2009.5 Peugeot 3008 Dag Owner's Manual

89
DIRECTIONAL LIGHTING
When the dipped or main beam head-
lamps are on, this function enables the
light beam to follow the direction of the
road.
The use of this function, coupled with the
xenon headlamps only, considerably im-
proves the quality of your lighting when
cornering.

with directional lighting

without directional lighting
Programming
Operating fault
The function is activated or
deactivated via the multi-
function display confi gura-
tion menu.
If a malfunction occurs, this warn-
ing light fl ashes on the instrument
panel, accompanied by a mes-
sage on the multifunction display.
Consult a PEUGEOT dealer.
AUTOMATIC ADJUSTMENT OF THE XENON HEADLAMPS
If a malfunction occurs, do not
touch the xenon bulbs. Consult
a PEUGEOT dealer.
In order to avoid causing a nuisance to
other road users, this system corrects
the height of the xenon headlamps beam
automatically and when stationary, in rela-
tion to the load in the vehicle.
If a malfunction occurs, this warn-
ing lamp is displayed on the in-
strument panel, accompanied by
an audible signal and a message
on the multifunction screen.
The system then places your head-
lamps in the lowest position.
When stationary or moving
at very low speed or when
reverse gear is engaged, the
function is inactive.
The status of the function remains
in the memory when the ignition is
switched off.

90
WIPER CONTROLS
System for selection and control of the
various front and rear wiping modes for
the elimination of rain and cleaning.
The vehicle's front and rear wipers are
designed to improve the driver's visibility
progressively according to the climatic
conditions.
Manual controls
The wiper commands are issued directly
by the driver by means of the stalk A and
the ring B .
Model with intermittent wiping
Model with AUTO wiping fast (heavy rain),
normal (moderate rain),
intermittent (proportional to
the speed of the vehicle),
automatic, then single
wipe (see next page).
park,
single wipe (press down-
wards),
Windscreen wipers

A. wiping speed selection stalk:
or
Programming
Various automatic wiper control modes
are also available according to the fol-
lowing options:
- automatic wiping for the windscreen wipers,
- rear wiping on engaging reverse gear.

91
Windscreen and headlamp wash
B. rear wiper selection ring:
park,
intermittent wipe,
wash-wipe (set duration).
Reverse gear
When reverse gear is engaged, the
rear wiper will come into operation if the
windscreen wipers are operating.
Programming
 Pull the windscreen wiper stalk to-
wards you. The windscreen wash
then the windscreen wipers operate
for a fi xed period.

If the dipped headlamps are on , the
headlamp washers operate at the same
time.
Rear wiper
If a signifi cant accumulation
of snow or ice is present, or
when using a bicycle carrier
on the boot, deactivate the automatic
rear wiper via the multifunction dis-
play confi guration menu.
The function is activated or de-
activated via the multifunction
display confi guration menu.
This function is activated
by default. Screenwash/headlamp wash low
In the case of vehicles fi tted with
headlamp washers, when the
minimum level of the reservoir
is reached, this warning light is
displayed on the instrument panel, ac-
companied by an audible signal and a
message on the multifunction display.
Next time you stop, fi ll the screenwash/
headlamp wash reservoir.
The warning light is displayed when the
ignition is switched on, or every time the
stalk is operated, until the reservoir is
fi lled.

92
Special position of the windscreen wipers Automatic windscreen wiping
The windscreen wipers operate auto-
matically, without any action on the part
of the driver, if rain is detected (sensor
behind the interior mirror), adapting their
speed to the intensity of the rainfall.
Activation
This is controlled manually by the driver by
pushing lever A to the "AUTO" position.
It is accompanied by a message on the
multifunction display. In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of the
windscreen.
This action enables you to position the
wiper blades for winter parking, clean-
ing or replacement.
To park the wipers after this has been
done, switch on the ignition and operate
the stalk.
Do not cover the rain sensor,
linked with the brightness sen-
sor and located in the centre
of the windscreen behind the interior
mirror.
Switch off the automatic wiping when
using an automatic car wash.
In winter, it is advisable to wait until
the windscreen is completely clear
of ice before activating the automatic
wiping. The automatic wiping must be
reactivated if the ignition has
been off for more than one
minute, by pushing lever A down-
wards.
Switching off
This is controlled manually by the driver
by moving lever A upwards and return-
ing it to position "0" .
It is accompanied by a message on the
multifunction display. Operating fault
If an automatic wiping malfunction oc-
curs, the wipers will operate in intermittent
mode.
Have it checked by a PEUGEOT dealer.
For optimum and lasting
wiping of the "fl at-blade" wiper
blades, it is advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen.

