicle is moving(speedhigher than 6 mph (10 km/h)), this warning
lamp comes on, accompanied by anaudible signal and a message in the multifunction screen for a few seconds.

Version with deadlocking

The interior door controls donot operate when the vehicle is deadlocked.
