MONOCHROME INSTRUMENT PANEL (WITH MULTIFUNCTION SCR
EEN A)

1. Rev counter

2. Gear effi ciency indicator for a
manual gearbox or gear selector
lever and gear for the electronic
gearbox system or automatic
gearbox
3. "Foot on brake" warning lamp for
the electronic gearbox system or
automatic gearbox/Electric parking
brake

4. Speedometer

5. Cruise control or speed limiter
setting
A. Lighting rheostat (available day
and night)

B. Trip mileage recorder reset
Central screen Controls
TWO-TONE INSTRUMENT PANEL (WITH MULTIFUNCTION SCRE
EN C)

6. Fuel gauge

7. Trip mileage recorder

8. Multifunction screen A/C

9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- service indicator,
- engine oil level indicator,
- total mileage recorder.

I
31
M O N I T O R I N G
INSTRUMENT PANEL WITH MYWAY OR NAVIDRIVE MULTIFUNCTION SCREEN

1. Cruise control or speed limiter
setting

2. Speedometer

3. MyWay or NaviDrive multifunc-
tion screen
4. Rev counter

5. "Foot on brake" warning lamp for
the electronic gearbox system or
automatic gearbox/Electric park-
ing brake

6. Fuel gauge
A. Lighting rheostat (available day
and night)

B. Trip mileage recorder reset
Central screen Controls

7. Gear effi ciency indicator for a
manual gearbox or selector lever
position and gear for the elec-
tronic gearbox system or auto-
matic gearbox

8. Trip mileage recorder

9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- service indicator,
- engine oil level indicator,
- total mileage recorder.

10. Warning lamp zone.

I
32M O N I T O R I N G
Indicator and warning lamps
Visual indicators informing the driver that a system is in
operation (operation or deactivation indicator lamps) or of
the occurrence of a fault (warning lamp).
When the ignition is switched on
Certain warning lamps come on for a few seconds when
the vehicle's ignition is switched on.
When the engine is started, these same warning lamps
should switch off.
If they remain on, before moving off, refer to the
information
on the warning lamp concerned. Associated warnings
The switching on of certain warning lamps may be a
ccompanied
by an audible signal and a message on the multifunc tion screen.
Operation indicator lamps
If one of the following indicator lamps comes on, this confi rms
that the corresponding system has come into operati on.
The warning lamps may come on continuously (fi xed) or fl ash.
Certain warning lamps may come on in two different modes.
Only by relating the type of lighting to the operat ing status of the
vehicle can it be ascertained whether the situation is normal or
whether a fault has occurred.

Warning lamp is on Cause Action/Observations

Left-hand
direction
indicato
r fl ashing with
buzzer. The lighting stalk is pushed down.


Right-hand
direction
indicator fl ashing with
buzzer. The lighting stalk is pushed up.


Sidelamps fi xed. The lighting stalk is in the
"Sidelamps" position.


Dipped beam
headlamps fi xed. The lighting stalk is in the "Dipped
beam headlamps" position.


Main beam
headlamps fi xed. The lighting stalk is pulled towards
you. Pull the stalk to return to dipped
beam headlamps.

Hazard
warning lamps fl ashing with
audible signal. The hazard warning lamps switch,
located on the dashboard, has been
operated. The left-hand and right-hand direction
indicators and their associated indicator
lamps fl ash simultaneously.

I
33
M O N I T O R I N G

Warning lamp is on Cause Action/Observations

Front
foglamps fi xed. The front foglamps are
switched on. Turn the ring on the stalk rearwards twice
to switch off the front foglamps.

Rear
foglamps fi xed. The rear foglamps are
switched on. Turn the ring on the stalk rearwards to
switch off the rear foglamps.

Diesel engine
pre-heating fi xed. The ignition switch is at the
2nd position (ignition on). Wait until the warning lamp has switched off befor
e starting.
The duration for which the warning lamp is on is d etermined
by the climatic conditions.