92
Special position of the windscreen wipers Automatic windscreen wiping
The windscreen wipers operate auto-
matically, without any action on the part
of the driver, if rain is detected (sensor
behind the interior mirror), adapting their
speed to the intensity of the rainfall.
Activation
This is controlled manually by the driver by
pushing lever A to the "AUTO" position.
It is accompanied by a message on the
multifunction display. In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of the
windscreen.
This action enables you to position the
wiper blades for winter parking, clean-
ing or replacement.
To park the wipers after this has been
done, switch on the ignition and operate
the stalk.
Do not cover the rain sensor,
linked with the brightness sen-
sor and located in the centre
of the windscreen behind the interior
mirror.
Switch off the automatic wiping when
using an automatic car wash.
In winter, it is advisable to wait until
the windscreen is completely clear
of ice before activating the automatic
wiping. The automatic wiping must be
reactivated if the ignition has
been off for more than one
minute, by pushing lever A down-
wards.
Switching off
This is controlled manually by the driver
by moving lever A upwards and return-
ing it to position "0" .
It is accompanied by a message on the
multifunction display. Operating fault
If an automatic wiping malfunction oc-
curs, the wipers will operate in intermittent
mode.
Have it checked by a PEUGEOT dealer.
For optimum and lasting
wiping of the "fl at-blade" wiper
blades, it is advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen.

93
COURTESY LIGHTS
Selection and control of the various
passenger compartment lights.

1. Front courtesy light

2. Map reading lights
Front and rear courtesy lights
In this position, the courtesy
light comes on gradually:
Map reading lights

 With the ignition on, press the cor-
responding switch.
In permanent lighting mode,
different lighting times are
available:
- with the ignition off, approximately ten minutes,
- in energy economy mode, approxi- mately thirty seconds,
- with the engine running, unlimited.
- when the vehicle is unlocked,
- when the key is removed from the
ignition,
- when a door is opened,
-
when the remote control locking button is
activated, in order to locate your vehicle.
Permanently off.
Permanent lighting. When the front courtesy light
is in the "permanent lighting"
position, the rear courtesy
light will also come on, unless it is in
the "permanently off" position.
To switch off the rear courtesy light,
place it in the "permanently off"
position.
Rear side reading lights

 With the ignition on, the fi rst press of
the corresponding switch switches on
the reading light concerned in perma-
nent lighting mode.

 Following a second press, it comes on: - when the vehicle is unlocked,
- when the key is removed from the ignition,
- when a door is opened,
- when the remote control locking button is pressed, in order to locate
your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Take care not to place anything
in contact with the courtesy
lights.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.

3. Rear side reading lights

4. Rear courtesy light

94
AMBIENT LIGHTING
The dimmed passenger compartment
lighting improves visibility in the vehicle
when the light is poor.
INTERIOR WELCOME LIGHTING
The remote switching on of the pas-
senger compartment lighting makes
your approach to the vehicle easier in
poor light. It operates with the automatic
switching on of the lights.
Switching on

 Press the open padlock on the re-
mote control.
The courtesy lights come on; your
vehicle is also unlocked.
Switching off
The interior welcome lighting switch-
es off automatically after a set time or
when one of the doors is opened.
Programming
Switching on
At night, the footwell lighting and the
front courtesy light ambient lamp A
come on automatically when the side
lights are switched on.
Switching off
The ambient lighting switches off
automatically when the side lights are
switched off.
Programming
The duration of the welcome
lighting is associated with and
identical to that of the auto-
matic follow-me-home lighting. The function is activated or
deactivated via the multi-
function display confi gura-
tion menu.
This function is activated
by default.
The function is activated or
deactivated via the multi-
function display confi gura-
tion menu.
EXTERIOR SIDE LIGHTERS
To make your approach to the vehicle
easier, these illuminate:
- the zones facing the driver’s and
passenger’s doors,
- the zones forward of the door mirrors and rearward of the front doors.
Switching on
The side lighters come on:
- when you unlock the vehicle,
- when you remove the key from the ignition,
- when you open a door,
- when you use the remote control.
Switching off
They are timed to go out automatically.

95
Different lighting times are
available:
- when the ignition is off, approxi-mately ten minutes,
- in energy economy mode, approxi- mately thirty seconds,
- when the engine is running, no limit.
This comes on automatically when the
boot is opened and switches off auto-
matically when the boot is closed.
BOOT LIGHTING TORCH
Removable light, incorporated in the
boot wall, which can be used to light the
boot or as a torch. Operation
Once engaged fi rmly in its location, it
comes on automatically when the boot
is opened and switches off automatic-
ally when the boot is closed.
It operates with NiMH type storage bat-
teries.
It has an operating autonomy of approxi-
mately 45 minutes and recharges while
you are driving.
Observe the polarities when
fi tting the storage batteries.
Never replace the storage batteries
with batteries.
For the torch function, refer to
the "Layout - § Torch" section.
