TM-152
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
MAIN POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEM (PART 1)
Check the following.
 Harness for short or open between battery positive term inal and A/T assembly vehicle side harness connec-
tor terminal 2. Refer to PG-11, "
Wiring Diagram - BATTERY POWER SUPPLY -".
Battery
 10A fuse (No.38, located in the fuse, fusible link and relay box). Refer to PG-141, "
Fuse and Fusible Link
Arrangement".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
7.CHECK HARNESS BETWEEN IPDM E/ R AND A/T ASSEMBLY (PART 1)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R vehicle side harness connector terminal and A/T assembly vehicle
side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace damaged parts.
8.CHECK HARNESS BETWEEN IPDM E/ R AND A/T ASSEMBLY (PART 2)
Check continuity between A/T assembly vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace damaged parts.
9.DETECT MALFUNCTIONING ITEM (PART 2)
Check the following.
 Harness for short or open between ignition switch and IPDM E/R. Refer to PG-89, "
Wiring Diagram - IGNI-
TION POWER SUPPLY -".
 Ignition switch
 10A fuse (No.55, located in the IPDM E/R). Refer to PG-143, "
Fuse, Connector and Terminal Arrangement".
 IPDM E/R
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
IPDM E/R vehicle side harness connector A/T assembly vehicle side harness connector Continuity
Connector Terminal Connector Terminal
E15 57 F51 1
Existed
6
A/T assembly vehicle side harness connector
GroundContinuity
Connector Terminal
F51 1
Not existed
6
Revision: 2010 May2011 QX56

SHIFT LOCK SYSTEMTM-157
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM
Component Function CheckINFOID:0000000006226882
1.CHECK A/T SHIFT LOCK OPERATION (PART 1)
1. Turn ignition switch ON.
2. Shift the selector lever to “P” position.
3. Attempt to shift the selector lever to any other position with the brake pedal released.
Can the selector lever be shifted to any other position?
YES >> Go to TM-157, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK A/T SHIFT LOCK OPERATION (PART 2)
Attempt to shift the selector lever to any other position with the brake pedal depressed.
Can the selector lever be shifted to any other position?
YES >> INSPECTION END
NO >> Go to TM-157, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006226883
1. CHECK POWER SOURCE
1. Turn ignition switch OFF.
2. Disconnect fuse block (J/B) connector.
3. Turn ignition switch ON.
4. Check voltage between fuse block (J/B) connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following.  10A fuse [No. 3, located in fuse block (J/B)]. Refer to PG-140, "
Fuse, Connector and Terminal
Arrangement".
 Harness for short or open between ignition switch and fuse block (J/B). Refer to PG-89, "
Wiring
Diagram - IGNITION POWER SUPPLY -".
 Ignition switch
2.CHECK HARNESS BETWEEN FUSE BLOCK (J/B ) AND STOP LAMP SWITCH (PART 1)
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Check continuity between fuse block (J/B) vehicl e side harness connector terminal and stop lamp switch
vehicle side harness connector terminal.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN FUSE BLOCK (J/B ) AND STOP LAMP SWITCH (PART 2)
Check continuity between stop lamp switch vehicle side harness connector terminal and ground.
Fuse block (J/B) connector
GroundVoltage (Approx.)
Connector Terminal
E103 4F Battery voltage
Fuse block (J/B) vehicle side harness connector Stop lamp switch vehicle side harness connector Continuity
Connector Terminal Connector Terminal
E103 4F E115 3 Existed
Revision: 2010 May2011 QX56

SHIFT LOCK SYSTEMTM-159
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
10.CHECK INSTALLATION POSITION OF STOP LAMP SWITCH
Adjust stop lamp switch position. Refer to BR-7, "
Inspection and Adjustment".
>> GO TO 11.
11 .CHECK STOP LAMP SWITCH (PART 2)
Check stop lamp switch. Refer to TM-159, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace stop lamp switch. Refer to BR-20, "
Exploded View".
Component Inspection (Stop Lamp Switch)INFOID:0000000006226884
1.CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to BR-20, "
Exploded View".
Component Inspection (Park Position Switch)INFOID:0000000006226885
1.CHECK PARK POSITION SWITCH
Check continuity between A/T shif t selector connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace A/T shift selector assembly. Refer to TM-176, "
Exploded View".
Component Inspection (Shift Lock Solenoid)INFOID:0000000006226886
1.CHECK SHIFT LOCK SOLENOID
Apply voltage to A/T shift selector connector terminals and check that shift lock solenoid is activated.
CAUTION:
Connect the fuse between the termina ls when applying the voltage.
Stop lamp switch connector
Condition Continuity
Te r m i n a l
34 Depressed brake pedal Existed
Released brake pedal Not existed
A/T shift selector connector
Condition Continuity
Te r m i n a l
11 1 2 Selector lever in
“P” position. Existed
Other than the above. Not existed
A/T shift selector connector Condition Status
Te r m i n a l
+ (fuse) –
11 1 2  Selector lever in
“P” position.
 Apply 12 V direct current between terminals 11 and 12. Shift lock solenoid operates
Revision: 2010 May2011 QX56

