2010 VOLKSWAGEN TOUAREG navigation system

Upper center console

Fig. 7 Overview of upper center console.
Key to fig. 7:
(1) Air vent for indirect ventilation
(3) Air vents z
(2) Storage compartment
(4) Radio or Radio & Navigation system (factory installed)
(5) Controls for:
– Climatronic
– Seat heating switch button A
(6) Located here:
– Switch for emergency flashers
– PASSENGER AIR BAG /&&  light (front airbag for front seat passenger)
– Park Distance Control system button  or ∗
– Rear View camera ∗
– Heated steering wheel \b

Odometer displays
The odometer indicates the total distance driven by the vehicle.
The trip odometer (trip) shows the distance driven since the last time the trip odometer was reset. The last digit indicates 1/10 mile (100 meters).
Outside temperature display
At outside temperatures below about +39 °F (+4 °C), a “snowflake symbol” (icy road warning) appears in the display. The symbol flashes at first, then stays on until the outside temperature rises above
+43 °F (+6 °C) ⇒ .
When the vehicle is not moving or when you are driving at very low speeds, the temperature displayed may be slightly higher than the actual outside temperature.
The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C).
Compass display
When the ignition and navigation system are switched on, the current compass direction is indicated in
the instrument cluster display ⇒  Compass.
Selector lever positions
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive (D) and Sport Drive (S), as well as in Tiptronic® mode.
Speed warning
If you exceed the top speed that has been set, this will be signaled in the instrument cluster display. This feature is useful in various situations, for instance when using winter tires that are not designed for the vehicle's top speed.
The speed warning can be set and switched on and off in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Speed warning from the list.
x Place your finger on the touchscreen slider ? and, keeping your finger on the screen, move your finger to slide it to the desired speed setting.
x OR: Tap the - or + function key on the screen to move the slider in steps.
x Tap the Active function key on the screen to switch on the speed warning.
If the check box in the Active function key is checked =, the feature is switched on.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.

d Are maintenance, repair facilities, necessary tools and testing equipment as well as spare parts readily available for your vehicle?
d Are there authorized Volkswagen dealers and authorized Volkswagen Service Facilities in the countries where you will be driving?
d For gasoline engines: Is unleaded fuel with the right octane rating readily available?
d For diesel engines: Is ultra low-sulfur diesel fuel and AdBlue readily available?
d Are engine oil ⇒  Engine oil and other operating fluids that meet Volkswagen quality and perfor-mance requirements available where you will be driving? For more information, please See
⇒ Booklet Warranty and Maintenance.
d Does the factory installed navigation system work in the countries where you will be driving, and is navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving expected?
NOTICE
Volkswagen is not responsible for mechanical damage that may result from substandard fuel or service or the unavailability of Genuine Volkswagen parts.
Driving through water on roads

Safety information on Infotainment System
WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System, when using your mobile phone, or when operating the mobile phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your mobile phone, and the mobile phone controls only if road, traffic, and weather conditions permit and you will not be distracted from your driving.
x If you cannot use the Infotainment System, your mobile phone, or the mobile phone con-trols safely while driving, wait until later or find a safe spot where you can pull off the road and park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are exposed to high volumes for short periods only.
WARNING
The volume level may suddenly get louder change when you switch media source or connect a new audio source.
x Always lower the base volume before switching media source or connecting a new audio source.
WARNING
Driving recommendations and traffic symbols displayed by the navigation system may differ from the current traffic situation.
x Traffic signs and traffic regulations have priority over the recommendations and displays provided by the navigation system.
x Always adjust your speed and driving style to road, traffic, weather, and visibility condi-tions.
WARNING
External devices that are loose in the vehicle or not properly secured could be thrown around the interior and cause injuries during a sudden driving or braking maneuver, or in a crash.
x Never put or attach an external device on a door, on the windshield or above or near to the areas marked “AIRBAG” on the steering wheel, the instrument panel and the seat backrests, or between these areas and the vehicle occupants. External devices could cause serious injury in an accident, especially when the airbags inflate.

Settings main menu (CAR)

Fig. 140 Infotainment system with navigation: Settings main menu (CAR).

Fig. 141 Infotainment system without navigation: Settings main menu (CAR).

Navigation data
All navigation data required for navigation is stored in the unit navigation data memory.
Street routing is subject to ongoing changes like, for example, new streets, street names or street numbers. The route guidance may be inaccurate or incorrect if the navigation data is no longer up to date. You should therefore have the unit navigation data memory updated by a Volkswagen dealer-ship on a regular basis. The updates are subject to a fee.
Possible errors in navigation
When the navigation system cannot receive any data from GPS satellites (dense canopy of trees, tunnel, underground car park), navigation can still continue using the vehicle sensors.
In areas that are not or only incompletely digitized on the data medium (such as one-way streets and street type not sufficiently captured), the navigation system also tries to enable route guidance.
Please remember that the navigation may sometimes not be so accurate as usual if the precise vehi-cle position cannot be determined.
Navigation main menu

Fig. 167 Navigation main menu: Destination mode.

Fig. 168 Navigation main menu: Tour mode.

Function key: Effect
Last name: , First name: , Company: : Each open an input window to name
the directory entry more precisely. The entries next to Last name and
First name are used as voice commands.
Create new telephone numbers : Opens an input window where you can
enter a telephone number manually.
Create business navigation destination : Opens a menu where you can
select a navigation destination for the “Business P” favorites category or
convert a stored mailing address into a navigation destination.
Create business mailing address : Opens a menu to enter a mailing ad-
dress manually in input windows.
Create private navigation destination : Opens a menu where you can se-
lect a navigation destination for the “Private T” favorites category or con-
vert a stored mailing address into a navigation destination
Create private mailing address : Opens a menu to enter a mailing address
manually in input windows.
Read contact : The voice command stored under Last name and First
name is read out
= Private contact : The directory entry is only displayed when the corre-
sponding user profile is loaded. If the check box = is cleared, the directory
entry is transferred to the general user profile and is always displayed

If the prefix Create ... is not displayed in a function key, corresponding information is already stored.
This information is displayed below the function key (such as in fig. 192: Business navigation destina-
tion ). Press the function key to display or modify the stored information ⇒ fig. 193.
Converting mailing addresses into navigation destinations
Information that is stored as Business mailing address or Private mailing address can be converted into navigation destinations, such as the telephone directory entries of a connected mobile phone.
x Press the Create private navigation destination or Create business navigation destination button.
x Press the Create navigation destination function key.
The mailing address is converted into a navigation destination in the Infotainment System and dis-played in the Address entry menu where it can be edited further

In some cases, an imported contact still needs to be converted for the navigation system
Directory settings

Fig. 196 Address book opened for editing.

Fig. 197 Directory settings.
