 The ambient sensor input value that is displayed on “Data Monitor” of CONSULT-III is the value before the
correction. It may not match the indica ted temperature on the information display.
 After removal and installation of the battery and comb ination meter, an ambient sensor-detected tempera-
ture is indicated on the information display.
 Depending on engine heat or heat on the road surfaces, an ambient temperature may be indicated higher
than actual one.
INTERRUPT INDICATION
 The combination meter displays an interrupt regarding a warning, alert, and maintenance on the information
display, based on signals received from each unit and switch.
 When conditions are satisfied, the normal screen swit ches to a warning screen to display an interrupt.
Door Open Warning
 When all the following operating conditions are satisfied, the combination meter displays a door open warn-
ing on the information display by an interrupt.
 The combination meter judges showing/hiding of “door open warning”, according to the signals below:
Parking Brake Release Warning
 When all the following operating conditions are satisfi ed, the combination meter displays a parking brake
release warning on the information display by an interrupt.
 The combination meter judges showing/hiding of “parki ng brake release warning”, according to the signals
below:
Low Fuel Warning
 When all the following operating conditions are satisfied, the combination meter displays a low fuel warning on the information display by an interrupt.
*: With the vehicle in a horizontal position
 The combination meter judges showing/hiding of “low fuel warning”, according to the signals below:
Operating condition
Ignition switch ON
Door Any door is open
Signal name Signal path
Ignition signal —
Door switch signal Door switch BCM Combination meter
Operating condition
Ignition switch ON
Parking brake Applied
Vehicle speed 7 km/h (4.3 MPH) or more
Signal name Signal path
Ignition signal —
Parking brake switch signal Parking brake switch Combination meter
Vehicle speed signal ABS actuator and electric unit (control unit) Combination meter
Operating condition
Ignition switch ON
Fuel remaining quantity
*Approximately 15.4 (4 US gal, 3-3/8 Imp gal) or less (including fuel remained)
Revision: 2010 May2011 QX56

MWI-24
< SYSTEM DESCRIPTION >
SYSTEM
Low Washer Fluid Warning
 When all the following operating conditions are satisfied, the combination meter displays a low washer fluid
warning on the information display by an interrupt.
 The combination meter judges showing/hiding of “low washer fluid warning”, according to the signals below:
Travel Time (Alert)
 When all the following operating conditions are satisfied, the combination meter displays a travel time on the
information display by an interrupt.
 The combination meter judges showing/hiding of “travel time”, according to the signals below:
Low Ambient Temperature (Alert)
 When all the following operating conditions are satisfied, the combination meter displays a low ambient tem-
perature on the information display by an interrupt.
 The combination meter judges showing/hiding of “low ambient temperature”, according to the signals below:
Signal name Signal path
Ignition signal —
Fuel level sensor signal Fuel level sensor Combination meter
Operating condition
Ignition switch ON
Washer level switch Decrease in fluid level (washer level switch ON for 180 seconds or more)
JSNIA0033GB
Signal name Signal path
Ignition signal —
Washer level switch signal Washer level switch Combination meter
Operating condition
Ignition switch Switch-ON time
Signal name Signal path
Ignition signal —
Operating condition
Ignition switch ON
ambient temperature 3
°C (37 °F) or less
information display “ON” is selected in “SETTING”
Revision: 2010 May2011 QX56

MWI
SYSTEMMWI-25
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
Tire (Maintenance) When all the following operating conditions are satisfied, the combination meter displays a tire warning on
the information display by an interrupt.
 The combination meter judges showing/hiding of “tire warning”, according to the signals below:
Oil Filter (Maintenance)
 When all the following operating conditions are satisfied, the combination meter displays an oil filter warning on the information display by an interrupt.
 The combination meter judges showing/hiding of “oil filter warning”, according to the signals below:
Engine Oil (Maintenance)
 When all the following operating conditions are satisfied, the combination meter displays an engine oil warn-
ing on the information display by an interrupt.
 The combination meter judges showing/hiding of “engine oil warning”, according to the signals below:
Other (Maintenance)
 When all the following operating conditions are satisfied, the combination meter displays an other warning on the information display by an interrupt.
Signal name Signal path
Ignition signal —
Ambient sensor signal Ambient sensor Combination meter
Operating condition
Ignition switch ON
Mileage More than value set in “SETTING”
Signal name Signal path
Ignition signal —
Vehicle speed signal ABS actuator and electric unit (control unit) Combination meter
Operating condition
Ignition switch ON
Mileage More than value set in “SETTING”
Signal name Signal path
Ignition signal —
Vehicle speed signal ABS actuator and electric unit (control unit) Combination meter
Operating condition
Ignition switch ON
Mileage More than value set in “SETTING”
Signal name Signal path
Ignition signal —
Vehicle speed signal ABS actuator and electric unit (control unit) Combination meter
Revision: 2010 May2011 QX56

