U1502 ICC SENSOR CAN COMM CIRCDAS-189
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U1502 ICC SENSOR CAN COMM CIRC
DTC LogicINFOID:0000000006228159
DTC DETECTION LOGIC
NOTE:
If DTC “U1502” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U1502” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1502” detected as the current malfunction?
YES >> Refer to DAS-189, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228160
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U1502” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “LASER”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-55, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1502 (147) ICC SEN CAN COMM
CIR ADAS control unit detects an error signal that is
received from ICC sensor via CAN communi-
cation
ICC sensor
Revision: 2010 May2011 QX56

DAS-190
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1513 METER CAN 3
U1513 METER CAN 3
DTC LogicINFOID:0000000006228161
DTC DETECTION LOGIC
NOTE:
If DTC “U1513” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U1513” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1513” detected as the current malfunction?
YES >> Refer to DAS-190, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228162
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U1513” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK COMBINATION METER SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “S elf Diagnostic Result” of “METER/M&A”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
MWI-43, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1513 (163) METER CAN CIRC 3 ADAS control unit detects an error signal that is
received from combination meter via CAN
communication
Combination meter
Revision: 2010 May2011 QX56

DAS
U1514 STRG SEN CAN 3DAS-191
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U1514 STRG SEN CAN 3
DTC LogicINFOID:0000000006228163
DTC DETECTION LOGIC
NOTE:
If DTC “U1514” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U1514” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1514” detected as the current malfunction?
YES >> Refer to DAS-191, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228164
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U1514” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1514 (165) STRG SEN CAN CIRC 3 ADAS control unit detects an error signal that is
received from steering angle sensor via CAN
communication
Steering angle sensor
Revision: 2010 May2011 QX56

DAS-192
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1515 ICC SENSOR CAN 3
U1515 ICC SENSOR CAN 3
DTC LogicINFOID:0000000006228165
DTC DETECTION LOGIC
NOTE:
If DTC “U1515” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U1515” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1515” detected as the current malfunction?
YES >> Refer to DAS-192, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228166
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U1515” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “S elf Diagnostic Result” of “LASER”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-55, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1515 (165) ICC SENSOR CAN
CIRC 3 ADAS control unit detects an error signal that is
received from ICC sensor via CAN communi-
cation
ICC sensor
Revision: 2010 May2011 QX56

DAS
U1517 ACCELERATOR PEDAL ACTUATOR CAN 3DAS-193
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U1517 ACCELERATOR PEDAL ACTUATOR CAN 3
DTC LogicINFOID:0000000006228167
DTC DETECTION LOGIC
NOTE:
If DTC “U1517” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U1517” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1517” detected as the current malfunction?
YES >> Refer to DAS-193, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228168
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U1517” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ACCELERATOR PEDAL ACTU ATOR SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ACCELE PEDAL ACT”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-108, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1517 (167) APA CAN CIRC 3 ADAS control unit detects an error signal that is
received from accelerator pedal actuator via
CAN communication
Accelerator pedal actuator
Revision: 2010 May2011 QX56

DAS-194
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U1520 4WD CAN 3
U1520 4WD CAN 3
DTC LogicINFOID:0000000006228169
DTC DETECTION LOGIC
NOTE:
If DTC “U1520” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U1520” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1520” detected as the current malfunction?
YES >> Refer to DAS-194, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228170
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U1520” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK TRANSFER CONTROL UNI T SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ALL MODE AWD/4WD”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DLN-29, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1520 (176) 4WD CAN CIRC 3 ADAS control unit detects an error signal that is
received from transfer control unit via CAN
communication
Transfer control unit
Revision: 2010 May2011 QX56

