2014 CITROEN DS3 CABRIO Handbook (in English)

19Te c h n i c a l d a t a


WEIGHTS AND TOWED LOADS (in kg)



Petrol engines


VTi 82



VTi 120



THP 155


THP 150 *



Gearboxes


Manual



Manual



Auto

matic



Manual



Model codes:
SB...


HMZ0



5FS0



5FS9



5FV8


5FN8 *




- Unladen weight
1 032
1 088
1 133
1 156


- Kerb weight
1 107
1 163
1 208
1 231


- Gross vehicle weight (GV W)
1 532
1 575
1 610
1 619


- Gross train weight (GTW)
on a 12 % gradient
2 332
2 475
2 510
2 519


- Braked trailer (within the GTW limit)
on a 12 % gradient
800
900
900
900


- Braked trailer ** (with load transfer within the
GTW limit)
1 100
1 150
1 150
1 150


- Unbraked trailer
520
570
570
570


- Recommended nose weight
46
46
46
46

* For Belgium.

**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

20Te c h n i c a l d a t a

MODELS:



ENGINES AND GEARBOXES



Model codes:
SB...


9HP0/S



9HP8/PS



DIESEL ENGINES



e-

HDi 90 PEF


Cubic capacity (cc)

1 560
Bore x stroke (mm)

75 x 88.3
Max power: EU standard (kW)
68
Max power engine speed (rpm)
4 000
Max torque: EU standard (Nm)
230
Max torque engine speed (rpm)
1 750
Fuel

Diesel
Catalytic conver ter

yes
Particle emissions filter (PEF)
yes

GEARBOX

Manual
(5-speed)
Electronic gearbox system
(6-speed)

OIL CAPACITIES (in litres)


Engine (with filter replacement)
3.75

.../S:
e-HDi model fitted with Stop & Start

21Te c h n i c a l d a t a


WEIGHTS AND TOWED LOADS (in kg)



Diesel engines



e- HDi 90 PEF



Gearbox


Manual

(5 - speed)



Electronic gearbox system
(6- speed)



Model codes:
SB...


9HP0/S



9HP8/PS




- Unladen weight
1 085
1 090


- Kerb weight
1 160
1 165


- Gross vehicle weight (GV W)
1 625
1 639


- Gross train weight (GTW)
on a 12 % gradient
2 525
2 539


- Braked trailer (within GTW limit)
on 12 % gradient
900
900


- Braked trailer * (with load transfer
with the GTW limit)
1 150
1 150


- Unbraked trailer
570
570


- Recommended nose weight
46
46
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
*
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

22Te c h n i c a l d a t a





Dimensions (in mm)

4Dconcept
Diadeis
Edipro
This handbook describes all of the equipment
available in the whole range.
Your vehicle will be fi tted with some of this
equipment described in this document, depending
on its trim level, version and the specifi cation for the
country in which it is sold.
The descriptions and illustrations are given without
any obligation. Automobiles CITROËN reserves
the right to modify the technical specifi cations,
equipment and accessories without having to update
this edition of the handbook.
This document is an integral part of your vehicle. It
should be passed on to the new user in the event of
sale or transfer. Automobiles CITROËN declares, by application of
the provisions of the European regulation (Directive
2000/53) relating to End of Life Vehicles, that it
achieves the objectives set by this regulation and
that recycled materials are used in the manufacture
of the products that it sells.
Reproduction or translation of all or part of this
handbook is prohibited without written authorisation
from Automobiles CITROËN.
Printed in the EU
Anglais
03-13


For any work on your vehicle, use a qualifi ed
workshop that has the technical information,
competence and equipment required, which a
CITROËN dealer is able to provide.
