2011 TOYOTA AVALON Owners Manual

217 3-1. Using the air conditioning system and defogger
3
Interior features
AVALON_U (OM41428U)Turning to the right increase the temperature and turn-
ing to the left decrease the temperature.
The temperature for the driver and passenger seats can be set sep-
arately.
Adjusting the settings
■Adjusting the temperature setting
Turning to the right increase the temperature and turning
to the left decrease the temperature.
Turning to the right (increase) or turning to the left
(decrease) to separately adjust the temperature for the passenger and
driver sides (dual mode). Press to return the driver and passenger
side temperatures to the same setting (simultaneous mode).
The air conditioning system switches between dual and simultaneous
modes each time is pressed.
■Adjusting the fan speed
Press “
” (increase) or “” (decrease) on the .
Press to turn the fan off.

218 3-1. Using the air conditioning system and defogger
AVALON_U (OM41428U)■Changing the air outlets
Press .
The air outlets switch each time
the button is pressed. The air flow
shown on the display indicate the
following.
Air flows to the upper body.
Air flows to the upper body and
feet.

219 3-1. Using the air conditioning system and defogger
3
Interior features
AVALON_U (OM41428U)Air flows to the feet.
Air flows to the feet and the
windshield defogger operates.
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recircu-
lated air mode (indicator on) modes each time the button is pressed.

220 3-1. Using the air conditioning system and defogger
AVALON_U (OM41428U)
Defogging the windshield
Press
.
The air conditioning system con-
trol operates automatically.

221 3-1. Using the air conditioning system and defogger
3
Interior features
AVALON_U (OM41428U)
Adjusting the position of and opening and closing the air outlets
Center outlets
Turn the knob to open or close
the vent
Direct air flow to the left or
right, up or down
Side outlets
Direct air flow to the up or
down
Direct air flow to the left or
right
Rear seat outlets
Direct air flow to the up or
down
Direct air flow to the left or
right

222 3-1. Using the air conditioning system and defogger
AVALON_U (OM41428U)
■Using the automatic mode
Fan speed is adjusted automatically in accordance with the temperature set-
ting and ambient conditions. As a result, the following may occur.
●Immediately after the switch is pressed, the fan may stop for a while until
warm or cool air is ready to flow.
●Cool air may flow to the area around the upper body when the heater is
on.
■Using the system in recirculated air mode
The windows will fog up more easily if the recirculated air mode is used for
an extended period.
■Switching between outside air and recirculated air modes
Recirculated air mode or outside air mode may be automatically switched to
in accordance with the temperature setting and the inside temperature.
■Window defogger feature
Recirculated air mode may automatically switch to outside air mode in situa-
tions where the windows need to be defogged.
■Outside temperature approaches 32 F (0 C)
The air conditioning system may not operate even when is pressed.
■When the indicator light on flashes
Press and turn off the air conditioning system before turning it on once
more. There may be a problem in the air conditioning system if the indicator
light continues to flash. Turn the air conditioning system off and have it
inspected by your Toyota dealer.
■Air conditioning odors
●During use, various odors from inside and outside the vehicle may enter
into and accumulate in the air conditioning system. This may then cause
odor to be emitted from the vents.
●To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.

223 3-1. Using the air conditioning system and defogger
3
Interior features
AVALON_U (OM41428U)
CAUTION
■To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The
difference between the temperature of the outside air and that of the wind-
shield can cause the outer surface of the windshield to fog up, blocking your
vision.
NOTICE
■To prevent battery discharge
Do not leave the automatic air conditioning system on longer than necessary
when the engine is not running.

224
3-1. Using the air conditioning system and defogger
AVALON_U (OM41428U)
Using the steering wheel climate control switches
Using the automatic mode
Press .
The air conditioning system will begin to operate. Air outlets and
fan speed are automatically adjusted according to the tempera-
ture setting.
Press “” to increase the temperature and “” to decrease the
temperature on .
The temperature for the driver and passenger seats can be set
separately.
Adjust the temperature settings
Press “
” to increase the temperature and “” to decrease the tem-
perature on .
Turning off the fan
Press .
Some air conditioning feature can be controlled using the switches
on the steering wheel.
Temperature control
Automatic mode
Off
