Page 105 of 112
SPECIFICATIONS
8-2
8
2nd:2.000 (32/16)
3rd: 1.667 (30/18)
4th:
1.444 (26/18)
5th: 1.286 (27/21)
6th: 1.150 (23/20)
Chassis:Frame type:Diamond
Caster angle: 24.00 °
Trail:
97 mm (3.8 in)Front tire:Type:Tubeless
Size:
120/70 ZR17M/C (58W)
Manufacturer/model: BRIDGESTONE/BT016F F
Manufacturer/model: DUNLOP/Qualifier PT MRear tire:Type: Tubeless
Size: 180/55 ZR17M/C (73W)
Manufacturer/model:
BRIDGESTONE/BT016R F Manufacturer/model:
DUNLOP/Qualifier PT M
Loading:Maximum load:
186 kg (410 lb)
(Total weight of rider, passenger, cargo and
accessories)Tire air pressure (measured on cold
tires):Loading condition:0–90 kg (0–198 lb)
Front:250 kPa (2.50 kgf/cm², 36 psi)
Rear:
290 kPa (2.90 kgf/cm², 42 psi)
Loading condition: 90–186 kg (198–410 lb)
Front:250 kPa (2.50 kgf/cm², 36 psi)
Rear:
290 kPa (2.90 kgf/cm², 42 psi)
High-speed riding: Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear: 290 kPa (2.90 kgf/cm², 42 psi)Front wheel:Wheel type:
Cast wheel
Rim size: 17M/C x MT3.50Rear wheel:Wheel type:
Cast wheel Rim size:
17M/C x MT5.50
Front brake:Type:
Dual disc brake
Operation: Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:Single disc brake
Operation: Right foot operation
Specified brake fluid:
DOT 4Front suspension:Type:Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 115.0 mm (4.53 in)Rear suspension:Type:
Swingarm (link suspension)
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel: 120.0 mm (4.72 in)Electrical system:Ignition system:TCI
U1JSE0E0.book Page 2 Wednesday, July 27, 2011 10:34 AM
Page 106 of 112
SPECIFICATIONS
8-3
8
Charging system:AC magnetoBattery:Model:
YTZ10S
Voltage, capacity: 12 V, 8.6 AhHeadlight:Bulb type:
Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 55 W × 2
Tail/brake light:
LED
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light:
LED
License plate light: 12 V, 5.0 W × 1
Meter lighting: LED
Neutral indicator light:
LED
High beam indicator light: LED
Oil level warning light: LED
Turn signal indicator light:
LED Fuel level warning light:
LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
Immobilizer system indicator light: LED
Shift timing indicator light: LED
Fuses:Main fuse:50.0 A
Headlight fuse: 15.0 A
Taillight fuse:
7.5 A
Signaling system fuse: 10.0 A
Ignition fuse: 15.0 A
Radiator fan fuse:
15.0 A × 2
Fuel injection system fuse: 15.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse:
7.5 A
U1JSE0E0.book Page 3 Wednesday, July 27, 2011 10:34 AM
Page 107 of 112
CONSUMER INFORMATION
9-1
9
EAU48612
Identification numbers Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26520
Model label
The model label is affixed to the frame
under the passenger seat. (See page
3-20.) Record the information on this la-
bel in the space provided. This informa-
tion will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number
1. Model label
U1JSE0E0.book Page 1 Wednesday, July 27, 2011 10:34 AM
Page 108 of 112
INDEXAAir filter element .................................... 6-19
Anti-theft alarm (optional)...................... 3-14
Auxiliary light ......................................... 6-38BBattery................................................... 6-33
Brake and clutch levers, checking and lubricating ..................... 6-30
Brake and shift pedals,
checking and lubricating ..................... 6-30
Brake fluid, changing ............................ 6-26
Brake fluid level, checking .................... 6-25
Brake lever ............................................ 3-16
Brake lever free play, checking ............. 6-23
Brake light switches .............................. 6-24
Brake pedal ........................................... 3-17CCables, checking and lubricating .......... 6-29
Care ........................................................ 7-1
Catalytic converters .............................. 3-19
Clutch lever ........................................... 3-15
Clutch lever free play, adjusting ............ 6-23
Coolant.................................................. 6-16
Coolant temperature warning light .......... 3-5
Cowlings and panels, removing and installing ......................... 6-8DDimmer switch ...................................... 3-14
Drive chain, cleaning and lubricating .... 6-28
Drive chain slack ................................... 6-27EEngine break-in ....................................... 5-3
Engine idling speed, checking .............. 6-19
