7. Release Sunrider  latch (both sides).
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255

8. Open the swing gate and lower the top.
NOTE: Ensure the fabric does not overhang the sides of
the vehicle. Quick Steps For Raising The Soft Top
1. Open the swing gate and raise the top, engaging the
Sunrider  latches (another person may be needed to
help with this operation).256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Install rear corner panels.
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257

3. Rotate the header forward. 4. Engage the header latches.258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

5. Install the back window. 6. Install the side windows.
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259

7. Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to the
window. 8. Insert the retainer along the bottom edge of the
window into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish
by closing the zipper completely and attaching the
Velcro  along the top and rear of the window. Repeat
this step for the opposite side.
1 — Incorrect Insertion
2 — Correct Insertion260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Folding Down The Soft Top
1 — Header Bow 6 — Body Side Retainer
2 — 2–Bow 7 — Quarter Window
3 — 3–Bow 8 — Check Strap
4 — 4–Bow 9 — Front Retainer — Quarter Window
5 — Sail Panel 10 — Bottom Retainer — Quarter Window
3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
5 — Sail Panels262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