DAS
POWER SUPPLY AND GROUND CIRCUITDAS-195
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
POWER SUPPLY AND GROUND CIRCUIT
ADAS CONTROL UNIT
ADAS CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006223648
1.CHECK ADAS CONTROL UNIT POWER SUPPLY CIRCUIT
Check voltage between ADAS contro l unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the ADAS control unit power supply circuit.
2.CHECK ADAS CONTROL UNIT GROUND CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the ADAS control unit connector.
3. Check for continuity between ADAS control unit harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair the ADAS control unit ground circuit.
ACCELERATOR PEDAL ACTUATOR
ACCELERATOR PEDAL ACTUATOR : Diagnosis ProcedureINFOID:0000000006223649
1.CHECK FUSES
Check if any of the following fuses are blown:
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK ACCELERATOR PEDAL ACTUATOR POWER SUPPLY CIRCUIT
Check voltage between accelerator pedal actuator harness connector and ground.
Te r m i n a l Condition
Vo l ta g e
(Approx.)
(+) (–)
ADAS control unit
GroundIgnition
switch
Connector Terminal
B61 16 OFF 0 V
ON Battery volt-
age
ADAS control unit
GroundContinuity
Connector Terminal
B61 6 Existed
Signal name Fuse No.
Battery power supply 33
Revision: 2010 May2011 QX56

DAS
DCA SYSTEM NOT ACTIVATED (SWITCH IS ON)DAS-201
< SYMPTOM DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
DCA SYSTEM NOT ACTIVA TED (SWITCH IS ON)
DescriptionINFOID:0000000006223655
The dynamic driver assistance switch can be tu rned ON/OFF, but the DCA system does not operate.
NOTE:
Never start the operation under the following conditions. No operation condition
 When the brake pedal depressed
 When the ICC system is set
 When the system judges that the vehicle co mes to a standstill by the system control
 When the vehicle ahead is not detected Operation cancellation condition
 When the dynamic driver assistance switch is turned to OFF
 When the system malfunction occurs
 When ABS or VDC (including the TCS) operates
 When the VDC is turned OFF
 When driving into a strong light (i.e., sunlight)
 When the ICC sensor body window is dirty and the measurement of the distance between the vehicles
becomes difficult
 When ABS warning lamp is ON
 When the SNOW mode switch is turned ON
 When the 4WD shift switch is not AUTO position
Diagnosis ProcedureINFOID:0000000006223656
1.CHECK CAUSE OF AUTOMATIC CANCELLATION
Check if there is any cancellation cause in the “CAUSE OF AUTO-CANCEL” on “WORK SUPPORT” of “ICC/
ADAS” with CONSULT-III.
Is it displayed?
Not displayed>>GO TO 2.
“OPE SW VOLT CIRC”>>Refer to DAS-138, "
DTC Logic".
“VHCL SPD UNMATCH”>>Refer to DAS-131, "
DTC Logic".
“IGN LOW VOLT”>>Refer to DAS-130, "
DTC Logic".
“CAN COMM ERROR”>>Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
“ICC SENSOR CAN COMM ERR”>>Refer to DAS-177, "
DTC Logic".
“ABS/TCS/VDC CIRC”>>Refer to DAS-133, "
DTC Logic".
“APA HI TEMP”>>Refer to DAS-170, "
DTC Logic".
“ECD CIRCUIT”>>Refer to DAS-156, "
DTC Logic".
2.PERFORM ALL OF THE SELF-DIAGNOSIS
1. Perform “All DTC Reading”.
2. Check if any DTC is detected in self-d iagnosis results of “ICC/ADAS”. Refer to DAS-100, "
DTC Index".
Is any DTC detected?
YES >> GO TO 3.
NO >> GO TO 4.
3.REPAIR OR REPLACE MALFUNCTIONING PARTS
Repair or replace malfunctioning parts i dentified by the self-diagnosis result.
>> GO TO 6.
4.CHECK EACH SWITCH AND VEHICLE SPEED SIGNAL
1. Start the engine.
2. Check that the following items operate norma lly in “DATA MONITOR” of “ICC/ADAS”.
- “VHCL SPEED SE”
- “BRAKE SW”
- “DYNA ASIST SW”
Is there a malfunctioning item?
Revision: 2010 May2011 QX56
