2010 VOLKSWAGEN TOUAREG Owners Manual

NOTICE
Before opening or closing the rear hatch, make sure there is enough room to do so, as for example when the vehicle has a trailer or is in a garage.
At temperatures below +32 °F (0 °C), the rear hatch may not open automatically after you unlock it. It will be necessary to lift it by hand.
Power operation of the rear hatch

Fig. 32 Button in the open rear hatch.

The rear hatch will then move into closing position by itself and will be closed by the soft-close feature
⇒ .
If, while closing automatically, the rear hatch meets resistance or becomes blocked by an obstacle, it will reopen slightly.
Check to see why the rear hatch could not close.
Try again to close the rear hatch.
Canceling the opening or closing feature
You can stop the opening or closing of the rear hatch by pressing one of the & buttons a second time. Pressing one of the & buttons again makes the hatch move back to its original position.
You can then open the hatch further by hand. This requires some strength.
Saving the opening angle
The rear hatch must be at least half way open to be able to save the opening angle.
x Stop the opening process at the desired opening angle
x Press the ⇒ fig. 32 button in the open rear hatch ⇒  for at least 3 seconds. This saves the opening angle.
The warning flashers will blink and a chime will sound to confirm that the angle has been saved.
To completely open the rear hatch again you must first save a new opening angle.
x Unlock the rear hatch and open it to the saved position.
x Manually push open the rear hatch as far as it will go. This requires some strength.
x Press the ⇒ fig. 32 button in the open rear hatch for at least 3 seconds.
x The opening angle has been reset to the factory setting.
WARNING
Improper or unsupervised closing of the rear hatch can cause severe injuries.
x Never leave your vehicle unattended or let children play around your vehicle, especially with the rear hatch left open. A child could crawl into the vehicle and pull the rear hatch shut, becoming trapped and unable to get out. A closed vehicle can become very hot or very cold depending on the season. Temperatures can quickly levels that can cause unconsciousness or death, particularly to small children.
WARNING
A closed rear hatch cannot open completely and an open rear hatch cannot close automati-cally if a luggage rack is installed on it or if it is covered by a heavy layer of snow. In this case, you will have to hold the rear hatch or prop it up to keep it open.
NOTICE
Before opening or closing the rear hatch, make sure there is enough room to do so, as for example when the vehicle has a trailer or is in a garage.
NOTICE
x Remove any luggage or bicycle rack mounted on the rear hatch before opening the hatch.

NOTICE
If the system is operated too often in succession, it will shut itself off to help prevent overheat-ing.
x The feature can be used again as soon as the system has cooled down. In the meantime, the rear hatch can be opened or closed by hand, though this requires some strength.
x If the vehicle battery or the fuse is blown when the rear hatch is open, the rear hatch system must be reset. To reset the rear hatch, it must be closed once.
Make sure that the remote control vehicle key is not in the luggage compartment before closing the rear hatch.
Sensor-controlled rear hatch opener (Easy Open)

Fig. 33 Keyless Access locking and starting system: Opening the sensor-controlled rear hatch (Easy Open).

x If the rear bumper is very dirty.
x If the rear bumper has salty water on it after driving on salted roads.
x If a trailer hitch/ball mount has been installed on the vehicle.
Easy Open may be automatically deactivated in heavy rain to help prevent unintentional deployment caused by water running down the vehicle, for example.
WARNING
Careless use of the Easy Open feature can cause falls and serious personal injury
x Always make sure you have firm footing when using the Easy Open feature, and that the surface you are standing on is not uneven or slippery.
x Always remember that it will be necessary for you to move backwards to let the rear hatch open. Be careful not to lose your balance, particularly when holding things in your hands.
x Never use Easy Open feature unless you can use it safely.
CAUTION
If a valid vehicle key is within range of the rear hatch, the Easy Open feature can deploy unin-tentionally in some cases and open the rear hatch: for example, when sweeping the ground or floor below the rear bumper, if there is a strong stream of water or steam or when carrying out maintenance or repairs around the rear bumper. If the rear hatch opens unintentionally, it can injure anyone or damage anything in its way.
x Never leave a valid vehicle key within range of the rear hatch unattended.

Power windows

Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not completely closed, the one-touch feature will not work and must be reactivated:
x Close all windows and doors.
x Pull up the switch for the respective window and hold it for at least 2 seconds in this position.
x Release the switch, pull up and hold again. The one-touch feature is now reactivated.
The one-touch feature can be reactivated for one or more windows at the same time.
Convenience closing
From outside the vehicle (vehicles with Keyless Access), hold your finger on the lock sensor surface
on the outside of the door handle for a few seconds until the windows close ⇒ page 47.
Convenience closing closes the windows first and then the power sunroof.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children, remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-dows for several minutes after the ignition is switched off as long as the driver or front pas-senger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power windows and keep them from being opened and closed.
If the power windows malfunction, the one-touch feature, as well as pinch protection will not work properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility right away.
Power window pinch protection

x If closing takes longer than about 10 seconds, pinch protection is turned on again. The window stops again if there is resistance.
x If the window still will not close, please see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Without pinch protection, power windows will close with enough force to cause serious per-sonal injury.
x Always be careful when closing power windows.
x Always make sure that no one is in the way when overriding pinch protection to close power windows!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the window frame; injuries may result.
Pinch protection is also active during convenience closing of the windows and the power sunroof
⇒  Power windows – features.
