DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-87
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Active Pedal
CAUTION:
 Shift the selector lever to “P” po
sition, and then perform the test.
 Never depress the accelerator pedal excessively. (T he engine speed may rise unexpectedly when
finishing the test.)
NOTE:
 Depress the accelerator pedal to check when performing the test.
 The test can be performed only when the engine is running.
NOTE:
The test is finished in 10 seconds after starting
DCA INDICATOR
NOTE:
The test can be performed only when the engine is running.
LDP BUZZER
WARNING SYSTEM IND
Test item Operation Description Accelerator pedal operation
Active Pedal MODE1
Transmit the accelerator pedal feedback force control signal
to the accelerator pedal actuator via ITS communication. Constant with a force of 25 N
for 8 seconds
MODE2 Constant with a force of 15 N
for 8 seconds
MODE3 Change up to a force of 25 N for
8 seconds
MODE4 Change up to a force of 15 N for
8 seconds
Test start Starts the tests of “MODE1”, “MODE2”, “MODE3” and
“MODE4” —
Reset Stops transmitting the accelerator pedal feedback force
control signal below to end the test.
—
End Returns to the “SELECT TEST ITEM” screen —
JPOIA0061GB
Te s t i t e m Opera-
tion Description DCA system switch indicator
DCA INDICATOR Off
Stops transmitting the DCA system switch indicator signal be-
low to end the test
—
On Transmits the DCA system switch indicator signal to the com-
bination meter via CAN communication ON
Te s t i t e m
Opera-
tion Description Warning buzzer
LDP BUZZER Off
Stops transmitting the warning buzzer signal below to end the
test
—
On Transmits the warning buzzer signal to the warning buzzer ON
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ACCELERATOR PEDAL ACTUATOR)
DAS-91
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
DIAGNOSIS SYSTEM (ACCELER ATOR PEDAL ACTUATOR)
CONSULT-III Function (ACCELERATOR PEDAL ACT)INFOID:0000000006223509
DESCRIPTION
CONSULT-III performs the following functions via CAN communication with ADAS control unit and the com-
munication with accelerator pedal actuator.
SELF DIAGNOSTIC RESULT
Self Diagnostic Result
Refer to DAS-108, "DTC Index".
FFD (Freeze Frame Data)
The accelerator pedal actuator records the fo llowing data when the malfunction is detected.
NOTE:
 The number is 0 when is detected now.
 The number increases like 1 → 2 ··· 38 → 39 after returning to the normal condition whenever IGN OFF →
ON.
 The number is fixed to 39 until the self-di agnosis results are erased if it is over 39.
DATA MONITOR
Test mode Function
Self Diagnostic Result  Displays malfunctioning system memorized in accelerator pedal actuator
 Displays the Freeze Frame Data when the malfunction is detected
DATA MONITOR Displays real-time input/output data of accelerator pedal actuator
ACTIVE TEST Enables operation check of electrical loads by sending driving signal to them
ECU Identification Displays accelerator pedal actuator parts number
CAN Diag Support Monitor The results of transmit/receive diagnosis of ITS communication can be read
Freeze Frame Data item [Unit] Description
TGT FBK FRC
[N] It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out
from the accelerator pedal feedback force control signal received via ITS communication at the time
when the malfunction is detected
TGT MOT POSI
[%] It displays the target motor position that the accelerator pedal actuator read out from the accelerator
pedal feedback force control signal received via ITS communication at the time when the malfunction
is detected
ACT MOT POSI
[%] It displays the integrated motor position that the accelerator pedal actuator read out at the time when
the malfunction is detected
AP OPEN
[%] It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS
communication at the time when the malfunction is detected
APA TEMP
[ ° C] It displays the integrated motor temperature that the accelerator pedal actuator read out at the time
when the malfunction is detected
APA CURRENT
[A] It displays the integrated motor consumption current that the accelerator pedal actuator read out at
the time when the malfunction is detected
APA PWR
[V] It displays the power supply voltage that the accelerator pedal actuator read out at the time when the
malfunction is detected
APA OPE STATS
[On/Off] It displays the activation permission status of accelerator pedal actuator at the time when the mal-
function is detected
APA STATS
[READY/NG/TP NG/INIT] It displays the condition of accelerator pedal actuator at the time when the malfunction is detected
IGN Counter
NoteIt displays number of ignition switch OFF → ON after the malfunction is detected
Revision: 2010 May2011 QX56

DAS-94
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system
On
When the buzzer of the following system not operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
 When IBA system is malfunctioning
