2010.5 Citroen C4 PICASSO Owner's Manual

VI
112
F I T T I N G S
CARGO NET(GRAND C4 PICASSO)
This enables you to maximise the
vehicle’s loadspace.
It retains objects, preventing them
from sliding towards the front of the
passenger compartment.

You insert it under the luggage-
cover roller securing it on the
third-row side mouldings. Position 1
5-seat confi guration: installed behind
the second row.

Installing the roller

 Remove the protective covers
located under the blind roller
notches.

 Position the roller under that of
the luggage-cover blind.

 Raise the fl ap on the blind, posi-
tioning it on top of the blind.

 Deploy the net, passing it be-
tween the rollers and the seats.

 Pull the net upwards.

 Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).

Removing the roller

 Carry out these operations in re-
verse order. Position 2
2-seat confi guration; installed be-
hind the fi rst row.

Removing the roller

 Carry out these operations in re-
verse order.

Installing the roller

 With the second-row seats fold-
ed away, remove the covers of
the Isofi x mounting points locat-
ed on the seat backrests.

 Secure the roller on the Isofi x
mounting points.

 Deploy the net and pull it up-
wards.

 Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).

VI
113
F I T T I N G S
LUGGAGE ANCHORING RINGS (C4 PICASSO)
There are 4 anchoring rings in the
boot to enable you to secure your
luggage:
- 1, 2, 3 and 4 on the boot fl oor.
LUGGAGE ANCHORING RINGS (GRAND C4 PICASSO)
There are 4 anchoring rings in the
boot to enable you to secure your
luggage:
- 1, 2, 3 and 4 on the boot fl oor. For reasons of safety in the event of
sudden braking, it is recommended
that you place heavy objects on
the fl oor as close as possible to
the backrests of the second-row
seats.
LUGGAGE RETAINING NET (GRAND C4 PICASSO)
Attached to the luggage anchoring
rings, it allows objects to be held on
the boot fl oor.

VI
114
F I T T I N G S
TORCH
This is a portable lamp, fi tted in the
boot wall, which can be used to illu-
minate the boot or as a torch.
Grand C4 Picasso

C4 Picasso Boot lamp
The boot lamp
A comes on automat-
ically when the boot is opened and
switches off automatically when the
boot is closed.
Various lighting durations are avail-
able:
- ignition off, approximately ten minutes,
- in energy economy mode, approxi- mately thirty seconds,
- engine running, no limit.
Operation of the torch
This torch operates with NiMH re-
chargeable batteries.
It has a battery life of approximately
45 minutes and recharges while you
are driving.
 Extract the torch from its location
pulling it upwards, as indicated
by the arrow.

 Press the switch B , located on
the back, to switch the torch on
or off.

 Unfold the support C , located on
the back, to set down and raise
the torch; for example, when
changing a wheel.
Stowing the torch

 Put the torch back in place in its
location, starting at the bottom.
If you have forgotten to switch off the torch, this switches it off auto-
matically.
Observe the polarities when fi tting
the batteries.
Never replace the rechargeable
batteries with normal single-use
batteries.
For replacement of the batteries,
see the "Practical information -
Changing a bulb" section
It the torch is not engaged correct-
ly, it may not charge and may not
come on when the boot is opened.
Using the torch

VI
109
F I T T I N G S
LUGGAGE COVER(C4 PICASSO)
This is in two parts.
Rear parcel shelf

Removal

 Unhook the cords.

 Push upwards, then lift on each
side of the luggage cover. Front parcel shelf

Removal

 First remove the rear shelf.

 Push upwards, then lift on each
side.

Fitting

 Offer up the shelf to its housings
and push fi rmly down until it en-
gages.

 For the shelf to rise with the tail-
gate, take the cords and attach
them on the tailgate.
Refi tting

 Direct the fl ap downwards.

 Offer up the shelf to its housings
and push fi rmly down until it en-
gages.

VI
110
F I T T I N G S
MODUBOX (C4 PICASSO)
Equipment for use both inside the
vehicle and away from the vehicle.
It comprises a shopping trolley and
a fl exible bag (insulated on some
versions) which can be used inde-
pendently of each other depending
on your needs (by detaching the fas-
tenings on each side at the top and
bottom).
To use

 Unhook the red strap to free the
Modubox.

 Unhook the black strap then
press on the round buttons on
either side of the Modubox si-
multaneously to unfold it. Use outside the vehicle
Stowing inside the vehicle

 Perform the operations in re-
verse to fold and stow inside the
vehicle.

 If you have used your Modubox
away from the vehicle, take
care to reposition it correctly in
the housings provided for this
purpose.
BAG HOOK
LUGGAGE COVER ROLLER (GRAND C4 PICASSO)
Position 1
5-seat confi guration; installed be-
hind the second-row seats, with the
third-row seats folded away.

