2010 VOLKSWAGEN TOUAREG Owners Manual

any requirement for engaging Hill Hold is no longer met while the vehicle is stopped, Hill Hold disen-gages, the indicator light in the button goes out, and the brakes are automatically released and will no longer hold the vehicle.

Hill Hold is activated automatically when points 1 to 3 are met at the
same time:
1. Hold the stopped vehicle on an incline with the foot brake or elec-
tronic parking brake.
2. The engine is running “smoothly”.
3. The transmission must be in Drive (D) or Sport Drive (S) and the
foot brake must be depressed to keep the vehicle from moving.
4. To drive off, take your foot off the brake pedal and gently depress
the accelerator within 2 seconds.
Release the brake as you gently depress the accelerator.

Hill Hold is immediately deactivated:
x If any requirement listed in the table above is no longer met (see ⇒ table on page 453).
x If the engine is not running smoothly or the engine malfunctions.
x If the engine stalls or is switched off.
x If the transmission is in Neutral (N).
x If a tire does not have enough road contact (such as when the vehicle is tipped or at an angle).
WARNING
The intelligent technology of Hill Hold cannot overcome the laws of physics. Never let the increased convenience provided by Hill Hold tempt you into taking risks.
x The Hill Hold feature cannot hold the vehicle in all hill start situations (for example, if the surface is icy or slippery).
x Hill Hold can only help keep the vehicle from moving for less than 2 seconds. After that, the brakes will be released and the vehicle can roll down the hill.
Hill Descent Assist

An indicator light k comes on in the instrument cluster display whenever Hill Descent Assist is ena-bled. The indicator light blinks when Hill Descent Assist is regulating the brakes.
Hill Descent Assist is always enabled, but only regulates the brakes when certain requirements are met.
Hill Descent Assist regulates automatically:
x If the vehicle is in off-road mode and the indicator light k is on.
x And: If your speed is under 18 mph (30 km/h).
x And: If the downhill grade is 10 % or steeper.
x And: If you neither accelerate nor apply the brakes.
x And: If the vehicle's engine is running.
If you accelerate or step on the brake when Hill Descent Assist is operating, the feature switches off. Hill Descent Assist begins regulating speed again the next time the requirements are met.
Hill Descent Assist does not regulate speed:
x On downhill grades of less than 10 %.
x OR: At speeds over 18 mph (30 km/h).
x OR: If the driver brakes or accelerates.
WARNING
Always be ready to apply the brakes. Otherwise accidents and injuries can occur.
x Hill Descent Assist is merely a driving aid and cannot always slow the vehicle down enough under on downhill grades.
x The vehicle may pick up speed despite the use of Hill Descent Assist.
The Hill Descent Assist also works when you are backing down a hill.

Cruise Control System (CCS)

Warning and indicator lights

Fig. 266 In the instrument cluster display: Cruise control status indications.

Adaptive Cruise Control (ACC) with Front Assist

WARNING
Always remember that the Adaptive Cruise Control has limits – Using Adaptive Cruise Con-trol when it is not possible to drive safely at a constant speed can be dangerous and can lead to an accident and serious personal injury.
x Adaptive Cruise Control will not slow the vehicle down or maintain the set distance when you drive towards an obstacle or something on or near the road that is not moving, such as vehicles stopped in a traffic jam, a stalled or disabled vehicle.
x Always adjust your speed and the distance you keep between you and the vehicles ahead of you to the road, traffic, weather, and visibility conditions.
x Never use Adaptive Cruise Control on steep, winding, or slippery roads (such gravel roads, wet roads, or snowy or icy roads) or on roads with standing water.
x Never use Adaptive Cruise Control when driving in heavy or varying stop-and-go traffic.
x Never use Adaptive Cruise Control when driving off-road or on unpaved roads.
x Always remember that the Adaptive Cruise Control cannot detect a vehicle that is driving towards you in your traffic lane and that it cannot detect narrow vehicles such as motorcy-cles and bicycles.
x Never follow a vehicle so closely that you cannot stop your vehicle safely. The Adaptive Cruise Control cannot slow or brake the vehicle safely when you follow another vehicle too closely. Always remember that the Adaptive Cruise Control has a braking power that is only about 30% of the vehicle's maximum braking ability, under certain circumstances the auto-matic braking function cannot bring the vehicle to a stop in time.
x Always turn off Adaptive Cruise Control when entering turn lanes, exit lanes and construc-tion zones or in similar situations because the vehicle will automatically accelerate to the stored speed when the road ahead is clear.
x To help prevent unintended operation of Adaptive Cruise Control, switch the system off when it is not being used.
x It is dangerous to use the Resume feature when the previously set speed is too high for the existing road, traffic, or weather conditions.
x When traveling downhill, the Adaptive Cruise Control may not be able to maintain a con-stant speed. The vehicle will speed up because of its own weight. Downshift and/or use the foot brake to slow the vehicle.
x Never allow the closing speed between you and other vehicles to be so high that the Adaptive Cruise Control may not be able to slow your vehicle safely. If closing speed is too high, you must apply the brakes yourself to reduce the risk of a rear-end crash.
x If a driver intervention warning appears in the instrument cluster display, immediately takeover the control of the brake and gas pedals and low down the vehicle or bring it to stop when necessary and according to the traffic situation.
x If a Forward Collision Warning system (Front Assist) collision warning appears in the instrument cluster display, immediately takeover the control of the brake and gas pedals and low down the vehicle or bring it to stop when necessary and according to the traffic situation.
x Always be prepared to takeover the control of the brake and the gas pedal in every situa-tion.
NOTICE
If you suspect that ACC and the Forward Collision Warning system (Front Assist) don't work properly or the sensors are damaged, switch off ACC immediately.
x Go see an authorized Volkswagen dealer or Volkswagen Service Facility for assistance and have the ACC system checked.

Display, warning and indicator lights

Fig. 269 In the instrument cluster display: ACC is active and the maximum distance is set to the detected vehicle in front.

Fig. 270 In the instrument cluster display: ACC is not active but a vehicle was detected in front.

Lights
up Possible cause ⇒  Proper response
