2010 VOLKSWAGEN TOUAREG Owners Manual

In vicinity of destination9: Area around last destination.
Along the route10: Along the calculated route.
In a new city : Select country and town as center of search area.
Nationwide : Whole of country you are currently driving in.
x Press to select search area ⇒ fig. 174.
x Then press to select the desired point of interest category ⇒ fig. 176.
x Some point of interest categories contain further sub-categories that are revealed upon pressing.
The points of interest found in the search area for the selected point of interest category are displayed in a list
Select point of interest from list and show in detailed view
The nearest points of interest are displayed at the top of the list of points of interest that have been found.
If the immediate vicinity has been selected as the search area, additional distance and direction details will be displayed -.
The distances and directions initially refer to the route as the crow flies. The arrow - is shown “not filled in”.
In the background, the Infotainment System starts to calculate the route to the nearest points of inter-est in the list. Points of interest for which a possible route has been calculated are displayed with a “filled in” arrow. In this case, the actual distance to be driven is displayed.
The selection of points of interest can be narrowed down further by entering a name
x Touching a point of interest in the list shows the point of interest in the detailed view ⇒ fig. 175.
Selection options in the detailed view
'11: Opens a list where you can select other points of interest with the same address.
,: Stores the points of interest in the destination memory
.: Shows the point of interest on the map.
Start : Starts route guidance to the point of interest.
12: Makes a call to a displayed telephone number.
9 Only if a destination has already been set. 10 Can only be selected during route guidance. 11 Only displayed when several points of interest with the same address can be selected. 12 Only active or displayed when a telephone number is included in the point of interest information and a
mobile phone or a SIM card is connected to the Infotainment System ⇒ page 360.

Searching for points of interest using the name

Fig. 176 Select point of interest category.

Fig. 177 List of hotels in vicinity of location.

Response Effect
Press the Search function key in a
list to select a point of interest cate-
gory ⇒ fig. 176.
Search for points of interest within
the previously selected search area.
In a list of found points of interest,
press the Options function key and
then the Search for name function
key ⇒ fig. 177.
Search for points of interest within
the displayed selection of points of
interest.

x Enter the keyword for the point of interest search in the subsequent input window
Correct spelling of entries is important. In the same way as when selecting a destination address, it is only possible to make entries that correspond with a point of interest stored in the navigation data.
In some lists, the Options ⇒ fig. 177 interface can be used to put special objects into alphabetical order, according to trade names or categories.
Selecting special and favorite destinations from the map

Selecting destinations from the map

Fig. 178 Destination on map.

Fig. 179 Menu: Destination details.

OK : Opens the destination details menu ⇒ fig. 179.
Menu: Destination details
The Destination details menu displays all information for the given destination.
x Press the , function key to store the destination
x 13: Makes a call to a displayed telephone number.
x Press the Start function key to start route guidance
Entering a destination using coordinates

Fig. 180 Enter the destination using coordinates.

The coordinates for the current vehicle position can be shown in the additional window of the map display
Selecting stored destinations (last destinations, directory)

Fig. 181 List of automatically stored recent destinations.

Fig. 182 Loading a destination from the directory.

x Press the ( Last destinations or ) Favorites function key ⇒ fig. 169.
x Press the entry in the list to start route guidance
x OR: Press the H function key next to the required entry and select one of the following options.
Start route guidance : Starts route guidance
Show details : Shows the destination in the detail view.
Show destination on map : Shows the destination on the map
Loading a destination from the directory
The Load from directory menu only displays directory entries for which route guidance can be started (display: symbol 3).
The directory needs to be opened for editing in order to display or edit all directory entries
x Press the * Directory function key ⇒ fig. 169.
x Press the desired directory entry in the Load from directory menu.
x If more than one navigation destination is stored for a directory entry, you then need to select the desired navigation destination by touching the screen.
x Press one of the following options in the Destination details menu.
Start route guidance : Starts route guidance
Add as stopover : Allows you to add the destination to the tour plan
Enter/show destination on map : Shows the destination on the map
You can also search for directory entries using a search function.
x Press the Search function key and search for the directory entry by entering the entry name in an input window

Directory (navigation destinations, addresses and
telephone numbers) *
