2010 TOYOTA TUNDRA Owners Manual

649
6-1. Specifications
6
Vehicle specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package*4: P275/55R20 tires
USK55L-TRTDGA
5.7 L V8
(3UR-FBE) engine 4WDStandard 8700 lb. (3945 kg)
*2
10100 lb. (4580 kg)*3
9600 lb. (4355 kg)*3,4
USK56L-THTDGA
Long8600 lb. (3900 kg)
*2
10500 lb. (4760 kg)*3
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)

650 6-1. Specifications
Double Cab models
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)
GSK51L-CRASKA 4.0 L V6
(1GR-FE) engine 2WD Standard 4800 lb. (2175 kg)
UPK51L-CRTSKA
4.6 L V8
(1UR-FE) engine 2WD
Standard 7200 lb. (3265 kg)
*2
8600 lb. (3900 kg)*3
UPK51L-CRTLKA
7100 lb. (3220 kg)
*2
8600 lb. (3900 kg)*3
UPK52L-CHTSKA
Long 8500 lb. (3855 kg)
UPK56L-CRTSKA 4WDStandard 6900 lb. (3130 kg)
*2
8300 lb. (3765 kg)*3
UPK56L-CRTLKA
6800 lb. (3085 kg)
*2
8300 lb. (3765 kg)*3
UPK57L-CHTSKA
Long 8200 lb. (3720 kg)
USK51L-CRTSKA
5.7 L V8
(3UR-FE) engine 2WD
Standard 8600 lb. (3900 kg)
*2
10600 lb. (4805 kg)*3
USK51L-CRTLKA
8600 lb. (3900 kg)
*2
10500 lb. (4760 kg)*3
USK52L-CHTSKA
Long 10400 lb. (4715 kg)
USK56L-CRTSKA 4WDStandard 8300 lb. (3760 kg)
*2
10300 lb. (4670 kg)*3
USK56L-CRTLKA
8300 lb. (3760 kg)
*2
10200 lb. (4625 kg)*3
USK57L-CHTSKA
Long 10100 lb. (4580 kg)

651
6-1. Specifications
6
Vehicle specifications
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package
USK56L-CRTSGA
5.7 L V8
(3UR-FBE) engine 4WD
Standard 8300 lb. (3760 kg)
*2
10300 lb. (4670 kg)*3
USK56L-CRTLGA
8300 lb. (3760 kg)
*2
10200 lb. (4625 kg)*3
USK57L-CHTSGA
Long 10100 lb. (4580 kg)
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)

652 6-1. Specifications
CrewMax models
*1: The model code is indicated on the Certification Label. (P. 653)*2: Without towing package*3: With towing package
Model code*1EngineDriving
systemBed typeTowing capacity
(Trailer weight + cargo)
UPK51L-PSTSKA
4.6 L V8
(1UR-FE) engine 2WD
Short 7000 lb. (3175 kg)
*2
8500 lb. (3855 kg)*3
UPK51L-PSTLKA
7000 lb. (3175 kg)
*2
8500 lb. (3855 kg)*3
UPK56L-PSTSKA
4WD 6700 lb. (3035 kg)
*2
8200 lb. (3715 kg)*3
UPK56L-PSTLKA
6700 lb. (3035 kg)
*2
8100 lb. (3670 kg)*3
USK51L-PSTSKA
5.7 L V8
(3UR-FE) engine 2WD
8400 lb. (3810 kg)
*2
10400 lb. (4715 kg)*3
USK51L-PSTLKA
8400 lb. (3810 kg)
*2
10400 lb. (4715 kg)*3
USK56L-PSTSKA
4WD 8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTLKA
8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTSGA
5.7 L V8
(3UR-FBE) engine 4WD 8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3
USK56L-PSTLGA
8100 lb. (3670 kg)
*2
10100 lb. (4580 kg)*3

653
6-1. Specifications
6
Vehicle specifications
Vehicle identification
■ Vehicle identification number
The vehicle identificati on number (VIN) is the legal identifier for your
vehicle. This is the primary identification number for your Toyota. It is
used in registering the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.
This number is also on the
Certification Label.

654 6-1. Specifications
■Engine number
The engine number is stamped on the engine bl ock as shown.
4.0 L V6 (1GR-FE) engine
4.6 L V8 (1UR-FE) engine
5.7 L V8 (3UR-FE, 3UR-FBE) engine

655
6-1. Specifications
6
Vehicle specifications
Engine
4.0 L V6 (1GR-FE) engine
4.6 L V8 (1UR-FE) and 5.7 L V8 (3UR-FE, 3UR-FBE) engines
Model1GR-FE
Type 6-cylinder V-type, 4-cycle, gasoline
Bore and stroke 3.70  3.74 in. (94.0  95.0 mm)
Displacement 241.4 cu.in. (3956 cm3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold)
Intake
Exhaust 0.006 
0.010 in. (0.15  0.25 mm)
0.011  0.015 in. (0.29  0.39 mm)
Model 1UR-FE, 3UR-FE, 3UR- FBE
Type 8-cylinder V-type, 4-cycle, gasoline
Bore and stroke 4.6 L V8 (1UR-FE) engine
3.70 
3.27 in. (94.0  83.0 mm)
5.7 L V8 (3UR-FE, 3UR-FBE) engine
3.70  4.02 in. (94.0  102.0 mm)
Displacement 4.6 L V8 (1UR-FE) engine
281.2 cu.in. (4608 cm3)
5.7 L V8 (3UR-FE, 3UR-FBE) engine
345.6 cu.in. (5663 cm
3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold) Intake
Exhaust Automatic adjustment

656 6-1. Specifications
Fuel
Lubrication system4.0 L V6 (1GR-FE) engine
Engine Gasoline engine Flex-fuel engine
Fuel typeUnleaded gasoline onlyUnleaded gasoline, E85,
or a blend of the two fuels
Octane rating
(Unleaded gasoline) 87 (Research octane number 91) or higher
Ethanol percentage
(E85) 
85% or less
Fuel tank capacity
(Reference) 26.4 gal. (100.0 L, 22.0 lmp.gal.)
Oil capacity
Drain and refill
(Reference)
With filter
Without filter 5.5 qt. (5.2 L, 4.6 Imp.qt.)
5.2 qt. (4.9 L, 4.3 Imp.qt.)