MWI
DIAGNOSIS SYSTEM (COMBINATION METER)
MWI-33
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
K L
M B A
O P
*: DDS (hill descent control) NOTE:
Some items are not available according to vehicle specification.
SPECIAL FUNCTION
Special menu
W/L ON HISTORY
 Stores histories when warning/indicator lamp is turned on.
 “W/L ON HISTORY” indicates the “TIME” when the warning/ indicator lamp is turned on.
 The “TIME” above is:
- 0: The condition that the warning/indicator lamp has been turned on 1 or more times after starting the engine and waiting for 30 seconds.
- 1 - 39: The number of times the engine was restarted after the 0 condition.
- NO W/L ON HISTORY: Stores NO (0) turning on history of warning/indicator lamp.
NOTE:
 W/L ON HISTORY is not stored for approximately 30 seconds after the engine starts.
 Brake warning lamp does not store any history when the parking brake is applied or the brake fluid level gets
low.
Display Item
AT SFT DWN SW
[On/Off] Status of manual mode shift down switch.
PKB SW
[On/Off] Status of parking brake switch.
BUCKLE SW
[On/Off] Status of seat belt buckle switch (driver side).
BRAKE OIL SW
[On/Off] Status of brake fluid level switch.
A/C AMP CONN
[Off] This item is displayed, but cannot be monitored.
ENTER SW
[On/Off] Status of (ENTER) switch.
SELECT SW
[On/Off] Status of (SELECT) switch.
DISTANCE
[km] Value of distance to empty calculated by combination meter.
OUTSIDE TEMP
[ ° C or °F] Ambient temperature value converted from ambient sensor signal received from
ambient sensor.
NOTE:
This may not match with the temperature value indicated on the information dis-
play. (Because the information display value is a corrected value from the ambient
sensor input value.)
FUEL LOW SIG
[On/Off] Status of fuel level low warning signal to output to AV control unit via CAN com-
munication.
TOW MODE IND
[On/Off] Status of TOW mode indicator lamp judged from TOW mode indicator lamp signal
received from TCM with CAN communication line.
BUZZER
[On/Off] XBuzzer status (in the combination meter) is detected from the buzzer output signal
received from each unit via CAN communication and the warning output condition
of the combination meter.
Display item [Unit]
MAIN
SIGNALS Description
Display item Description
W/L ON HISTORY Lighting history of warning lamp and indicator lamp can be checked.
Revision: 2010 May2011 QX56

MWI
COMBINATION METERMWI-35
< ECU DIAGNOSIS INFORMATION >
C
DE
F
G H
I
J
K L
M B A
O P
ECU DIAGNOSIS INFORMATION
COMBINATION METER
Reference ValueINFOID:0000000006221721
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Condition Value/Status
SPEED METER
[km/h] Ignition switch
ON
While driving Input value of vehicle speed signal
(CAN communication signal)
NOTE:
655.35 is displayed when the malfunc-
tion signal is received
SPEED OUTPUT
[km/h] Ignition switch
ON
While driving Output value of vehicle speed signal
(CAN communication signal)
NOTE:
655.35 is displayed when the malfunc-
tion signal is received
ODO OUTPUT
[km/h or mph] Ignition switch
ON
—Output value of odometer signal (CAN
communication signal)
TACHO METER
[rpm] Ignition switch
ON
Engine running Input value of engine speed signal
(CAN communication signal)
NOTE:
8191.875 is displayed when the mal-
function signal is received
FUEL METER
[L] Ignition switch
ON
— Input value of fuel level sensor signal
W TEMP METER
[ ° C] Ignition switch
ON
—Input value of engine coolant tempera-
ture signal (CAN communication sig-
nal)
NOTE:
215 is displayed when the malfunction
signal is input
ABS W/L Ignition switch
ONABS warning lamp ON On
ABS warning lamp OFF Off
VDC/TCS IND Ignition switch
ONVDC OFF indicator lamp ON On
VDC OFF indicator lamp OFF Off
SLIP IND Ignition switch
ONVDC warning lamp ON On
VDC warning lamp OFF Off
BRAKE W/L Ignition switch
ONBrake warning lamp ON On
Brake warning lamp OFF Off
DOOR W/L Ignition switch
ONDoor open warning ON On
Other than the above Off
HI-BEAM IND Ignition switch
ONHigh-beam indicator lamp ON On
High-beam indicator lamp OFF Off
TURN IND Ignition switch
ONTurn signal indicator lamp ON On
Turn signal indicator lamp OFF Off
FR FOG IND Ignition switch
ONNOTE:
This item is displayed, but cannot be moni-
tored.
Off
RR FOG IND Ignition switch
ONNOTE:
This item is displayed, but cannot be moni-
tored.
Off
Revision: 2010 May2011 QX56

