< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Output Signal Item
Transmit unit Signal name Description
ECM CAN com-
munica-
tionClosed throttle position signal Receives idle position state (ON/OFF)
Accelerator pedal position signal Receives accelerator pedal position (angle)
ICC steering switch
signal
Dynamic driver as-
sistance switch sig-
nal Receives the operational state of the ICC steering
switch
Engine speed signal Receives engine speed
Stop lamp switch signal Receives an operational state of the brake pedal
Snow mode signal Receives an operational state of the snow mode
TCM CAN com-
munica-
tionInput speed signal Receives the number of revolutions of input shaft
Current gear position signal Receives a current gear position
Shift position signal Receives a selector lever position
Output shaft revolution signal Receives the number of revolutions of output shaft
ABS actuator
and electric unit
(control unit) CAN com-
munica-
tionABS malfunction signal Receives
a malfunction state of ABS
ABS operation signal Receives an operational state of ABS
ABS warning lamp signal Receives an ON/OFF state of ABS warning lamp
TCS malfunction signal Receives a malfunction state of TCS
TCS operation signal Receives an operational state of TCS
VDC OFF switch signal Receives an ON/OFF state of VDC
VDC malfunction signal Receives a malfunction state of VDC
VDC operation signal Receives an operational state of VDC
Vehicle speed signal (ABS) Receives wheel speeds of four wheels
Stop lamp switch signal Receives an operational state of the brake pedal
Yaw rate signal Receives yaw rate acting on the vehicle
Steering angle
sensor CAN com-
munica-
tionSteering angle sensor malfunction signal Receives a malfunction state of steering angle sensor
Steering angle sensor signal
Receives the number of revolutions, turning direction of
the steering wheel
Steering angle speed signal Receives the turning angle speed of the steering wheel
AV control unit CAN com-
munica-
tionSystem selection signal
Receives a selection state of each item in “Driver As-
sist” selected with the navigation system
Transfer control
unit CAN com-
munica-
tion
Current 4WD mode signal Receives a mode selection state of the 4WD shift mode
ICC sensor ITS com-
munica-
tion
ICC sensor signal
Receives detection results, such as the presence or ab-
sence of a vehicle ahead and distance from the vehicle
Accelerator
pedal actuator ITS com-
munica-
tionAccelerator pedal actuator operation status
signal
Receives an operational state of accelerator pedal ac-
tuator
Reception unit Signal name Description
ABS actuator
and electric
unit (control
unit) CAN commu-
nication
Brake fluid pressure control signal Transmits a brake fluid pressure control signal to acti-
vates the brake
Revision: 2010 May2011 QX56

DAS-70
< SYSTEM DESCRIPTION >[DCA]
SYSTEM
FUNCTION DESCRIPTION
When a vehicle is detected ahead The vehicle ahead detection indicator comes ON.
When vehicle approaches a vehicle ahead If the driver is not depressing the accelerator pedal, t
he system activates the brakes to decelerate smoothly
as necessary. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limita-
tions of the system.
 If the driver is depressing the accelerator pedal, the system moves the accelerator pedal upward to assist
the driver to release the accelerator pedal.
When brake operation by driver is required The system alerts the driver by a warning chime and blinking the vehicle ahead detection indicator. If the
driver is depressing the accelerator pedal after the wa rning, the system moves the accelerator pedal upward
to assist the driver to switch to the brake pedal.
CAUTION:
If the vehicle ahead comes to a stan dstill, the vehicle decelerates to a standstill within the limitations
of the system. The system will release brake control wi th a warning chime once it judges the vehicle is
at a standstill. To prevent the vehicle from moving , the driver must depress the brake pedal. [The sys-
tem will resume control automatically once the system reaches 5 km/h (3 MPH)].
NOTE:
 Depending on the position of the accelerator pedal, the system may not be able to assist the driver to
release the accelerator pedal appropriately.
 When the driver depresses the accelerator pedal even further while the system is moving the acce\
lerator pedal upward, the accelerator pedal control will be canceled.
