2011 HONDA CR-Z check engine

Contents
Quick Reference GuideP. 2
Safe DrivingP. 29
Instrument Panel P. 67
ControlsP. 97
FeaturesP. 135
DrivingP. 191
MaintenanceP. 237
Handling the UnexpectedP. 285
InformationP. 311
IndexP. 323
Child Safety P. 56 Exhaust Gas Hazard P. 64 Safety Labels P. 65Opening and Closing the Hatch P. 104 Security System P. 105 Opening and Clos ing the Windows P. 107
Adjusting the Mirror P. 118 Adjusting the Seats P. 119
Climate Control System P. 131
Audio with Navigation System P. 151 Audio Error Messages P. 167 Audio Rem ote Controls P. 169
Bluetooth ®
HandsFreeLink ®
P. 173
When Driving P. 197 Braking P. 219 Parking Your Vehicle P. 223 Accessories and Modifications P. 235
Maintenance Under the Hood P. 245 Replacing Light Bulbs P. 258
Checking and Maintaining Tires P. 269 12 Volt Battery P. 278 Remote Trans mitter Care P. 279
Cleaning P. 281
Engine Does Not Start P. 293 Jump Starting P. 294 Shift Lever Does Not Move P. 296 Fuses P. 304 Emergency Towing P. 308 When You Cannot Open the Hatch P. 310
Devices that Emit Radio Waves P. 315 Reporting Safety Defects (U.S. Vehicles) P. 316
Customer Service Information P. 320 Warranty Coverages P. 321

Quick Reference Guide
13
Safe Driving P. 2 9
Before Driving Checklist P.192
Before driving, check the seat positions, steering

●
wheel and mirror adjustments. Airbags

P.41Your vehicle is fitted with airbags to help protect you and

●
your passenger during a moderate to severe collision.
Seat Belts
P.34Fasten your seat belt and sit with a correct driving

●
posture. Check that your passenger is wearing their seat

●
belt correctly.
Child Safety

P. 5 6Your vehicle is not recommended for child passengers.

● If you decide to
disregard our recommendations and transport a child passenger, the child should be properly restrained. Never put a rear-facing child seat in the passenger's seat.
Exhaust Gas Hazard
P. 6 4Your vehicle emits dangerous exhaust gases that contain carbon

●
monoxide. Do not run the engine in confined spaces where carbon monoxide gas can accumulate.
Fasten your lap belt as
low as possible.
Main Menu

Quick Reference Guide
22
Maintenance P. 2 3 7
Under the Hood P. 2 4 5
Check engine oil, engine coolant, and window washer fluid.

●
Add when necessary. Check transmission fluid (CVT).

●
Check brake fluid and clutch fluid.

●
Check the 12 volt battery regularly.

●
Pull the hood release handle under the corner of the
dashboard.
Locate the hood latch handle, pull the handle up, and lift up the hood.
When finished, close the hood and make sure it is
firmly locked in place.
Wiper Blades P. 2 6 6
Replace blades if they leave streaks

●
across the windshield.
Lights
P. 2 5 8
Inspect all lights regularly.

●
Tires
P. 2 6 9
Inspect tires and wheels regularly.

●
Check tire pressure regularly.

●
Install snow tires for winter driving.

●
Main Menu

Quick Reference Guide
23
Handling the Unexpected

P. 2 8 5
Flat Tire P. 2 8 7
Park in a safe location and replace the flat

●
tire with the compact spare tire located under the cargo area. Engine Won't Start

P. 2 9 3
If the 12 volt battery is dead, jump start it

●
using a booster battery. Overheating

P. 2 9 7
Park in a safe location. If there is no steam

●
coming out, open the hood, and let the engine cool down.
Indicators Come On P. 2 9 9
Identify the indicator and consult the

●
owner's manual. Blown Fuse

P. 3 0 4
Check for a blown fuse if an electrical

●
device does not operate. Emergency Towing

P. 3 0 8
Call a professional towing service if you

●
need to tow your vehicle.
Main Menu

68
Instrument Panel
Indicators
IndicatorName On/Blinking Explanation Message
U.S.
Canada Parking Brake and Brake System Indicator Comes on briefly when you turn

•
the ignition switch to ON
II, then
goes off (comes on when the parking brake is applied).Comes on when the brake fluid

•
level is low.Comes on if there is a problem

•
with the brake system.The beeper sounds and the

•
indicator comes on if you drive with the parking brake not fully released. Comes on while driving

