2011 TOYOTA AVALON Owners Manual

17
AVALON_U (OM41428U)
Rear sunshade switchP. 354
Glass breakage sensorP. 94
Fuel filler door opener P. 87
Trunk openerP. 50
Outside rear view mirror switches P. 77
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
VSC off switch P. 196

18
AVALON_U (OM41428U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustration may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.

19
AVALON_U (OM41428U)
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle could
affect electronic systems such as the multiport fuel injection system/sequen-
tial multiport fuel injection system, electronic throttle control system, cruise
control system, vehicle stability control system, SRS airbag system and seat
belt pretensioner system, be sure to check with your Toyota dealer for pre-
cautionary measures or special instructions regarding installation.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota
dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.

20
AVALON_U (OM41428U)
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that will hurt or kill you,
your occupants or others.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that dis-
tracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■General precautions regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the cigarette lighter, the windows, the moon roof, or other features of the
vehicle. In addition, heat build-up or extremely cold temperatures inside the
vehicle can be fatal to children.

21
AVALON_U (OM41428U)
Symbols used throughout this manual
Cautions & Notices
Symbols used in illustrations
CAUTION
This is a warning against anything which may cause injury to people if the
warning is ignored. You are informed about what you must or must not do in
order to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause damage to the vehicle or
its equipment if the warning is ignored. You are informed about what you must
or must not do in order to avoid or reduce the risk of damage to your Toyota
and its equipment.
Safety symbol
The symbol of a circle with a slash through it means “Do not”,
“Do not do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turn-
ing, etc.) used to operate switches
and other devices.
Indicates the outcome of an opera-
tion (e.g. a lid opens).

22
AVALON_U (OM41428U)

Before driving1
23
AVALON_U (OM41428U)
1-1. Key information
Keys ................................... 24
1-2. Opening, closing and locking
the doors and trunk
Smart key system .............. 26
Wireless remote control ..... 38
Doors ................................. 43
Trunk .................................. 50
1-3. Adjustable components
(seats, steering wheel,
mirrors)
Front seats ......................... 54
Rear seats.......................... 56
Driving position memory
system ............................. 58
Head restraints................... 62
Seat belts ........................... 65
Steering wheel ................... 73
Inside rear view mirror ....... 75
Outside rear view
mirrors.............................. 771-4. Opening and closing the
windows and moon roof
Power windows .................. 80
Moon roof ........................... 83
1-5. Refueling
Opening the fuel tank
cap ................................... 87
1-6. Theft deterrent system
Engine immobilizer
system ............................. 91
Alarm.................................. 94
Theft prevention labels
(U.S.A.) ............................ 98
1-7. Safety information
Correct driving posture....... 99
SRS airbags ..................... 101
Front passenger occupant
classification system ...... 114
Child restraint systems..... 120
Installing child
restraints ........................ 125

24
AVALON_U (OM41428U)
1-1. Key information
Keys
Using the mechanical key (vehicles with smart key system)
Take out the mechanical key.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the
smart key system does not oper-
ate properly, you will need the
mechanical key.
The following keys are provided with the vehicle.
Vehicles with smart key system
Electronic keys
• Operating the smart key
system (P. 26)
• Operating the wireless
remote control function
(P. 38)
Mechanical keys
Key number plate
Vehicles without smart key system
Master keys
Operating the wireless remote
control function (
P. 38)
Key number plate