SELECTOR LEVER POSITION INDICATORTM-163
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or replace damaged parts.
9.CHECK POWER SOURCE (PART 2)
1. Turn ignition switch OFF.
2. Disconnect A/T shift selector connector.
3. Turn ignition switch ON.
4. Check voltage between A/T shift selector vehicle side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Check illumination circuit. Refer to INL-34, "
Wiring Diagram".
10.CHECK SHIFT POSITION SWITCH (PART 2)
1. Disconnect shift position switch connector.
2. Check continuity between A/T shift selector connec tor terminals and shift position switch connector termi-
nals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
Component Inspection (Selecto r Lever Position Indicator)INFOID:0000000006226889
1.CHECK SELECTOR LEVER POSITION INDICATOR
Check that selector lever position indicator lamps turn on.
CAUTION:
Connect the fuse between the termina ls when applying the voltage.
A/T shift selector vehicle side harness connector
Condition Voltage (Approx.)
Connector Te r m i n a l
+ −
M57 9 10 Lighting switch 1ST Battery voltage
A/T shift selector connector Shift position switch connector Continuity
Connector Terminal Connector Terminal
M57 9
M281 9Existed
1, 2, 3, 4, 5, 8, 10, 12 Not existed
10 8Existed
1, 2, 3, 4, 5, 9, 10, 12 Not existed
Shift position switch harness connector Condition Status
Te r m i n a l
+ (fuse) −
110 Apply 12 V direct current between
terminals 1 and 10.
“M” mode indicato
r lamp turns on.
2
12Apply 12 V direct current between
terminals 2 and 12.
“P” position indicator lamp turns on.
3 Apply 12 V direct current between
terminals 3 and 12. “R” position indica
tor lamp turns on.
4 Apply 12 V direct current between
terminals 4 and 12.
“D” position indica
tor lamp turns on.
5 Apply 12 V direct current between
terminals 5 and 12. “N” position indica
tor lamp turns on.
98 Apply 12 V direct current between
terminals 9 and 8. Illumination lamp turns on.
Revision: 2010 May2011 QX56

WCS
POWER SUPPLY AND GROUND CIRCUITWCS-39
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
DTC/CIRCUIT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000006222743
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between combination meter harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between combination meter and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between combination meter harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
Power source Fuse No.
Battery 11
Ignition switch ON or START 3
Te r m i n a l s
Ignition switch po-sition Vo l ta g e
(Approx.)
(+) (
−)
Combination meter
Ground
Connector Terminal
M34 1OFF
Battery voltage
2ON
Combination meter
GroundContinuity
Connector Terminal
M34 3
Existed
23
Revision: 2010 May2011 QX56

POWER SUPPLY AND GROUND CIRCUITWT-51
< DTC/CIRCUIT DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000006225530
1.CHECK FUSE/FUSIBLE LINK
1. Turn the ignition switch OFF.
2. Check for fusing of the fuse and fusible link at the low tire pressure warning control unit.
- Check the 10 A fuse [No. 3 in fuse block (J/B)]
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-detected parts.
2.CHECK LOW TIRE PRESSURE WARNING CONTROL UNIT POWER SUPPLY CIRCUIT
1. Disconnect the low tire pressure warning control unit harness connector.
2. Turn the ignition switch ON. CAUTION:
Never start engine.
3. Check the voltage between the low tire pressure warning control unit and ground.
4. Turn the ignition switch OFF.
5. Check the voltage between the low tire pressure warning control unit and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the following. If any items are damaged, repair or replace damaged parts.  Harness for short or open between ignition switch and low tire pressure warning control unit har-ness connector
 Battery voltage.
3.CHECK LOW TIRE PRESSURE WARNI NG CONTROL UNIT GROUND CIRCUIT
1. Turn the ignition switch OFF.
2. Check the continuity between the low tire pressure warning control unit harness connector and ground.
- Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
Low tire pressure warning control unit —Voltage
Connector Terminal
M96 15 Ground Battery voltage
Low tire pressure warning control unit —Voltage
Connector Terminal
M96 15 Ground 0 V
Low tire pressure warning control unit —Continuity
Connector Terminal
M96 32 Ground Existed
Revision: 2010 May2011 QX56

