2009 TOYOTA PRIUS Owners Manual

5
When trouble arises
425
5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
*1: This warning light is di
splayed on the touch screen.
Warning lightWarning light/Details
Vehicle stability control system warning light (if
equipped)
Indicates a malfunction in the Enhanced VSC system.

*1
Automatic headlight leveling system warning light (if
equipped) Indicates a malfunction in the automatic headlight level-
ing system.

(U.S.A.)

(Canada)
ABS warning lightMalfunction in:
• The ABS; or
• The brake assist system.
Brake system warning light (yellow indicator) Malfunction in the electronically controlled brake sys-
tem.

*1
or
*1
Electric power steering system warning lightMalfunction in the EPS (Electric Power Steering).

426 5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
Have the malfunction repaired immediately.After taking the specified steps to correct the suspected problem,
check that the warning light turns off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*2
A door or a back door is
not fully closed.
Check that all doors and the
back door are closed.
Low fuel level warning
light Remaining fuel
(Approximately 3.0 gal.
[11.4 L, 2.5 Imp.gal.] or
less) Refuel the vehicle.
Driver’s seat belt
reminder light (warning
buzzer)
*3
Warns the driver to fasten
his/her seat belt. Fasten the seat belt.
Front passenger’s seat
belt reminder light
(warning buzzer)
*3
Warns the front passen-
ger to fasten his/her seat
belt. Fasten the seat belt.
Tire pressure warning
light
When the light comes on:
Low tire inflation pressure.
Adjust the tire inflation
pressure.
When the light stays on
after blinking for 1 minute:
Malfunction in the tire
pressure warning system. Have the system checked
by your Toyota dealer.

5
When trouble arises
427
5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
*1: This warning light is di
splayed on the touch screen.
*2: Open door warning buzzer:

(U.S.A.)
Engine oil replacement
reminder light
Illuminates for about 3 sec-
onds and then flasher for
about 15 seconds:
Engine oil is scheduled to
be changed. Check and the engine oil,
and change if necessary.
Comes on and remains:
Engine oil should be
changed. Check and change the
engine oil.

*1
Hybrid battery warning
light
The hybrid battery voltage
drops when the transmis-
sion is left in “N” position. Push the “P” position
switch.
The hybrid battery is dis-
charged. If this light comes on with
the “READY” light on in this
case, have the system
checked by your Toyota
dealer.

*1
High coolant temperature
warning light Indicates high engine cool-
ant temperature P. 454
Master warning light A buzzer sounds and the
warning light comes on
and flashes to indicate that
the master warning system
has detected a malfunc-
tion. Take appropriate action in
accordance with the mes-
sage displayed on the touch
screen.
Warning lightWarning light/DetailsCorrection procedure

428 5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
*3:Driver’s and front passenger’s seat belt reminder buzzer:
The driver’s and front passenger’s seat belts reminder sounds to alert the
driver and front passenger that his or her seat belt is not fastened. The
buzzer sounds intermittently for 10 seconds after the vehicle has reached a
speed of at lest 12 mph (20 km/h). Then, if the seat belt is still unfastened,
the buzzer will sound in a different tone for 20 more seconds.
Have the malfunction repaired immediately. (vehicles with smart
key system)
After taking the specified steps to correct the suspected problem,
check that the warning light turn off.
AlarmWarning lightDetailsCorrection procedure
Interior and
exterior alarm:
One beep
(sounds con-
tinuously)
The driver has
removed the smart key
from the vehicle while
the hybrid system is
not OFF and the shift
lever is in a position
other than “P”.Pressing the “P”
position switch
before removing the
smart key from the
vehicle and turning
the hybrid system
OFF.
Interior alarm:
One beep
Exterior alarm:
3 beeps The driver has
removed the smart key
from the vehicle while
the hybrid system is
not OFF and the shift
lever is in the “P” posi-
tion.
Turn the hybrid sys-
tem OFF and
remove the key
from the vehicle.
A passenger has
removed the smart key
from the vehicle while
the hybrid system is
not OFF. Check whether the
passenger leaving
the vehicle is carry-
ing the smart key.

5
When trouble arises
429
5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
Exterior alarm:
One beep
(sounds for 2
seconds)
The lock button has
been pressed while
the hybrid system is
not OFF and the shift
position is in “P”.
Turn the hybrid sys-
tem OFF.
Interior alarm:
One beep (for 5
seconds) The vehicle’s ID code
detection system has
judged that the smart
key is not present
when the “POWER”
switch is pressed.
Check that the
smart key is in the
vehicle and within
the detection area.
AlarmWarning
lightDetailsCorrection procedure

430 5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
■If the malfunction indicator lamp comes on while driving
First check the following:
● Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■ Power steering warning light
When the voltage is low or drops, the power steering warning light may
come on.
■ SRS warning light
This warning light system monitors the following:
● The airbag sensor assembly
● Front airbag sensors
● The curtain shield airbag sensors
● The side and curtain shield airbag sensor assemblies
● The driver’s seat position sensor
● Driver’s seat belt buckle switch
● The front passenger occupant classification ECU
● The pressure sensor
● The belt tension sensor
● “AIR BAG ON” and “AIR BA G OFF” indicator lights
● Front passenger’s seat belt buckle switch
● The inflators
● The warning light
● The interconnecting wiring and power sources

5
When trouble arises
431
5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
■
Front passenger detection sensor and passenger seat belt reminder
If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash, even if a passenger is not
sitting in the seat.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflation pressure changes caused by temper-
ature. In this case, adjusting the ti re inflation pressure will turn off the
warning light (after a few minutes).
■When a tire is replaced with a spare tire
The compact spare tire is not equipped with the tire pressure warning
valve and transmitter. If a tire goes flat, the tire pressure warning light will
not turn off even though the flat tire is replaced with the spare tire.
Replace the spare tire with the repair ed tire and adjust the proper tire
inflation pressure. The ti re pressure warning light will turn off after a few
minutes.
■If the tire pressure warning system is inoperative
The tire pressure warning system will be disabled in the following condi-
tions:
(When the condition be comes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmit-
ters are used.
●If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer.
●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or
higher.

432 5-2. Steps to take in an emergency
PRIUS_U_(OM47614U)
The tire pressure warning system may be disabled in the following condi-
tions:
(When the condition becomes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies
are nearby.
●If a radio set at similar frequencies is in use in the vehicle.
●If a window tint that affects the radio wave signals is installed.
●If there is a lot of snow or ice on the vehicle, in particular around the
wheels or wheel housings.
●If non-genuine Toyota wheels are used (Even if you use Toyota
wheels, the tire pressu re warning system may not work properly with
some types of tires.).
●If tire chains are used.
■If the tire pressure warning light comes on after blinking for 1
minute frequently
If the tire pressure warning light comes on after blinking for 1 minute fre-
quently when the “POWER” switch is turned to ON mode, have it
checked by your Toyota dealer.
