Acoustic driving recommendation settings
The volume of an acoustic driving recommendation can be adjusted to a predefined minimum and maximum volume using the volume control D. All additional acoustic driving recommendations are issued at this volume.
The volume of audible navigation recommendations can be preset in the volume settings.
In the Navigation settings menu, you can switch off spoken navigation recommendations or define their level of detail.
Even when navigation information is switched off, you can show them briefly in the map view by press-
ing the setting knob ⇒ fig. 131 (3).
If a turn was missed during route guidance and there is no possibility to turn, continue driving until the navigation system offers an alternative route.
The quality of the announcements given by the unit depends on the navigation data provided.
Route guidance in tour mode

Fig. 219 Tour plan in Tour mode.

Showing routes or a maneuver list

Fig. 220 Maneuver list in the split screen.

During route guidance, you can manually exclude the route section immediately ahead of your current location. The route exclusion is revoked when route guidance is stopped.
x In the Navigation main menu, press the Route function key ⇒ fig. 216.
x In the pop-up window, press the Avoid area function key.
The Avoid area menu opens. The length of the stretch to be excluded from the current vehicle position.
x Press the ` function key to specify up to which route section the route ahead should be blocked.
x Press the a function key to shorten the route exclusion.
x Press the OK function key to confirm the exclusion entry.
In the Navigation main menu ⇒ fig. 216, the icon for an active route exclusion

Display of traffic congestion and dynamic route guidance

Fig. 221 SIRIUS traffic flow display and traffic congestion on the map.

Displaying Sirius traffic reports in a list

Function key: Effect

Complete : Detailed driving recommendations with lane recommen-
dation and additional information.

Compact : Some additional navigation recommendations and infor-
mation are left out.
Off : No spoken navigation recommendations.
Time display : Display  during route guidance.

Arrival time : The estimated time of arrival at the destination is dis-
played.

Driving time : The estimated driving time until reaching the destina-
tion is displayed.
Map icons : Select icons for display on the map
= Speed limit display : The speed stored in the navigation data for the
road you are currently travelling on is displayed on the map. The actual
speed limit may differ from this display.
Advanced navigation settings : Allows settings for demo mode.
SIRIUS traffic ID : The Sirius traffic ID and the Internet address and the
telephone number of the Sirius activation hotline are displayed in the pop-
up window
Instrument cluster guidance : Visual navigation recommendations for guid-
ance in the instrument cluster
Arrow view : Travel direction arrows show the direction of travel and
the distance to the next turn-off point.
Street view : Road and route view corresponding with the map dis-
play in the Infotainment System.

Function key: Effect
= Voice guidance during phone call : Spoken navigation recommendations
are also given during a telephone call.

Advanced navigation settings: Demo mode and manual location
x In the Advanced navigation settings menu, check the check box in the Demo mode function key by pressing it = to start virtual route guidance to the entered destination.
x Press the Enter current position manually function key to select a manual location in the same way you entered a destination
If demo mode is enabled an additional pop-up window opens when you start route guidance.
x Pressing the Demo mode function key starts a “virtual route guidance” to the destination you have entered.
x If you press the Normal mode function key, a “real route guidance” starts.
The sequence of events and the operations in virtual route guidance are similar to those in real route guidance. Once a manual location has been entered, the virtual route guidance starts from that position.
Virtual route guidance is repeated when you reach the fictitious destination and always starts again from the starting point if it is interrupted.
When real route guidance is started following route guidance in demo mode, the unit first has to reori-ent itself. Depending on the number of currently received satellites, this orientation may take some time. Vehicle movement can reduce the re-orientation time.
If the vehicle is moved and the unit can determine its current location by GPS, any manually entered location will be overwritten with the current vehicle location.
Disable demo mode after use, otherwise you will be prompted to choose between virtual and normal route guidance each time you start route guidance.

MAP (map display)
