The buttons 1 , 2 , and 3 on the roof keypad ⇒ fig. 37 between the sun visors can operate up to 3 separate remote control devices (for example, a gate and garage door, a house alarm, or a lighting system).
Getting ready to program
x Please read the product manufacturer's instructions before programming the garage door opener or other device.
x Safely park the vehicle within range of the device to be programmed.
x Switch the ignition on, but do not start the engine.
Menu Garage door opener in the Infotainment System
Call up the Garage door opener menu in the Infotainment System ⇒ fig. 38.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
Function key: Effect
Program buttons : Buttons 1 , 2 or 3 can be programmed after you tap the
function key. Follow the instructions on the Infotainment System screen.
Delete button assignment : Deletes the programming of buttons 1 , 2 , and
3 ⇒ fig. 37.
Version information : Most recent programming information for your author-
ized Volkswagen dealer or authorized Volkswagen Service Facility.
Programming information
You must complete the programming process within 5 minutes. If you exceed this time limit, the pro-gramming is cancelled.
If programming is cancelled, a red LED lights up in the keypad and the turn signals flash once.
Programming unassigned buttons
x Complete the programming preparation steps described above ⇒ page 73.
x Press unassigned button in the roof keypad ⇒ fig. 37.
x Follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3 times.
Repeat these steps with another unassigned garage door opener button to use that button to control another device.