 When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
 When IBA system is normal
 When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-96
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON indicator lamp OFF Off
LANE DPRT W/L Drive the vehicle and activate
the LDW system or LDP sys-
tem Lane departure warning lamp ON On
Lane departure warning lamp OFF Off
LDW BUZER OUT-
PUT Drive the vehicle and activate
the LDW/LDP system or BSW
system When the buzzer of the following system operates
 LDW/LDP system
 BSW system
On
When the buzzer of the following system does not oper-
ate
 LDW/LDP system
 BSW system Off
LDP SYSTEM ON Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
READY signal Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
Camera lost Drive the vehicle and activate
the LDW system, LDP system Both side lane markers are detected Detect
Deviate side lane marker is lost Deviate
Both side lane markers are lost Both
Shift position  Engine running
 While driving Displays the
shift position
Turn signal Turn signal lamps OFF
Off
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamp LH and RH blinking LH&RH
SIDE G While driving Vehicle turning right Negative value
Vehicle turning left Positive value
WARN REQ Drive the vehicle and activate
the LDP system Lane departure warning is operating On
Lane departure warning is not operating Off
STATUS signal Drive the vehicle and activate
the LDP system When the LDP system is ON Stnby
When the LDP system is operating Warn
When the LDP system is canceled Cancl
When the LDP system is OFF Off
Lane unclear While driving Lane marker is unclear On
Lane marker is clear Off
FUNC ITEM Ignition switch ON FUNC1
FUNC ITEM (NV-ICC) Ignition switch ON Off
FUNC ITEM (NV-
DCA) Ignition switch ON
Off
DCA SELECT Ignition switch ON “Distance Control Assist” set with the navigation system
is ON
On
“Distance Control Assist” set with the navigation system
is OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-98
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223511
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(V/W)
Ground Warning systems
switch
InputIgnition
switch ON When warning systems
switch is not pressed
12 V
When warning systems
switch is pressed 0 V
3
(R/Y) IBA OFF switch Input Ignition
switch
ON When IBA OFF switch is
not pressed
12 V
When IBA OFF switch is
pressed 0 V
4
(LG/B) Warning systems ON
indicator
OutputIgnition
switch ON Warning systems ON indi-
cator ON
0 V
Warning systems ON indi-
cator OFF 12 V
5
(R) ICC brake hold relay
drive signal
OutputIgnition
switch ON —12 V
At “STOP LAMP” test of
“Active test” 0 V
6
(B) Ground — Ignition
switch ON —0 V
7
(L) ITS communication-H — — — —
8
(Y) ITS communication-L — — — —
12
(G/R) Warning buzzer signal Output Ignition
switch ON Warning buzzer operation 0 V
Warning buzzer not oper-
ating
12 V
14
(L) CAN -H — — — —
15
(P) CAN -L — — — —
16
(W/G) Ignition power supply Input Ignition switch ON Battery Voltage
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warn
ing lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warn
ing lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warn
ing lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56

DAS-104
< ECU DIAGNOSIS INFORMATION >[DCA]
ICC SENSOR
ICC SENSOR
Reference ValueINFOID:0000000006228056
VALUES ON THE DIAGNOSIS TOOL
TERMINAL LAYOUT
PHYSICAL VALUES
Monitor item Condition Value/Status
VHCL SPEED SE While driving Value of vehicle
speed signal
(wheel speed)
YAW RATE While driving Vehicle stopped 0.0
Vehicle turning right Positive value
Vehicle turning left Negative value
PWR SUP MONI Ignition switch ON Power supply
voltage value of ICC sensor
DISTANCE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the dis-
tance from the
preceding vehi- cle
When a vehicle ahead is not detected 0.0
RELATIVE SPD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the rel-
ative speed
When a vehicle ahead is not detected 0.0
LASER OFFSET NOTE:
The item is indicated, but not used
—
LASER HEIGHT NOTE:
The item is indicated, but not used —
STEERING ANGLE Ignition switch ON When setting the steering wheel in straight-ahead posi-
tion
0.0
When turning the steering wheel 90 ° rightward +90
When turning the steering wheel 90 ° leftward -90
STRG ANGLE
SPEED Ignition switch ON At the time of turning the steering wheel Steering wheel
turning speed is
displayed
L/R ADJUST Ignition switch ON At the completion of laser beam adjustment Horizontal cor-
rection value is
displayed
U/D ADJUST Ignition switch ON At the completion of laser beam adjustment Vertical correc-
tion value is dis-
played
JPOIA0105ZZ
Revision: 2010 May2011 QX56

DAS
ICC SENSORDAS-105
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Fail-safeINFOID:0000000006228057
If a malfunction occurs in the ICC sensor, ADAS cont rol unit cancels control, sounds a beep, and turns ON the
ICC system warning lamp in the combination meter.