 When the driver is depressing the accelerator pedal, the brake control by the system is not operated.
 When the driver is depressing the brake pedal, neither the brake control nor the alert by the system oper-
ates.
 When the ICC system is set, the DCA system will be canceled.
OPERATION DESCRIPTION
ICC sensor calculates a distance from a vehicle ahead and a relative speed to transmit the ICC sensor signal
to the ADAS control unit via ITS communication. Based on the received signal, the ADAS control unit trans-
mits a control signal to the accelerator pedal actuator via ITS communication and to the ABS actuator control
unit (control unit) via CAN communication.
Combination
meter CAN commu-
nicationMeter display
signal
Vehicle ahead detec-
tion indicator signal
Transmits a signal to display a state of the system on
the information display
DCA system switch in-
dicator signal
ICC warning lamp signal Transmits an ICC warning lamp signal to turn ON the
ICC system warning lamp
Buzzer output signal Transmits a buzzer output signal to activate the buzz-
er
ICC sensor ITS commu-
nicationVehicle speed signal
Transmits a vehicle speed calculated by the ADAS
control unit
Steering angle sensor signal Transmits a steering angle sensor signal received
from the steering angle sensor
Accelerator
pedal actuator ITS commu-
nicationAccelerator pedal position signal
Transmits an accelerator pedal angle calculated by
the ADAS control unit
Accelerator pedal feedback force control
signal Transmits a target actuation force value calculated by
the ADAS control unit
ICC brake hold
relay ICC brake hold relay drive signal
Activates the brake hold relay and turns ON the stop
lamp
Reception unit Signal name Description
Revision: 2010 May2011 QX56

DAS
SYSTEMDAS-71
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Operation Condition
ADAS control unit performs the control when the following conditions are satisfied.
 When the DCA system setting on the navigation screen is ON.
 When the dynamic driver assistance switch is turned to ON.
 When the brake pedal is not depressed.
 When the vehicle speed is above approximately 5 km/h (3 MPH).
 When the vehicle ahead is detected.
 When the ICC system is not set.
No Operation Condition
The ADAS control unit is not operat e when the system is under any condi tions of the no operation condition.
 When the brake pedal depressed.
 When the ICC system is set.
 When the system judges that the vehicle co mes to a standstill by the system control.
 When the vehicle ahead is not detected.
Operation Cancellation Condition
The ADAS control unit cancels the operation when the syst em is under any conditions of the operation cancel-
lation condition.
 When the dynamic driver assistance switch is turned to OFF.
 When the system malfunction occurs.
 When ABS or VDC (including the TCS) operates.
 When the VDC is turned OFF.
 When the SNOW mode switch is turned ON.
 When the 4WD shift switch is turned to not AUTO position.
 When driving into a strong light (i.e., sunlight).
 When the ICC sensor body window is dirty and the measurement of the distance between the vehicles
becomes difficult.
Operation At The Driver Operation
Give priority to the driver operation in the following situation.
When vehicle approaches a vehicle ahead If the driver is not depressing the acceler-
ator pedal, the system activates the
brakes to decelerate smoothly as neces-
sary
If the driver is depressing the accelerator
pedal, the system moves the accelerator
pedal upward to assist the driver to re-
lease the accelerator pedal
When brake operation by driver is required The system alerts the driver by a warning
chime and blinking the vehicle ahead de-
tection indicator. If the driver is depressing
the accelerator pedal after the warning,
the system moves the accelerator pedal
upward to assist the driver to switch to the
brake pedal
Deceleration control It transmits the brake fluid
pressure control signal to the ABS actuator and electric unit (control unit) via
CAN communication and performs the brake control
Accelerator pedal actuation
control It transmits the accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS
communication and controls the accelerator pedal in the upward directionJSOIA0222ZZ
JSOIA0094ZZ
JPOIA0170GB
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-79
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
 It displays for up to 5 minutes and then stops.
