2010 JAGUAR XFR Engine

Published: 11-May-2011
Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Exhaust System
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. WARNINGS:


Make sure to support the vehicle with axle stands.


Observe due care when working near a hot exhaust system.
Raise and support the vehicle.

3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Engine Rear Undershield (501-02 Front End Body Panels, Removal and Installation).

5.
6. www.JagDocs.com

Published: 09-Dec-2012
Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Front Muffler
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. WARNINGS:


Make sure to support the vehicle with axle stands.


Observe due care when working near a hot exhaust system.
Raise and support the vehicle.

2. Refer to: Engine Rear Undershield (501-02 Front End Body Panels, Removal and Installation).

3. Torque: 55 Nm 4. Torque: 55 Nm

Published: 01-Aug-2012
Fuel System - General Information - Fuel System Pressure Release V8 5.0L
Petrol/V8 S/C 5.0L Petrol
General Procedures

Draining

1. Remove the fuel pump fuse.

2. Remove the fuel filler cap.


3. CAUTION: When depressurising the fuel system, make sure that
there is no throttle input. Failure to follow this instruction may cause
damage to the vehicle.
Start the engine and allow it to idle until the engine stalls.

4. Crank the engine for approximately five seconds to make sure that the
fuel rail pressure is released.

Filling


1. NOTE: Make sure all repairs have been carried out before
proceeding to the following steps.
Install the fuel pump fuse.

2. Install the fuel filler cap.

3. Read and clear stored DTC fault codes.

Safety Precautions (100-00 General Information, Description and Operation).

All except vehicles with diesel engine

2. For additional information, refer to: Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions (100-00 General Information, Description and Operation).

Vehicles with 3.0L or 4.2L engine

3. Release the pressure in the fuel system.
For additional information, refer to: Fuel System Pressure Release - V6 3.0L Petrol (310-00 Fuel System - General Information, General Procedures).

Vehicles with 5.0L engine

4. Release the pressure in the fuel system.
For additional information, refer to: Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol (310-00 Fuel System - General Information, General Procedures).

All vehicles

5. Remove the rear seat cushion.
For additional information, refer to: Rear Seat Cushion (501-10 Seating, Removal and Installation).

6. Detach and reposition the door opening weatherstrip. Fuel tank drain adaptor
310-154 Special Tool(s)

11.























12. CAUTION: The correct measurement must be used to
remove the fuel tank drain port top. Failure to follow this
instruction may result in damage to the vehicle.


NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.

Using a suitable tool, remove the top of the fuel tank drain
port.















NOTES:


A fuel vacuum drain unit must be attached to the
special tool to achieve full fuel tank drain.


Vehicles without Diesel engine shown, vehicles with
Diesel engine similar.

Using the special tool, drain the right-hand side of the fuel
tank.

13.

























14. NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.
Remove the special tool.






















CAUTION: Make sure the new fuel tank drain port
sealing cap is correctly installed. Failure to follow this
instruction may result in damage to the vehicle.


NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.
Install a new fuel tank drain port sealing cap.

15.























16. CAUTION: The correct measurement must be used to
remove the fuel tank drain port top. Failure to follow this
instruction may result in damage to the vehicle.


NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.

Using a suitable tool, remove the top of the fuel tank drain
port.















NOTES:


A fuel vacuum drain unit must be attached to the
special tool to achieve full fuel tank drain.


Vehicles without Diesel engine shown, vehicles with
Diesel engine similar.

Using the special tool, drain the left-hand side of the fuel
tank.

17.

























18. NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.
Remove the special tool.






















CAUTION: Make sure the new fuel tank drain port
sealing cap is correctly installed. Failure to follow this
instruction may result in damage to the vehicle.


NOTE: Vehicles without Diesel engine shown, vehicles
with Diesel engine similar.
Install a new fuel tank drain port sealing cap.













19.
Install the floor aperture cover.