MWI-40
< ECU DIAGNOSIS INFORMATION >
COMBINATION METER
11
(G) Ground Enter switch signal Input Ignition
switch
ONWhen switch (enter
switch) is pressed
0 V
Other than the above 5 V
12
(O) Ground Select switch signal Input Ignition
switch
ONWhen switch (select
switch) is pressed
0 V
Other than the above 5 V
13
(W/R) Ground
Illumination control switch
signal (+) InputIgnition
switch
ON When switch [illumi-
nation control sw
itch (+)] is
pressed 0 V
Other than the above 5 V
14
(R) Ground Illumination control switch
signal (
−) InputIgnition
switch
ON When switch [illumi-
nation control switch (
−)] is
pressed 0 V
Other than the above 5 V
15
(R/W) Ground Air bag signal Input Ignition
switch
ONAir bag warning lamp
ON
4 V
Air bag warning lamp
OFF 0 V
18
(W/R) Ground Ambient sensor signal Input — —
19
(V/W) Ground A/C auto amp. connection
recognition signal Input —When A/C auto amp. is
connected
5 V
Other than the above 0 V
20
(B) Ground Ambient sensor ground — Ignition
switch
ON—0 V
21
(L) —CAN-H — — — —
22
(P) —CAN-L — — — —
23
(B) Ground Ground — Ignition
switch
ON
—0 V
24
(V) Ground Fuel level sensor ground — Ignition
switch
ON—0 V
25
(O/L) Ground Alternator signal Input Ignition
switch
ONCharge warning lamp ON 2 V
Charge warning lamp OFF Battery voltage
26
(W) Ground Parking brake switch signal Input Ignition
switch
ONParking brake applied 0 V
Parking brake released 12 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
JSNIA0014GB
Revision: 2010 May2011 QX56

MWI
COMBINATION METERMWI-41
< ECU DIAGNOSIS INFORMATION >
C
DE
F
G H
I
J
K L
M B A
O P
28
(GR/R) Ground Security signal Input Ignition
switch
ONSecurity indicator lamp ON 0 V
Security indicator lamp
OFF
12 V
29
(BR) Ground Washer level switch signal Input Ignition
switch
ONWasher level switch ON 0 V
Washer level switch OFF 5 V
30
(SB) Ground
Vehicle speed signal
(2-pulse) OutputIgnition
switch
ON Speedometer operated
[When vehicle speed is ap-
prox. 40 km/h (25 MPH)] NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).
31
(BR/W) GroundVehicle speed signal
(8-pulse)
OutputIgnition
switch
ONSpeedometer operated
[When vehicle speed is ap-
prox. 40 km/h (25 MPH)] NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).
33
(W) Ground SNOW mode signal Input Ignition
switch
ONWhen SNOW mode switch
is pressed
12 V
Other than the above 0 V
34
(BR/Y) Ground Fuel level sensor signal Input Ignition
switch
ON
—
35
(O/B) Ground Seat belt buckle switch sig-
nal (driver side)
InputIgnition
switch
ON When driver side belts is
fastened
12 V
When driver side belts is
unfastened 0 V
36
(G/Y) Ground Passenger seat belt warn-
ing signal
InputIgnition
switch
ON  When driver side seat
belt fastened
 When getting in the pas- senger seat
 When passenger seat belt fastened 12 V
 When driver side seat belt fastened
 When getting in the pas- senger seat
 When passenger seat belt unfastened 0 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
JSNIA0015GB
JSNIA0012GB
JSNIA3013ZZ
Revision: 2010 May2011 QX56

MWI
B2205 VEHICLE SPEEDMWI-61
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
B2205 VEHICLE SPEED
DescriptionINFOID:0000000006221734
Vehicle speed signal is transmitted from ABS actuator and electric unit (control unit) via CAN communication
to combination meter.
DTC LogicINFOID:0000000006221735
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000006221736
1.PERFORM SELF-DIAGNOSIS OF ABS ACTUAT OR AND ELECTRIC UNIT (CONTROL UNIT)
Perform “Self Diagnostic Result” of ABS actuator and electric unit (control unit), and repair or replace malfunc-
tioning parts.
>> Refer to BRC-51, "
DTC Index".
DTCDisplay contents of
CONSULT-III Diagnostic item is detected when... Probable malfunction location
B2205 VEHICLE SPEED An abnormal vehicle speed signal is input
from ABS actuator and electric unit (control
unit) for 2 seconds or more  Wheel sensor
 ABS actuator and electric
unit (control unit)
Revision: 2010 May2011 QX56