• - Make sure
the parking brake is released. Check
the brake fluid level.
What to Do When It Comes On While Driving P.302
Comes on along with the ABS

•
indicator - Have the vehicle checked
by a dealer.
If the Brake System Indicator Comes
On P.302
U.S. Canada
Low Oil Pressure Indicator Comes on when you turn the

•
ignition switch to ON
II, and goes
off when the engine starts. Comes on when the engine oil

•
pressure is low. Comes on during driving

• -
Immediately stop in a safe place. If the Low Oil Pressure Indicator Comes On P.299
Main MenuTable of Contents

69
Instrument Panel
Indicators
IndicatorName On/Blinking Explanation Message
Malfunction Indicator Lamp Comes on when you turn the

•
ignition switch to ON
II, and goes
off either when the engine starts or after several seconds if the engine is not started. If “readiness codes” have not been set, it blinks five times before it goes off.Comes on if there is a problem

•
with the emissions control system.Blinks when a misfire in the

•
engine’s cylinders is detected. Readiness codes are part of the on

•
board diagnostics for the emissions control systems.
Readiness Codes P.317
Comes on during driving

• - Have
the vehicle checked by a dealer immediately.Blinks during driving

• - Stop in a safe
place where there are no flammable objects. Stop the engine for 10 minutes or more, and wait for it to cool down. Then, take the vehicle to a dealer.
If the Malfunction Indicator Lamp Comes On or Blinking P.301
12 Volt Battery Charging System Indicator Comes on when you turn the

•
ignition switch to ON
II, and goes
off when the engine starts.
Comes on when the 12 volt battery

•
is not charging. Comes on during driving

• - Turn off
the climate control system and rear defogger in order to reduce electricity consumption.
If the 12 Volt Battery Charging System Indicator Comes On P.300
Transmission Indicator(Shift Position Indicator) * Comes on for a few seconds when

•
you turn the ignition switch to ON
II, then goes off.
Blinks if the transmission system

•
has a problem. Blinks during driving

• - Avoid
sudden starts and acceleration and have the vehicle checked by a dealer immediately.
* Not available on all models
Main MenuTable of Contents

72
Instrument Panel
Indicators
IndicatorName On/Blinking Explanation Message
Door/Hatch Open Indicator Comes on for a few seconds if you

•
turn the ignition switch to ON
II,
then goes off. Comes on if the hatch or either

•
door is not completely closed. Goes off if both doors and the hatch

•
are closed.
EPS (Electric Power Steering System) Indicator Comes on when you turn the

•
ignition switch to ON
II, and goes
off when the engine starts. Comes on if there is a problem

•
with the EPS (Electric Power Steering System). Stays on constantly or does not

•
come on at all - Have the vehicle
checked by a dealer.
If the EPS Indicator Comes On P.302
U.S. models only
Low Tire Pressure/TPMS IndicatorComes on briefly when you turn

•
the ignition switch to ON
II.
Comes on if the tire pressure of any

•
of the tires becomes significantly low.Blinks for about one minute, and

•
then stays on if there is a problem with the TPMS, or when a compact spare tire is temporarily installed. Comes on during driving

• - Stop in
a safe place, check tire pressures, and inflate the tire(s) if necessary. Blinks and remains on

• - Have the
vehicle checked by a dealer. If the vehicle is fitted with a compact spare, get your regular tire repaired or replaced and put back on your vehicle as soon as you can.
Main MenuTable of Contents

73
Instrument Panel
Indicators
IndicatorName On/Blinking Explanation Message
High Temperature Indicator Comes on briefly when you turn

•
the ignition switch to ON
II.
Blinks when the engine coolant

•
temperature goes up, and stays on if the temperature continues to rise. Blinks while driving

• - Drive slowly to
prevent overheating.Stays on while driving

• - Immediately
stop in a safe place and allow the engine to cool.
Overheating P.297
IMA System Indicator Comes on briefly when you turn

•
the ignition switch to ON
II.
Comes on if there is a problem

•
with the IMA system. Remains on or does not come on

•
at all - Avoid high speed driving and
have the vehicle checked by a dealer as soon as possible.
If the IMA Indicator Comes ON P.303
System Message Indicator Comes on along with a beep when

•
a problem is detected. A system message on the multi-information display appears at the same time. While the indicator is on, press the

•
(information) button to see
the message again. Refer to the Indicators information in

•
this chapter when a system message appears on the multi-information display. Take the appropriate action for the message.
The multi-information display does not

•
return to the normal screen unless the warning is canceled, or the

button is pressed.
—
Main MenuTable of Contents
