2012 PEUGEOT 308 Owners Manual

303
06
1
2
3
4
5
6
7
8
9
MENU
OK
BLUETOOTH


For safety reasons and because they require prolonged attention
on the part of the driver, the operations for pairing of the Bluetooth
mobile telephone with the Bluetooth hands-free system of your
audio equipment must be carried out with the vehicle stationary
and the ignition on.

Press the MENU button.

A window is displayed with a message that a search is in progress.
Activate the telephone's Bluetooth function.

In the menu, select:


- Bluetooth telephone function -
Audio

- Bluetooth confi guration

- Perform a Bluetooth search

The services offered depend on the network, the SIM card and the
compatibility of the Bluetooth equipment used.
Consult your telephone's manual and your operator to fi nd out which
services are available to you.










BLUETOOTH TELEPHONE

SCREEN C

The TELEPHONE menu permits access to the following functions
in particular: Directory * , Call list, Pairing management.
The fi rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed in the
screen: enter a code with at least 4 digits.
Confi rm by pressing OK.

A message that the pairing has been successful appears in the screen.
Select the telephone to be connected from the list. Only one
telephone can be connected at a time.

A message is displayed in the screen of the
telephone chosen. To accept the pairing, enter the
same code on the telephone, then confi rm with OK.

The automatic connection authorised is only active after the
telephone has been confi gured.
The directory and the call list can be accessed after the
synchronisation period.

(Available according to model and version)

*
If your telephone is fully compatible.
If pairing fails, the number of attempts is not limited. Go to www.peugeot.co.uk for more information (compatibility, more
help, ...).
PAIRING A TELEPHONE/FIRST CONNECTION

304
06
1
2
1
2
1
OK

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed
display in the vehicle's screen.

Select the YES tab on the display
using the buttons and confi rm by
pressing OK.

Press the steering mounted control to accept the
call.


MAKING A CALL

From the Bluetooth telephone function Audio menu, select Manage
the telephone call then Call, Call list or Directory.

Press the steering mounted control for more than
two seconds for access to your directory, then
navigate with the thumb wheel.
Or
To dial a number, use your telephone's keypad,
with the vehicle stationary.



During a call, press the steering mounted control
for more than 2 seconds.
Confi rm with OK to end the call.

ENDING A CALL

BLUETOOTH

305
1
2
3
SOURCE
06

Initiate the pairing between the telephone and
the vehicle. This pairing can be initiated from
the vehicle's telephone function menu or via the
telephone's keypad. See steps 1 to 9 on the previous
pages. During the pairing phase, the vehicle must be
stationary with the key in the ignition.

Select the telephone to be connected from the telephone function
menu.
The audio system connects to a newly paired telephone
automatically.







BLUETOOTH AUDIO STREAMING *


Wireless transmission of the telephone's music fi les via the audio
equipment. The telephone must be able to manage the appropriate
Bluetooth profi les (Profi les A2DP/AVRCP).

*
Depending on the compatibility of the telephone.

**
In certain cases, playing of the Audio fi les must be initiated from the
keypad.

***
If the telephone supports the function.
Activate the streaming source by
pressing the SOURCE button ** .
The tracks to be played can be
controlled as usual via the buttons on
the audio system control panel and
the steering mounted controls *** .
The contextual information can be
displayed on the screen.


BLUETOOTH

306
07
1
2
3
4
5
6
7
8
MENU
OK
OK
OK
OK
CONFIGURATION

Press the MENU button.

Using the arrows, select DISPLAY
CONGIGURATION.

Press to confi rm the selection.

Using the arrows, select YEAR.
Press to confi rm the selection.

Press to confi rm the selection.
Adjust the setting.

Start again from step 1 then set
MONTH, DAY, HOUR, MINUTES.

















SETTING THE DATE AND TIME


SCREEN A

307
07
1
2
3
4
5
6
7
8
MENU
OK
OK
OK
OK
CONFIGURATION
Press the MENU button.

Using the arrows, select
PERSONALISATION
CONFIGURATION.

Press to confi rm the selection.

Using the arrows, select DISPLAY
CONFIGURATION.
Press to confi rm the selection.

Press to confi rm the selection.
Using the arrows, select ADJUST
DATE AND TIME.

Adjust the settings one by one
confi rming by pressing the OK
button. Next select the OK tab on the
screen then confi rm.























SETTING THE DATE AND TIME


SCREEN C

308
08 SCREEN MENU MAP


RADIO-CD
MAIN FUNCTION


* The parameters vary according to vehicle.
OPTION A

OPTION B...













MONOCHROME A


OPTION A1


OPTION A2



REG MODE

CD REPEAT

RANDOM PLAY



VEHICLE CONFIG *


REV WIPE ACT


OPTIONS


GUIDE LAMPS

DIAGNOSTICS

RDS SEARCH
CONSULT


ABANDON





UNITS



TEMPERATURE: °CELSIUS/°FAHRENHEIT



FUEL CONSUMPTION:
KM/L - L/100 - MPG

1
2
3
31
2
2
2
2
1
2
3
2
3
1
2
2
1
2
2

309
08 SCREEN MENU MAP


DISPLAY ADJUST


MONTH

DATE

HOUR

MINUTES
YEAR

12 H/24 H MODE



LANGUAGE


ITALIANO

NEDERLANDS

PORTUGUES

PORTUGUES-BRASIL
FRANCAIS

DEUTSCH

ENGLISH


ESPANOL

1
2
2
2
2
2
2
1
2
2
2
2
2
2
2
2

310
08 SCREEN MENU MAP


Press the OK dial for access to short-cut menus according to the display on the
screen:











MONOCHROME C


activate/deactivate RDS


activate/deactivate REG mode


activate/deactivate radiotext




RADIO


activate/deactivate Intro



CD/MP3 CD


activate/deactivate track repeat
(the entire current CD for CD, the entire
current folder for MP3 CD)


activate/deactivate random play
(the entire current CD for CD, the entire
current folder for MP3 CD)


activate/deactivate track repeat (of the
current folder/artist/genre/playlist)



USB


activate/deactivate random play
(of the
current folder/artist/genre/playlist)


1
1
1
1
1
1
1
1