Engine oil and oil filter cartridge ............ 6-13 Engine stop switch................................ 3-15
Engine trouble warning light ................... 3-7
EXUP system ....................................... 3-28
FFront and rear brake pads, checking .... 6-24
Front fork, adjusting .............................. 3-22
Front fork, checking .............................. 6-32
Fuel....................................................... 3-18
Fuel consumption, tips for reducing........ 5-3
Fuel level warning light ........................... 3-4
Fuel tank breather hose and
overflow hose ..................................... 3-19
Fuel tank cap ........................................ 3-17
Fuses, replacing ................................... 6-34HHandlebar switches .............................. 3-14
Hazard switch ....................................... 3-15
Headlight bulb, replacing ...................... 6-35
Helmet holding cable ............................ 3-21
High beam indicator light ........................ 3-4
Horn switch ........................................... 3-15IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ................ 3-29
Immobilizer system ................................. 3-1
Immobilizer system indicator light........... 3-7
Indicator lights and warning lights .......... 3-4LLicense plate light bulb, replacing ........ 6-38
Luggage strap holders .......................... 3-27MMain switch/steering lock........................ 3-2
Maintenance and lubrication, periodic .... 6-4 Maintenance,
emission control system ....................... 6-3
Matte color, caution ................................. 7-1
Model label .............................................. 9-1
Multi-function meter unit .......................... 3-8
NNeutral indicator light .............................. 3-4OOil level warning light .............................. 3-4PParking .................................................... 5-4
Part locations .......................................... 2-1
Pass switch ........................................... 3-14RRear view mirrors .................................. 3-22SSafety information ................................... 1-1
Seats ..................................................... 3-20
Shifting .................................................... 5-2
Shift pedal ............................................. 3-16
Shift timing indicator light ........................ 3-7
Shock absorber assembly, adjusting .... 3-25
Sidestand .............................................. 3-28
Sidestand, checking and lubricating...... 6-31
Spark plugs, checking ........................... 6-12
Specifications .......................................... 8-1
Starting the engine .................................. 5-1
Start switch............................................ 3-15
Steering, checking................................. 6-32
Storage.................................................... 7-4
Supporting the motorcycle .................... 6-39
Swingarm pivots, lubricating ................. 6-31TTail/brake light ....................................... 6-37
U1JSE0E0.book Page 1 Wednesday, July 27, 2011 10:34 AM
Page 109 of 112
INDEX
Throttle grip and cable, checking and lubricating ..................... 6-29
Throttle grip free play, checking ........... 6-19
Tires...................................................... 6-20
Tool kit .................................................... 6-2
Troubleshooting .................................... 6-43
Troubleshooting charts ......................... 6-45
Turn signal indicator lights ...................... 3-4
Turn signal light bulb, replacing ............ 6-37
Turn signal switch ................................. 3-14VValve clearance .................................... 6-20
Vehicle identification number.................. 9-1WWheel bearings, checking .................... 6-33
Wheel (front) ......................................... 6-39
Wheel (rear).......................................... 6-41
Wheels.................................................. 6-22
U1JSE0E0.book Page 2 Wednesday, July 27, 2011 10:34 AM
Page 110 of 112
A5-yoko_Blank.fm Page 1 Monday, July 11, 2011 4:13 PM
Page 111 of 112
A5-yoko_Blank.fm Page 1 Monday, July 11, 2011 4:13 PM
Page 112 of 112
PRINTED IN JAPAN2011.08-0.3×1 CR (E)
DIC183
PRINTED ON RECYCLED PAPER