 If multiple malfunctions exist, up to 6 DTCs can be stored in memory at the most, and the most recent
one is displayed first.
WHEN THE ON BOARD SELF-DIAGNOSIS DOES NOT START
If the on board self-diagnosis does not start, check the following items.
HOW TO ERASE ON BOARD SELF-DIAGNOSIS
1. Turn the ignition switch OFF.
2. Start the engine, and then start the on board self-diagnosis.
3. Press the CANCEL switch 5 times, and then press the DIS-
TANCE switch 5 times under the condition that the on board
self-diagnosis starts.
NOTE:
 Complete the operation within 10 seconds after pressing the
CANCEL switch first.
 If the operation is not completed within 10 seconds, repeat the procedure from step 1.
4. DTC 55 is displayed after erasing. NOTE:
DTCs for existing malfunction can not be erased.
5. Turn ignition switch OFF, and finish the diagnosis.
CONSULT-III Function (ICC/ADAS)INFOID:0000000006223507
APPLICATION ITEMS
CONSULT-III performs the following functions via CAN communication using ADAS control unit.
WORK SUPPORT
Assumed abnormal part Inspection item
Information display Combination meter malfunction Check that the self-diagnosis function of the combina-
tion meter operates. Refer to
MWI-29, "
On Board Diag-
nosis Function"
ICC steering switch malfunction
Perform the inspection for DTC“C1A06”. Refer to CCS-
94, "Diagnosis Procedure"Harness malfunction between ICC steering switch and ECM
ECM malfunction
ADAS control unit malfunction  Check power supply and ground circuit of ADAS con-
trol unit. Refer to DAS-62, "
Diagnosis Procedure".
 Perform SELF-DIAGNOSIS for “ICC/ADAS”with
CONSULT-III, and then check the malfunctioning
parts. Refer to DAS-38, "
DTC Index".
PKIB8373E
Diagnosis mode Description
Work Support Displays causes of automatic system cancellation occurred during system control
Self Diagnostic Result Displays the name of a malfunctioning system stored in the ADAS control unit
Data Monitor Displays ADAS control unit input/output data in real time
Active Test Enables an operational check of a load by transmitting a driving signal from the ADAS control unit to
the load
Ecu Identification Displays ADAS control unit part number
CAN Diag Support Monitor Displays a reception/transmission state of CAN communication and ITS communication
Revision: 2010 May2011 QX56

DAS-80
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
NOTE:
 Causes of the maximum five cancella
tions (system cancel) are displayed.
 The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to
254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.
Display Items for The Cause of Automatic Cancellation 1
Work support items Description
CAUSE OF AUTO-CANCEL 1 Displays causes of automatic system cancellation occurred during control of the following sys-
tems
 Vehicle-to-vehicle distance control mode
 Conventional (fixed speed) cruise control mode
 Distance Control Assist (DCA)
CAUSE OF AUTO-CANCEL 2 Displays causes of automatic system cancellation occurred during control of the Lane Depar-
ture Prevention (LDP) system
Cause of cancellation
Vehicle-to-vehicle distance control mode
Conventional (fixed speed) cruise control mode Distance Control Assist
Description
OPERATING WIPER ×The wiper operates at HI (it includes when the wiper is operated at
HI with the wiper switch AUTO position)
OPERATING ABS ××ABS function was operated
OPERATING TCS ×××TCS function was operated
OPERATING VDC ×××VDC function was operated
ECM CIRCUIT ××ECM did not permit ICC operation
OPE SW VOLT CIRC ×××The ICC steering switch input voltage is not within standard range
LASER SUNBEAM ××Intense light such as sunlight entered ICC sensor light sensing part
LASER TEMP ××Temperature around ICC sensor became low
SNOW MODE SW ××SNOW mode switch was pressed
OP SW DOUBLE
TOUCH ××
ICC steering switches were pressed at the same time
VHCL SPD DOWN ×××Vehicle speed lower than the speed as follows
 Vehicle-to-vehicle distance control mode is 24 km/h (15 MPH)
 Conventional (fixed speed) cruise control mode is 32 km/h (20
MPH)
WHL SPD ELEC NOISE ×××Wheel speed sensor signal caught electromagnetic noise
VDC/TCS OFF SW ××VDC OFF switch was pressed
VHCL SPD UNMATCH ×××Wheel speed became different from A/T vehicle speed
TIRE SLIP ××Wheel slipped
IGN LOW VOLT ×××Decrease in ADAS control unit IGN voltage
PARKING BRAKE ON ××The parking brake is operating
WHEEL SPD UNMATCH ×××The wheel speeds of 4 wheels are out of the specified values
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-81
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Display Items for The Cause of Automatic Cancellation 2
SELF DIAGNOSTIC RESULT
Refer to DAS-38, "DTC Index".
