2010 TOYOTA AVALON Owners Manual

9
AVALON_U (OM41437U)
Compass P. 306
Garage door opener switches P. 301
Inside rear view mirror P. 70
Personal light P. 277
Moon roof switch P. 77
Interior light P. 277
Vanity mirror P. 287
Personal light P. 277
Sun visor P. 286
SRS curtain shield airbag P. 90
A
: If equipped

10
AVALON_U (OM41437U)
B
Door lock switch P. 40
Window lock switch P. 74
Power window switches P. 74
Pictorial indexInterior

11
AVALON_U (OM41437U)
C
Cup holders P. 284
Navigation system switches*
Ashtray P. 290
Seat heater/ventilator switch P. 293
Shift lock override button P. 416
Shift lever P. 140
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
Storage compartment P. 283

12
AVALON_U (OM41437U)
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch P. 156
P. 145
P. 159
Gauges and meters P. 148
Windshield wipers and
washer switch
P. 160
Trunk opener main switch P. 46
Glove box P. 279
Telescopic lock release
lever
P. 68
Parking brake pedal
P. 146
Tilt lock release lever
P. 68
Driving position
memory switches

P. 55
Tire pressure warning reset switch
(hidden under panel)
P. 346
Horn P. 147

13
AVALON_U (OM41437U)
Audio remote control switches P. 239
Engine (ignition) switch
(vehicles without smart key
system)
P. 137
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
A
B
Telephone switch P. 247
Engine (ignition) switch
(vehicles with smart key system)
P. 133
Climate remote control
switches
P. 206
Talk switch* P. 247
Distance switch P. 172
Cruise control switch P. 165, 168

14
AVALON_U (OM41437U)
C
Pictorial indexInstrument panel
Center display P. 154
Emergency flashers
P. 384
Clock P. 288
Air conditioning
system
P. 198
Audio system
P. 210
Navigation system*
Rear window and outside rear
view mirror defoggers
P. 208
Air conditioning
system
P. 198

15
AVALON_U (OM41437U)
D
Rear sunshade switchP. 296
Glass breakage sensorP. 85
Fuel filler door opener P. 80
Trunk openerP. 46
Outside rear view mirror switches P. 72
: If equipped
*: Refer to “Navigation System Owner’s Manual”.

16
AVALON_U (OM41437U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustration may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.