Parking brake fi xed.
The parking brake is applied
or not properly released. Release the parking brake to switch off the
warning lamp, keeping your foot on the
brake pedal.
Observe the safety recommendations.
For further information on the parking
brake, refer to the "Driving" section.
fl ashing.
The parking brake is not fully
applied or is released.

Parking
space
sensors fi xed.
The parking space sensors
function is active. Press the corresponding button to
deactivate it.
fl ashing. The system is measuring the
space. Once the measurement has been done,
the warning lamp comes on fi xed again.

Electric child
lock temporarily. The electric child lock is
activated. Displayed for a few seconds after activating
the function and every time the ignition is
switched on.
For more information, refer to the "Child
safety" section.

I
34M O N I T O R I N G

Warning lamp is on Cause Action/Observations

Stop & Start fi xed.
The Stop & Start system has
put the engine in STOP mode
at a vehicle stop (traffi c lights,
traffi c jam, or other...). The warning lamp goes off and the engine
restarts automatically in START mode, as
soon as you want to move off.
fl ashes for a
few seconds,
then goes off. STOP mode is temporarily
unavailable.
or
START mode is invoked
automatically. Refer to "Driving - § Stop & Start" for
special cases with STOP mode and
START mode.

Passenger's
airbag
system fi xed. The control switch, located in
the glove box, is in the "
ON "
position.
The passenger's front airbag
is activated.
In this case, do not install a
rear-facing child seat. Turn the control switch to the "
OFF "
position to deactivate the front passenger's
airbag.
In this case you can install a rear-facing
child seat.
The passenger's airbag system is
automatically put into service on starting
the vehicle (" ON " position).

I
35
M O N I T O R I N G
Deactivation indicator lamps
If one of the following indicator lamps comes on,
this confi rms that the corresponding system has bee n switched off intentionally.
This is may be accompanied by an audible signal and a message on the multifunction screen.

Warning lamp is on Cause Action/Observations

Passenger's
airbag
system fi xed. The control, located in the
glove box, is set to the
OFF
position.
The passenger's front airbag
is deactivated.
In this case you can install a
"rear facing" child seat. Set the control to the
ON position to
activate the passenger's front airbag. In
this case, do not fi t a child seat in the rear-
facing position.
The passenger's airbag system is put into
service automatically when the vehicle is
started ( ON position).

ESP/ASR fi xed. The button, located in the
middle of the dashboard, is
pressed. Its indicator lamp is on.
The ESP/ASR is deactivated.
ESP: electronic stability
programme.
ASR: anti-skid regulation. Press the button to activate the ESP/ASR.
Its indicator lamp switches off.
The ESP/ASR system is activated
automatically when the vehicle is started.
If deactivated, the system is reactivated
automatically from approximately 30 mph
(50 km/h).

I
36M O N I T O R I N G
Warning lamps
When the engine is running or the vehicle is being driven,
the switching on of one of the following warning lamps indicates
a fault which requires action on the part of the driver.
Any fault resulting in the switching on of a warning lamp must be investigated further by reading the associated message
on the multifunction screen.
If you encounter any problems, do not hesitate to contact a CITROËN dealer.

Warning lamp is on Cause Action/Observations

STOP fi xed, associated
with another
warning lamp. It is associated with a
punctured tyre or the engine
coolant temperature. Stop as soon as it is safe to do so.
Park, switch off the ignition and call a
CITROËN dealer.

Service temporarily.
A minor fault has occurred
for which there is no specifi c
warning lamp. Identify the fault by reading the message
shown on the screen, such as, for
example:
- the closing of the doors, boot, rear
screen or bonnet,
- the remote control battery,
- the tyre pressures,
- saturation of the particle emission fi lter (Diesel).
For any other faults, contact a CITROËN
dealer.
fi xed. A major fault has occurred
for which there is no specifi c
warning lamp. Identify the fault by reading the message
shown on the screen and contact a
CITROËN dealer.
