2013 MITSUBISHI iMiEV Owner's Manual (in English)

Model name Condition
USB memory device Storage capacity of 256
Mbytes or more
iPod touch *
F/W Ver.1.1.1 or later
iPod classic *
F/W Ver.1.0 or later
iPod (fifth generation) *
F/W Ver.1.2.2 or later
iPod nano (fifth genera-
tion) *
F/W Ver.1.2 or later
iPod nano (second gen-
eration) *
F/W Ver.1.1.2 or later
Models other than USB
memory devices and
iPods Digital audio player sup-
porting
mass storage
class
* :
“iPod touch,” “iPod classic,” “iPod” and “iPod
nano” are registered trademarks of Apple Inc. in
the United States and other countries. NOTE
l Depending

on the type of the USB memory
device or other device connected, the connec-
ted device may not function properly or the
available functions may be limited.
l Use the iPod whose firmware has been upda-
ted to the latest version.
l You can charge your iPod by connecting it to
the USB input terminal when the electric mo-
tor switch is in the “ACC” or “ON” position.
l Do not keep your USB memory device or
iPod in your vehicle.
l It is recommended that you back up files in
case of data damage. l
Do
not connect to the USB input terminal
any device (hard disk, card reader, memory
reader, etc.) other than the connectable devi-
ces specified in the previous section. The de-
vice and/or data may be damaged. If any of
these devices was connected by mistake, re-
move it after turning the electric motor
switch to the “LOCK” position.
File specifications E00762400017
You can play music files of the following specifica-
tions

that are saved in a USB memory device or oth-
er device supporting mass storage class. Item Condition
File format MP3, WMA, AAC,
WAV
Maximum number of
levels
(including the
root) Level 8
Number of folders 700
Number of files 65,535 Sun visors
E00711201209 1- To eliminate front glare
2-

To eliminate side glare
Vanity mirror E00731900247
A vanity mirror is fitted to the back of the sun visor. For pleasant driving
6-35 6
OHAE13E1

Card holder
E00732000232
Cards
can be slipped into the holder (A) on the
back of the sun visor. Accessory socket
E00711601388
To
use a plug-in type accessory, open the lid, and
insert the plug in the accessory socket.
The accessory socket can be used while the electric
motor switch is in the “ON” or “ACC” position. CAUTION
l
Be
sure to use a “plug-in” type accessory
operating at 12 V and at 120 W or less. CAUTION
l
Long
use of the electric appliance when
the ready indicator is not illuminated
may run down the auxiliary battery.
l When the accessory socket is not in use,
be sure to close the lid, because the socket
might become clogged by foreign materi-
al and be short-circuited. For pleasant driving
6-36
6
OHAE13E1

Interior lamps
E007120012201- Room lamp (rear)
2-
Map & room lamps (front)
NOTE l If you leave the lamps on when the ready in-
dicator is not illuminated, you will run down
the auxiliary battery.
Before you leave the vehicle, make sure that
the lamps are turned off. Map & room lamps (front)
E00717300609
Room lamp 1- (DOOR)
lThe

lamp illuminates when a door or the
tailgate is opened. It goes off about 15 sec-
onds after the door or tailgate is closed
(delayed off function).
However, the lamp goes off immediately
in the following cases: • When the electric motor switch isturned to the “ON” position.
• When the central door lock function is used to lock the vehicle.
• When the remote control switch of the keyless entry system is used to
lock the vehicle.
l If the lamp is left switched on with the
electric motor switch in the “LOCK” or
“ACC” position and a door or the tailgate
is opened, it goes off automatically after
approximately 30 minutes.
The lamp will illuminate again after it au-
tomatically goes off in the following cases: • When
the electric motor switch is
turned to the “ON” position.
• When the remote control switch of the keyless entry system is operated.
• When any of the doors or the tailgate is opened after all doors and the tail-
gate are closed.
NOTE l When the key is removed while the doors
and tailgate are closed, the lamp is illumina-
ted and after about 15 seconds it goes off.
l The time until the lamp goes off (delayed
off) can be adjusted. For details, please con-
sult a MITSUBISHI MOTORS Authorized
Service Point.
l The auto cut-out function can be deactivated.
For details, please consult a MITSUBISHI
MOTORS Authorized Service Point.
2- The lamp stays off regardless of whether the
doors and tailgate are open or closed. For pleasant driving
6-37 6
OHAE13E1