TPMS SYMPTOMSWT-55
< SYMPTOM DIAGNOSIS >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
NOTE:
If transmitter wake-up operation is not completed for tw o or more transmitters, the applicable low tire pressure
warning lamp blinking patterns are displayed continuously.
(Example: Blinks once/OFF/blinks 3 times = Wake-up operation is not completed at the front LH wheel and
rear RH wheel transmitters.)
Low tire
pressure
warning
lamp The low tire pressure
warning lamp repeats
blinking at 0.5-second
intervals for 1 minute,
and then stays illumi-
nated. The combination meter fuse
is open or removed (or
pulled out).
Check and install the com-
bination meter fuse. If nec-
essary, replace the fuse.
The low tire pr essure warn-
ing control unit harness
connector is removed. Check the connection con-
ditions of the low tire pres-
sure warning
control unit
harness connector, and re-
pair if necessary.
Tire Pressure Monitoring
System (TPMS) malfunc-
tion.  Perform self-diagnosis.
- If necessary, perform
transmitter ID registra-
tion. Refer to WT-29,
"Work Procedure".
Hazard
warning
lamp The hazard warning
lamp does not blink
twice when the trans-
mitter is activated.
— The transmitter activation
tool does not activate.  Replace the battery in the
transmitter activation
tool.
 The ignition switch is OFF when the transmitter
wake-up operation is per-
formed.  Turn the ignition switch
ON when performing the
transmitter wake-up op-
eration.
 The transmitter activation tool is not used in the cor-
rect position.  Operate the transmitter
activation tool in the cor-
rect position when per-
forming the wake-up
operation.
 The transmitter is already waked up.  No procedure.
Diagnosis
items Symptom
(Ignition switch ON) Low tire pressure wa
rning lamp Cause Action
SEIA0788E
Revision: 2010 May2011 QX56

WW-1
DRIVER CONTROLS
C
DE
F
G H
I
J
K
M
SECTION WW
A
B
WW
N
O P
CONTENTS
WIPER & WASHER
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
3
Precaution for Procedure without Cowl Top Cover ......4
SYSTEM DESCRIPTION ..............................5
COMPONENT PARTS ................................... .....5
Component Parts Location .................................. ......5
Component Description ............................................6
Washer Switch ..........................................................6
SYSTEM ..............................................................7
FRONT WIPER AND WASHER SYSTEM ............. ......7
FRONT WIPER AND WASHER SYSTEM : Sys-
tem Diagram ..............................................................
7
FRONT WIPER AND WASHER SYSTEM : Sys-
tem Description .........................................................
7
FRONT WIPER AND WASHER SYSTEM : Fail-
safe ...........................................................................
9
REAR WIPER AND WASHER SYSTEM ............... ....10
REAR WIPER AND WASHER SYSTEM : System
Diagram ...................................................................
10
REAR WIPER AND WASHER SYSTEM : System
Description ..............................................................
10
REAR WIPER AND WASHER SYSTEM :
Fail Safe .................................................................
12
HEADLAMP WASHER SYSTEM .......................... ....12
HEADLAMP WASHER SYSTEM : System Dia-
gram ........................................................................
13
HEADLAMP WASHER SYSTEM : System De-
scription ...................................................................
13
DIAGNOSIS SYSTEM (BCM) ............................14
COMMON ITEM ..................................................... ....14
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .....................................................
14
WIPER .................................................................... ....15
WIPER : CONSULT-III Function (BCM - WIPER) ....15
DIAGNOSIS SYSTEM (IPDM E/R) ...................18
Diagnosis Description ..............................................18
CONSULT-III Function (IPDM E/R) .........................20
ECU DIAGNOSIS INFORMATION ..............23
BCM, IPDM E/R .................................................23
List of ECU Reference ......................................... ....23
WIRING DIAGRAM ......................................24
WIPER AND WASHER SYSTEM .....................24
Wiring Diagram .................................................... ....24
BASIC INSPECTION ...................................33
DIAGNOSIS AND REPAIR WORKFLOW ........33
Work Flow ............................................................ ....33
DTC/CIRCUIT DIAGNOSIS .........................35
WIPER AND WASHER FUSE ...........................35
Diagnosis Procedure ........................................... ....35
FRONT WIPER MOTOR LO CIRCUIT ..............36
Component Function Check ....................................36
Diagnosis Procedure ...............................................36
FRONT WIPER MOTOR HI CIRCUIT ...............37
Component Function Check ....................................37
Diagnosis Procedure ...............................................37
FRONT WIPER AUTO STOP SIGNAL CIR-
CUIT ..................................................................
38
Component Function Check ....................................38
Diagnosis Procedure ...............................................38
Revision: 2010 May2011 QX56
