2010 TOYOTA TUNDRA Owners Manual

465
3-7. Using the
storage features
3
Interior and exterior features
■Removing the cup holder (separated type seats only)
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
Push the tab down to release the lock
and remove the lid.
Stow the lid.
Pull the cup holder up and remove it.
Front cup holders

466 3-7. Using the storage features
Rear cup holdersDouble Cab models with front separated type seats Pull the lid down.
Double Cab models with front bench type seat Pull the lid down.
CrewMax models Pull the armrest down.
Rear cup holders

467
3-7. Using the
storage features
3
Interior and exterior features
Bottle holders
Instrument panel (front bench type seat) Push the lid.
Front door
CAUTION
■ Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
Rear cup holders and bottle holders

468 3-7. Using the storage features
Rear door (type A)
Rear door (type B)
■Removing the hold separator (front bench type seat only)
CAUTION
■When not in use (front bench type seat only)
Keep the bottle holders closed.
Injuries may result in the event of an accident or sudden braking.
Remove the hold separator.
Bottle holders

469
3-7. Using the
storage features
3
Interior and exterior features
Auxiliary boxes
Front door Press the knob and open the lid.
Front bench type seat (type A) Pull the strap.
NOTICE
■Items that should not be st owed in the bottle holders.
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.
Bottle holders and auxiliary boxes

470 3-7. Using the storage features
Front bench type seat (type B)Pull the lever up and fold down
the seatback.
Push the knob and lift the lid.
Front bench type seat (type C) Pull the lever up and fold down
the seatback.
Auxiliary boxes

471
3-7. Using the
storage features
3
Interior and exterior features
Push the knob and lift the lid.
Storage box (if equipped)
■ Using the storage box
Pull the lever up and raise the
rear seat cushion.
CAUTION
■Caution while driving
Keep the auxiliary boxes closed.
Injuries may result in the event of an accident or sudden braking.
Auxiliary boxes and storage box

472 3-7. Using the storage features
Turn the knob in the OPEN
direction.
Lift the lid.
■ Remove the storage box
Pull the lever up and raise the
rear seat cushion.
Turn the knob in the OPEN
direction.
Lift the lid.
Remove the lids.
Turn the knobs clockwise.
Remove the storage box.
Storage box