DATA MONITOR
INCHING LOST ×A vehicle ahead is not detected during the following driving when
the vehicle speed is approximately 24 km/h (15 MPH) or less
CAN COMM ERROR ×××ADAS control unit received an abnormal signal with CAN commu-
nication
ABS/TCS/VDC CIRC ×××An abnormal condition occurs in VDC/TCS/ABS system
ECD CIRCUIT ×××An abnormal condition occurs in ECD system
ASCD VHCL SPD DTAC ×Vehicle speed is detached from set vehicle speed
ASCD DOUBLE COMD ×Cancel switch and operation switch are detected simultaneously
APA HI TEMP ×The accelerator pedal actuator integrated motor temperature is
high
ICC SENSOR CAN
COMM ERR ××Communication error between ADAS control unit and the ICC sen-
sor
4WD LOCK MODE ×××Shifting of the 4WD shift switch to 4H or 4L
ABS WARNING LAMP ××ABS warning lamp ON
NO RECORD ××× —
Cause of cancellation Description
OPE VDC/TCS/ABS 1 The activation of VDC, TCS, or ABS during LDP system control
Vehicle dynamics Vehicle behavior exceeds specified value
Steering speed Steering speed was more than the specified value in evasive direction
End by yaw angle Yaw angle was the end of LDP control
Departure yaw large Detected more than the specified value of yaw angle in departure direction
ICC WARNING Target approach warning of ICC system, IBA system or FCW system was activated
CURVATURE Road curve was more than the specified value
Steering angle large Steering angle was more than the specified value
Brake is operated Brake pedal was operated
IGN LOW VOLT Decrease in ADAS control unit IGN voltage
Lateral offset Distance of vehicle and lane was detached in lateral direction more than the specified value
Lane marker lost Lane camera unit lost the trace of lane marker
Lane marker unclear Detected lane marker was unclear
Yaw acceleration Detected yawing speed was more than the specified value
Deceleration large Deceleration in a longitudinal direction was more than the specified value
Accel is operated Accelerator pedal was depressed
Departure steering Steering wheel was steered more than the specified value in departure direction
Evasive steering Steering wheel was steered more than the specified value in the evasive direction
R range Selector lever was operated to R range
Parking brake drift Rear wheels lock was detected
Not operating condition Did not meet the operating condition (vehicle speed, turn signal operation, etc)
SNOW MODE SW SNOW mo de switch was pressed
VDC OFF SW VDC OFF switch was pressed
OPE VDC/ABS 2 The activation of VDC or ABS duri ng a standby time of LDP system control
4WD LOCK MODE Shifting of the 4WD shift switch to 4H or 4L
NO RECORD —
Revision: 2010 May2011 QX56

DAS-84
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
LDP SYSTEM ON
[On/Off]×
Indicates [On/Off] status of LDP system
WARN REQ
[On/Off] ×
Indicates an ADAS control unit judged warning state (ON/OFF) of LDP system
READY signal
[On/Off] ×
Indicates LDP system settings
Camera lost
[Detect/Deviate/Both] ××Indicates a lane marker detection state judged from a lane marker detection signal
read by the ADAS control unit via ITS communication
(Lane camera unit transmits a lane marker signal via ITS communication)
Shift position
[Off, P, R, N, D, M/T1 -
7] ××
Indicates shift position read from ADAS control unit through CAN communication
(TCM transmits shift position signal through CAN communication)
Turn signal
[OFF/LH/RH/LH&RH] ××Indicates turn signal operation status read from ADAS control unit through CAN
communication (BCM transmits turn indicator signal through CAN communica-
tion)
SIDE G