DTC Inspection Priority ChartINFOID:0000000006228058
If multiple DTCs are detected simultaneously, che ck them one by one depending on the following DTC inspec-
tion priority chart.
DTC IndexINFOID:0000000006228059
NOTE:
 The details of time display are as per the following.
- 0: The malfunctions that are detected now
CAN communication system (U1000, U1010)
- 1 - 39: It increases like 0 → 1 → 2 ··· 38 → 39 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 39, it is fixed to 39 unt il the self-diagnosis results are erased.
Other than CAN communication s ystem (Other than U1000, U1010)
- 1 - 49: It increases like 0 → 1 → 2 ··· 38 → 49 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 49, it is fixed to 49 unt il the self-diagnosis results are erased.
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
1
(W/G)
GroundIgnition power supply Input Ignition switch ON Battery voltage
3
(L) ITS communication-H — — —
4
(B) Ground — Ignition switch ON 0 V
6
(Y) ITS communication-L — — —
Priority Detected items (DTC)
1  U1000: CAN COMM CIRCUIT
 U1010: CONTROL UNIT (CAN)
2  C1A50: ADAS MALFUNCTION
3  C1A01: POWER SUPPLY CIR
 C1A02: POWER SUPPLY CIR 2
 C1A12: LASER BEAM OFFCNTR
 C1A16: RADAR STAIN
 C1A18: LASER AIMING INCMP
 C1A21: UNIT HIGH TEMP
 C1A39: STRG SEN CIR
 U0104: ADAS CAN CIR1
 U0121: VDC CAN CIR2
 U0126: STRG SEN CAN CIR1
 U0405: ADAS CAN CIR2
 U0415: VDC CAN CIR1
 U0428: STRG SEN CAN CIR2
4  C1A00: CONTROL UNIT
Revision: 2010 May2011 QX56

DAS-108
< ECU DIAGNOSIS INFORMATION >[DCA]
ACCELERATOR PEDAL ACTUATOR
DTC Inspection Priority Chart
INFOID:0000000006223519
If multiple DTCs are detected simultaneously, chec k them one by one depending on the following DTC inspec-
tion priority chart.
DTC IndexINFOID:0000000006223520
NOTE:
 The details of time display are as per the following.
- CRNT: A malfunction is detected now
- PAST: A malfunction was detected in the past
 IGN counter is displayed in FFD (Freeze Frame Data).
- 0: The malfunctions that are detected now
- 1 - 39: It increases like 0 → 1 → 2 ··· 38 → 39 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunction is detected again in the process.
- If it is over 39, it is fixed to 39 until the self-diagnosis results are erased.
× : Applicable
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
1
(B/O)
Ground Battery power supply Input Ignition switch OFF Battery voltage
2
(B) Ground — Ignition switch ON 0 V
3
(W/G) Ignition power supply Input Ignition switch ON Battery voltage
4
(Y) ITS communication-L — — —
5
(L) ITS communication-H — — —
Priority Detected items (DTC)
1  U1000: CAN COMM CIRCUIT
 U1010: CONTROL UNIT (CAN)
2  C1F02: APA C/U MALF
3  C1F01: APA MOTOR MALF
 C1F03: APA HI TEMP
 C1F05: APA PWR SUPLY CIR
 C1F06: CAN CIR2
 C1F07: CAN CIR1
CONSULT-III display ICC system warnin
g lamp Fail-safe function Reference
C1F01: APA MOTOR MALF ON ×DAS-166
C1F02: APA C/U MALF ON ×DAS-168
C1F03: APA HI TEMP — — DAS-170
C1F05: APA PWR SUPLY CIR ON×DAS-171
C1F06: CAN CIR2 ON ×DAS-173
C1F07: CAN CIR1 ON ×DAS-174
U1000: CAN COMM CIRCUIT ON ×DAS-182
U1010: CONTROL UNIT (CAN) ON ×DAS-184
Revision: 2010 May2011 QX56