Map lamps
E00765200058
Regardless
of the position of the room lamp
switch, when the lens is pressed, the lamp on the
side that was pressed will illuminate. Press the lens
again to turn off the lamp. Room lamp (rear)
E007123003851- (ON)
The
lamp illuminates regardless of whether
the doors and tailgate are open or closed.
2- (•)
lThe

lamp illuminates when a door or the
tailgate is opened. It goes off about 15 sec-
onds after the door or tailgate is closed
(delayed off function).
However, the lamp goes off immediately
in the following cases: • When the electric motor switch isturned to the “ON” position.
• When the central door lock function is used to lock the vehicle.
• When the remote control switch of the keyless entry system is used to
lock the vehicle.

l If the lamp is left switched on with the
electric motor switch in the “LOCK” or
“ACC” position and a door or the tailgate
is opened, it goes off automatically after
approximately 30 minutes.
The lamp will illuminate again after it au-
tomatically goes off in the following cases:
• When the electric motor switch isturned to the “ON” position.
• When the remote control switch of the keyless entry system is operated.
• When any of the doors or the tailgate is opened after all doors and the tail-
gate are closed.
NOTE l When the key is removed while the doors
and tailgate are closed, the lamp is illumina-
ted and after about 15 seconds it goes off.
l The time until the lamp goes off (delayed
off) can be adjusted. For details, please con-
sult a MITSUBISHI MOTORS Authorized
Service Point. l
The auto cut-out function cannot be operated
when the room lamp switch is in the “ON”
position.
Also, this function can be deactivated. For de-
tails, please consult a MITSUBISHI
MOTORS Authorized Service Point.
3- (OFF) The lamp goes off regardless of whether the
doors and tailgate are open or closed. For pleasant driving
6-38
6
OHAE13E1

Storage spaces
E00713101752CAUTION
l
Never leave lighters, cans of carbonated
drink, and spectacles in the cabin when
parking the vehicle in hot sunshine. The
cabin will become extremely hot, so light-
ers and other flammable items may catch
fire and unopened drink cans (including
soft drink or beer cans) may rupture. Al-
so, spectacles with plastic lenses or mate-
rials could deform or crack.
l Keep the lids of storage spaces closed
while driving the vehicle. A lid or the con-
tents of a storage space could otherwise
cause injuries.
NOTE l When

leaving your vehicle, do not leave val-
uables in the storage spaces. 1- Secret box (RHD vehicles only)
2-

Glove box Glove box
E00726200242
To open, pull the lever (A). Card holder
E00765500019
There is a card holder inside the glove box. Secret box (RHD vehicles only)
E00724900056
The secret box is located on the upper part of the
glove box.
To use the box, open the lid. For pleasant driving
6-39 6
OHAE13E1

Cup holder
E00714500974CAUTION
l
Do not drink beverages while driving.
This is distracting and could cause an ac-
cident.
l Beverages can be spilled owing to vibra-
tion or other movement during vehicle op-
eration. Be careful not to get scalded by a
hot beverage if it is spilled.
LHD vehicles
Type 1
The

cup holder is located behind the parking brake
lever. Type 2
Tip the cup holder towards you to use it.
NOTE
l When

not using the holder, push the holder
to stow it away.
l Do not put your hand on the cup holder
while getting in or out of the vehicle. The
cup holder could break.
l Never place anything other than a cup or
drink can in the cup holder. RHD vehicles
Type 1
The

cup holder is located in front of the floor console. Type 2 (Passenger’s side only)
To use the cup holder, pull it out.
NOTE
l When

not using the holder, push the holder
to stow it away. For pleasant driving
6-40
6
OHAE13E1

Assist grips
E00732800272
The
assist grips (located above the doors on the
headliner) are not designed to support body weight.
They are intended for use only while seated in the
vehicle. CAUTION
l
Do
not use the assist grips when getting in-
to or out of the vehicle. The assist grips
could detach causing you to fall. For pleasant driving
6-41 6