[G] ××Indicates lateral G acting on the vehicle. This lateral G is judged from a side G
sensor signal read by ADAS control unit via CAN communication
(The ABS actuator and electric unit (control unit) transmits a side G sensor signal
via CAN communication)
STATUS signal
[Stnby/Warn/Cancl/
Off] ×
Indicates a control state of LDP system
Lane unclear
[On/Off] ××Indicates an ON/OFF state of the lane marker. The ON/OFF state is judged from
a detected lane condition signal read by the ADAS control unit via ITS communi-
cation
(The lane camera unit transmits a detected lane condition signal via ITS commu-
nication)
FUNC ITEM
[FUNC1] ×× × × Indicates systems which can be set to ON/OFF by selecting “Driver Assistance”
⇒
“Dynamic Assistance Settings” of the navigation system
FUNC1: Distance Control Assist (DCA), Lane Departure Prevention (LDP)
FUNC ITEM (NV-ICC)
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
FUNC ITEM (NV-
DCA)
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
DCA SELECT
[On/Off] ×× × × Indicates an ON/OFF state of the DCA system. The DCA system can be set to
ON/OFF by selecting
“Driver Assistance” ⇒ “Dynamic Assistance Settings” of the
navigation system
LDP SELECT
[On/Off] ×× × × Indicates an ON/OFF state of LDP system. LDP system can be set to ON/OFF by
selecting “Driver Assistance”
⇒ “Dynamic Assistance Settings” of the navigation
system
BSI SELECT
[On/Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI ICC SELECT
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI DCA SELECT
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
SYS SELECTABILITY
[On/Off] ×× × × Indicates the availability of ON/OFF switching for “Driver Assistance” items re-
ceived from the AV control unit via CAN communication
WARN SYS SW
[On/Off] ×× × ×
Indicates [On/Off] status of warning systems switch
BSW/BSI WARN LMP
[On/Off] ×
Indicates [On/Off] status of BSW warning lamp output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56

DAS-86
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
STOP LAMP
ICC BUZZER
BRAKE ACTUATOR
NOTE:
The test can be performed only when the engine is running.
NOTE:
The test is finished in 10 seconds after starting
Te s t i t e mOper-
ation Description  MAIN switch indicator
 ICC system warning lamp
 IBA OFF indicator lamp
METER LAMP Off
Stops sending the following signals to exit from the test
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal OFF
On Transmits the following signals to the combination meter via
CAN communication
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal
ON
Te s t i t e m
Oper-
ation Description Stop lamp
STOP LAMP Off
Stops transmitting the ICC brake hold relay drive signal be-
low to end the test OFF
On Transmits the ICC brake hold relay drive signal ON
Test item Operation Description ICC warning chime operation
sound
ICC BUZZER MODE1
Transmits the buzzer output signals to the combination
meter via CAN communication Intermittent beep sound
Test start Starts the tests of “MODE1” — Reset Stops transmitting the buzzer output signal below to end
the test —
End Returns to the “SELECT TEST ITEM” screen —
Test item Operation Description “PRESS SENS” value
BRAKE ACTUATOR MODE1
Transmits the brake fluid pressure control signal to the
ABS actuator and electric unit (control unit) via CAN
communication 10 bar
MODE2 20 bar
MODE3 30 bar
Test start Starts the tests of “MODE1”, “MODE2” and “MODE3” —
Reset Stops transmitting the brake fluid pressure control signal
below to end the test —
End Returns to the “SELECT TEST ITEM” screen —
PKIB1767J
Revision: 2010 May2011 QX56
