2011 HONDA FIT Owners Manual

Page 313 of 356

HONDA FIT 2011 2.G Owners Manual Checking and Replacing Fuses
If something electrical in your
vehicle stops working, check for a
blown fuse first. Determine from the
chart on pages 311 and 312, or the
diagram on the fuse label, whic

Page 314 of 356

HONDA FIT 2011 2.G Owners Manual 5. Look for a blown wire inside thefuse. If it is blown, replace it with
one of the spare fuses of the same
rating or lower.
If you cannot drive the vehicle
without fixing the problem, and you
do not

Page 315 of 356

HONDA FIT 2011 2.G Owners Manual INTERIOR FUSE BOXNo. Amps. Circuits Protected1 10 A Back Up
2 (7.5 A) TPMS

3 20 A Drivers Power Window 4  Not Used
5 10 A Back Up Light
6 10 A SRS
7 (10 A) Transmission SOL

8 7.5 A SRS
9 (20

Page 316 of 356

HONDA FIT 2011 2.G Owners Manual No. Amps. Circuits Protected49 (15 A) Door Lock
50 (15 A) Door Lock
51 10 A Passengers Side Headlight High Beam
52 15 A DBW 53  Not Used
54 20 A Rear Defogger

55 10 A Heated Mirror
56 30 A Fron

Page 317 of 356

HONDA FIT 2011 2.G Owners Manual If your vehicle needs to be towed,
call a professional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is verydangerous.
There are two ways to tow your vehicle:

Page 318 of 356

HONDA FIT 2011 2.G Owners Manual Trying to lift or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicles weight.
The steering system can be damaged if
the steering wheel is

Page 319 of 356

HONDA FIT 2011 2.G Owners Manual 3. Screw the towing hook into thebolt hole behind the bumper, then
tighten the hook securely with theextension.
To avoid damage to your vehicle, use
the towing hook for straight, flat
ground towing

Page 320 of 356

HONDA FIT 2011 2.G Owners Manual 316
Main MenuTable of Contents