 Press on the recess on the left
hand side of the Modubox to
raise (or lower) the handle.
Located on the left-hand interior wall
of the boot, this can be used to se-
cure shopping bags.
Installing the roller

 Position the left-hand end of the
roller in notch A .

 Compress the right-hand end of
the roller and place it in notch B .

 Pull out the blind until it reaches
the boot pillars.

 Insert the guides of the blind into
the rails on the pillars.

Removing the roller

 Carry out these operations in
reverse order.

VI
110
F I T T I N G S
MODUBOX (C4 PICASSO)
Equipment for use both inside the
vehicle and away from the vehicle.
It comprises a shopping trolley and
a fl exible bag (insulated on some
versions) which can be used inde-
pendently of each other depending
on your needs (by detaching the fas-
tenings on each side at the top and
bottom).
To use

 Unhook the red strap to free the
Modubox.

 Unhook the black strap then
press on the round buttons on
either side of the Modubox si-
multaneously to unfold it. Use outside the vehicle
Stowing inside the vehicle

 Perform the operations in re-
verse to fold and stow inside the
vehicle.

 If you have used your Modubox
away from the vehicle, take
care to reposition it correctly in
the housings provided for this
purpose.
BAG HOOK
LUGGAGE COVER ROLLER (GRAND C4 PICASSO)
Position 1
5-seat confi guration; installed be-
hind the second-row seats, with the
third-row seats folded away.

 Press on the recess on the left
hand side of the Modubox to
raise (or lower) the handle.
Located on the left-hand interior wall
of the boot, this can be used to se-
cure shopping bags.
Installing the roller

 Position the left-hand end of the
roller in notch A .

 Compress the right-hand end of
the roller and place it in notch B .

 Pull out the blind until it reaches
the boot pillars.

 Insert the guides of the blind into
the rails on the pillars.

Removing the roller

 Carry out these operations in
reverse order.

VI
111
F I T T I N G S
The roller has a moving fl ap to
avoid interference with the second-
row passengers when the seats
are in the "reclined" position.
 Engage the lug on the left of the
roller in notch C .

 Pass the right-hand end above
the third-row armrest.

 Engage the lug in notch D .

 Pull the seat belt(s) so that they
reel out without locking.

 Pull out the blind and engage
the guides into the rails on the
pillars.

 Lock the seat(s) in position.

Installing the roller

 Reel in the blind, then remove
the roller from its initial position.

 Position the roller, with the blind
pull bar uppermost, fl ap down-
ward.

 Fold the concertina boards.
Removing the roller

 Push the fl ap towards the seat
backrest.

 Lift the concertina board by tak-
ing it at the side, then position it
vertically.

 Release the seat by pulling the
strap E .


Push the backrest towards the front.

 Proceed in reverse order to in-
stalling. Position 3
7-seat confi guration; stowed behind
the third row seats when these are
folded away.

Installing the roller

 Fold the concertina boards.

 Position the roller, with the blind
pull bar uppermost, fl ap down-
ward.

 Engage the lug on the left of the
roller in notch C .

 Pass the right-hand end above
the third-row armrest.

 Engage the lug in notch D .

Removing the roller

 Proceed in reverse order to in-
stalling.
Position 2
7-seat confi guration; installed be-
hind the third-row seats when these
are folded away. This position con-
ceals objects stowed in the boot
from outside view.
The roller can only be stored when
the seats are folded away.
You can position the concertina
board vertically to lodge a bulky ob-
ject in the boot well.

VI
112
F I T T I N G S
CARGO NET(GRAND C4 PICASSO)
This enables you to maximise the
vehicle’s loadspace.
It retains objects, preventing them
from sliding towards the front of the
passenger compartment.

You insert it under the luggage-
cover roller securing it on the
third-row side mouldings. Position 1
5-seat confi guration: installed behind
the second row.

Installing the roller

 Remove the protective covers
located under the blind roller
notches.

 Position the roller under that of
the luggage-cover blind.

 Raise the fl ap on the blind, posi-
tioning it on top of the blind.

 Deploy the net, passing it be-
tween the rollers and the seats.

 Pull the net upwards.

 Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).

Removing the roller

 Carry out these operations in re-
verse order. Position 2
2-seat confi guration; installed be-
hind the fi rst row.

Removing the roller

 Carry out these operations in re-
verse order.

Installing the roller

 With the second-row seats fold-
ed away, remove the covers of
the Isofi x mounting points locat-
ed on the seat backrests.

 Secure the roller on the Isofi x
mounting points.

 Deploy the net and pull it up-
wards.

 Anchor it to the roof by means of
the fi xing points (after you have
removed their covers).
