2009 OPEL AGILA Owners Manual

5-15Instruments and controls
Instantaneous consumption
Display of instantaneous fuel
consumption.
Until the vehicle is moving, “--.-”
appears in the display.
Average consumption
Display of average fuel consumption.
The measurement can be restarted at
any time.
To reset: With average consumption
showing in the display, press and
hold the MODE button for approx.
2 seconds. The display will show
“--.-” briefly and the average
consumption figure will update after a
delay.
Range
Range is calculated from current fuel
tank content and instantaneous
consumption. The display shows
average values.
The range is updated automatically
after a brief delay when the vehicle
has been refuelled.
When the vehicle is being driven,
“--.-” appears in the display when fuel
level is low: fill up fuel tank as soon as
possible.

5-16 Instruments and controls
If control indicator Y illuminates in the
instrument cluster, refuel
immediately, regardless of the value
shown in the range display.
Setting units of measure
You can select which units of
measure are to be used for fuel
consumption figures.
With the vehicle stationary and with
instantaneous consumption showing
in the display, press and hold the
MODE button for approx. 2 seconds
to toggle between L/100km and
km/L.
Interruption of power supply
If the power supply has been
interrupted or if the battery voltage
has dropped too low, the values
stored in the trip computer will be lost.

6-1Lighting
LightingExterior lighting
Exterior lamps controls
Rotate end of lever:
In positions 8 and P, the tail lamps,
license plate lamps and instrument
panel lamps are also on.
Headlamp range
adjustmentq
Correct adjustment reduces dazzle
for other road users.
With dipped beam on, adjust
headlamp range to suit vehicle load: Exterior lighting ..................... 6-1
Interior lighting ...................... 6-4
P= Dipped beam or
high beam
8= Parking lamps
OFF = Off
„Driver only
=0
„Front seats occupied
=0
„All seats occupied
=1
„All seats occupied and load
in luggage compartment=2
1)

6-2 Lighting
Hazard warning lamps
To operate, press button ¨.
Turn signal lamps
To activate, move lever up or down:
When the steering wheel is turned
back, the lever automatically returns
to its rest position. This will not
happen when making a minor
steering manoeuvre such as lane
changing.
Tap signal: briefly move lever to
resistance point. The turn signal then
flashes three times when changing
lanes.
Headlamp high beam
To switch from dipped beam to high
beam, push lever forwards.
To switch back to dipped beam, pull
lever back towards steering wheel.
Control indicator P illuminates in the
instrument cluster when high beam is
on.
Headlamp flash
To activate the headlamp flash, pull
lever towards steering wheel. High
beam is engaged for the duration of
activation. „Driver only and load in
luggage compartment=2
1)Vehicles with automatic transmission
and all diesel engines: set to position 1.
Lever up = Right turn
Lever down = Left turn

6-3Lighting
Front fog lamps > 3
The front fog lamps can only be
switched on when the ignition is on
and the light switch is in position 8
or P.
Follow the regulations of the country
in which you are driving when using
front fog lamps.
Rear fog lamp r
The rear fog lamp can only be
switched on when the ignition is on
and the light switch is in position P.
.
Reversing lamps
Illuminate when reverse gear is
engaged and ignition is switched on.
Headlamps when driving
abroad
The asymmetrical dipped beam
increases the field of vision on the
near side of the lane.
When driving in countries which drive
on the opposite side of the road, this
causes glare for oncoming traffic.
To avoid glare, the headlamp pattern
should be adjusted to the horizontal
position.
Have the headlamps adjusted by a
workshop.
On =
Press button >; control
indicator illuminates in
button.
Off = Press button > again;
control indicator
extinguishes in button.
On =
Turn adjustment band
tor; control indicatorr
illuminates in instrument
cluster.
Off = Turn adjustment band
to OFF; control indicator
r extinguishes.

6-4 Lighting
Interior lighting
Courtesy lamps
Move switch position:In the DOOR position, front interior
lamps and the luggage compartment
lamp function as courtesy lamps and
illuminate when the doors or tailgate
are opened. If doors or tailgate
remain opened, lamps remain
illuminated for approx. 15 minutes.
Once all doors and the tailgate are
closed, the courtesy lamps dim
gradually after approx. 15 seconds.
Lamps dim immediately when key is
inserted in ignition.
When key is removed from ignition,
courtesy lamps illuminate for approx.
15 seconds before dimming
gradually.
Depending on equipment version,
opening certain doors may not cause
courtesy lamps to illuminate, even
while the switch is in the DOOR
position. Doors which cause courtesy
lamps to illuminate are identified by a
switch in the door opening 3.
The tailgate always causes courtesy
lamps to illuminate when the interior
lamp switch is in the DOOR position.
Luggage compartment lamp
Illuminates when a door or the
tailgate is opened. OFF = Interior lamps remain
off.
DOOR = Interior lamps
illuminate when a
door or the tailgate is
opened.
ON = Interior lamps remain
on.
Caution
To prevent the battery from
becoming discharged, do not leave
the interior lamp switch in the ON
position when leaving the vehicle.

7-1 Infotainment system
Infotainment
system
Steering wheel mounted
remote control 3.................. 7-2
Theft-deterrent feature .......... 7-3
Operation .............................. 7-4
Sound settings ...................... 7-5
Radio .................................... 7-6
Audio players ........................ 7-9
Mobile telephones and radio
equipment (CB) 3 ............... 7-10
Introduction
Overview
1fEjection of CDs
26Sound settings
3iMute/unmute
4AST Auto search
5- Display panel
6- Slot for audio/MP3 CDs
7AF Alternative frequency
8PTY Program Type

7-2 Infotainment system
9TA Traffic Announcement
03, RDM Radio: Preset station 3,
CD/MP3: Random playback
a6, TEXT Radio: Preset station 6,
MP3: Text display
b2, RPT Radio: Preset station 2,
CD/MP3: Repeat track
c5, DISC/FLD + Radio: Preset station 5,
MP3: Skip to next folder
d4, - DISC/FLD Radio: Preset station 4,
MP3: Skip to previous folder
e1, SCN Radio: Preset station 1,
CD: Scan tracks
fb VOLUME Press: Switching on and off,
Turn: Volume setting
gCD CD player mode
hFM/AM Switch between FM and AM wavebands
igRadio: Search downwards,
CD: Skip backwards,
MP3: Skip to previous file
jhRadio: Search upwards,
CD: Skip forwards,
MP3: Skip to next fileSteering wheel mounted
remote control 3
Infotainment system functions can be
operated with the buttons mounted
on the steering wheel.
To change the volume:
Press the < or] button.
To mute the Infotainment system:
Press the i button.
To change the mode:
Press the MODE button.
Pressing the MODE button also
switches the Infotainment system on.
