PREDICTED COURSE LINE OPERATION PRINCIPLE
Detection Of Steering Rotation Direction
Camera control unit detects the rotation direction of steering according to the phase difference of two pairs of
pulse signals (sensor signal 1 and sensor signal 2) input from steering angle sensor.
Detection Of Steering Neutral Position
The sensor signal 3 input from steering angle sensor is generated at 1 pulse per 1 rotation of the steering
wheel. Camera control unit detects the steering neutral position from this pulse.
Correction Of Steering Neutral Position
Camera control unit corrects the steering neutral position during driving according to the vehicle speed signal
and sensor signal.
JSNIA0708GB

AV-198
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
REAR VIEW MONITOR SYSTEM
Component Parts Location
INFOID:0000000003791258
1. Front squawker RH 2. Center speaker 3. Front squawker LH
4. Front door speaker LH 5. Rear door speaker LH 6. Rear control switch
7. Rear squawker LH 8. Woofer LH 9. BOSE amp.
10. Rear view camera 11. Woofer RH 12. Camera control unit
13. Rear squawker RH 14. Antenna amp. 15. Rear door speaker RH
16. Front door speaker RH 17. Steering angle sensor 18. Steering switch
19. AV control unit 20. Auxiliary input jacks 21. Preset switch
22. DVD player 23. Multifunction switch 24. Display unit
A. Trunk room upper RH B. Trunk room side RH C. Within rear pillar finisher RH
D. Spiral cable part E. In center console F. In grove box
JPNIA1058ZZ

AV
REAR VIEW MONITOR SYSTEM
AV-199
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Component DescriptionINFOID:0000000003791251
Part name Description
AV CONTROL UNIT Image on display is transmitted to rear view monitor image by serial communi-
cation between AV control unit and display unit.
 AV control unit recognizes the presence of camera system with camera con-
nection recognition signal.
DISPLAY UNIT Camera image signal is input from AV control unit.
 Rear view monitor image is changed by serial communication from AV control
unit.
CAMERA CONTROL UNIT Camera image signal is input from rear view camera. Camera image signal is
output to AV control unit.
 Power supply is transmitted to rear view camera.
 Superimposes the guiding line and predicted course line to the camera image
that outputs to AV control unit.
 Inputs the sensor signal from steering angle sensor, and then controls the pre-
dicted course line.
 Camera control unit is connected via AV communication.
REAR VIEW CAMERA The image of vehicle rear view is transmitted to camera control unit.
 It receives power supply from camera control unit and operates.
STEERING ANGLE SENSORSteering signal necessary for predicted course line control is transmitted to cam-
era control unit.

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-205
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P Display Diagnosis
The tint of the color bar indication is as per the following list if RGB signal error is detected.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the system.
Sp ea ke r Tes t
JSNIA0688GB
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
JSNIA0149GB
Diagnosis item Display Vehicle status Remarks
Vehicle speedON Vehicle speed > 0 km/h (0 MPH)
Changes in indication may be delayed by approximately
1.5 seconds. This is normal. OFF Vehicle speed = 0 km/h (0 MPH)
Parking brakeON Parking brake is applied.
OFF Parking brake is released.
LightsON Light switch ON
Block the light beam from the auto light optical sensor.
OFF Light switch OFF
IgnitionON Ignition switch ON
—
OFF Ignition switch in ACC position
ReverseONShift the selector lever to “R” posi-
tion
Changes in indication may be delayed by approximately
1.5 seconds. This is normal.
OFFShift the selector lever other than
“R” position

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-215
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
 For each signal, actual signal can be compared with the condition recognized on the system.
SELECTION FROM MENU
Allows the technician to select which vehicle signals should be displayed and displays the status of the
selected vehicle signals.
Display Item Display Vehicle status Remarks
VHCL SPD SIGOn Vehicle speed >0 km/h (0 MPH)
Changes in indication may be delayed. This is
normal. Off Vehicle speed =0 km/h (0 MPH)
PKB SIGOn Parking brake is applied.
Off Parking brake is released.
ILLUM SIGOnBlock the light beam from the auto
light optical sensor when the light
switch is ON .
—
OffExpose the auto light optical sensor
to light when the light switch is OFF
or ON.
IGN SIGOn Ignition switch ON
Off Ignition switch in ACC position
REV SIGOn Selector lever in R position
Changes in indication may be delayed. This is
normal.
OffSelector lever in any position other
than R
Item to be selected Description
VHCL SPD SIG
The same as when “ALL SIGNALS”
is selected. PKB SIG
ILLUM SIG
IGN SIG
REV SIG

AV
STEERING ANGLE SENSOR SIGNAL CIRCUIT
AV-253
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING ANGLE SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000003765727
 Steering angle sensor signal 1, 2 detects the turning direction and quantity of the steering and transmits it to
the camera control unit.
 Steering angle sensor signal 3 detects the neutral position of the steering and transmits it to the camera con-
trol unit.
 Camera control unit performs the correction of neutral position with sensor signal 1, 2, 3 and vehicle speed
signal.
Diagnosis ProcedureINFOID:0000000003901197
1.CHECK CONTINUITY STEERING ANGLE SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector and steering angle sensor connector.
3. Check continuity between camera control unit harness connector and steering angle sensor harness con-
nector.
4. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK SIGNAL SENSOR SIGNAL
1. Connect camera control unit connector.
2. Turn ignition switch ON.
3. Check voltage between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace camera control unit.
3.CHECK SIGNAL SENSOR SIGNAL
1. Turn ignition switch OFF.
2. Connect steering angle sensor connector.
Camera control unit Steering angle sensor
Continuity
Connector Terminals Connector Terminals
B25123
M303
Existed 24 6
25 8
Camera control unit
GroundContinuity
Connector Terminals
B25123
Not existed 24
25
(+)
(−)Voltag e
(Approx.) Camera control unit
Connector Terminals
B25123
Ground 5.0 V 24
25

AV-254
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
STEERING ANGLE SENSOR SIGNAL CIRCUIT
3. Turn ignition switch ON.
4. Check signal between camera control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace steering angle sensor.
(+)
(−) Condition Reference value Camera control unit
Connector Terminals
B25123, 24 GroundTurn the steering to the right
A: Sensor signal 1
B: Sensor signal 2
Turn the steering to the left
A: Sensor signal 1
B: Sensor signal 2
25 GroundTurn the steering around the
neutral position
A: Sensor signal 3
B: Sensor signal 1
SKIB3827E
SKIB3828E
SKIB3829E

AV-352
< ECU DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
CAMERA CONTROL UNIT
20
(L)—AV communication signal
(H)Input/
Output—— —
22
(W)Ground Reverse signal InputIgnition
switch
ONSelector lever in R position. 12.0 V
Other than selector lever in
R position.0 V
23
(G)Ground Sensor signal 1 InputIgnition
switch
ONTurn the steering to the
right.
A: Sensor signal 1
B: Sensor signal 2
Turn the steering to the left.
A: Sensor signal 1
B: Sensor signal 2
24
(SB)Ground Sensor signal 2 InputIgnition
switch
ONTurn the steering to the
right.
A: Sensor signal 1
B: Sensor signal 2
Turn the steering to the left.
A: Sensor signal 1
B: Sensor signal 2
25
(O)Ground Sensor signal 3 InputIgnition
switch
ONTurn the steering around
the neutral position.
A: Sensor signal 3
B: Sensor signal 1 Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3827E
SKIB3828E
SKIB3827E
SKIB3828E
SKIB3829E
